571-1. For safe use
GX 460 _O M_ OM6 0L 72U _( U)
1
For safety and security
Installing child restraints
Child restraint LATCH anchors
LATCH anchors are provided for the
right side second seat and between the
center and left side second seats. (But-
tons displaying the location of the
anchors are attached to the seats.)
Seat belts equipped with a child
restraint locking mechanism (ALR/
ELR belts except driver’s seat belt)
( → P. 3 0 )
Anchor brackets (for top tether strap)
An anchor bracket is provided for each
second seat.
Follow the child restraint system manufacturer’s instructions. Firmly secure
child restraints to the seats using the LATCH anchors or a seat belt. Attach the
top tether strap when installing a child restraint.
The lap/shoulder belt can be used if yo ur child restraint system is not compati-
ble with the LATCH (Lower Anchors and Tethers for Children) system.
GX460_OM_OM60L72U_(U).book Page 57 Friday, May 16, 2014 3:03 PM

73
GX 460 _O M_ OM6 0L 72U _( U)
Instrument cluster2
2. Instrument clusterWarning and indicators lights ................................................. 74
Gauges and meters ..................... 79
Multi-information display .......... 82
Fuel consumption information ...................................88
GX460_OM_OM60L72U_(U).book Page 73 Friday, May 16, 2014 3:03 PM

74
GX 460 _O M_ OM6 0L 72U _( U)2. Instrument cluster
Warning and indicators lights
The units used on the speedometer may di
ffer depending on the target region.
The warning and indicators lights on the instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.
GX460_OM_OM60L72U_(U).book Page 74 Friday, May 16, 2014 3:03 PM

79
GX 460 _O M_ OM6 0L 72U _( U)2. Instrument cluster
2
Instrument cluster
Gauges and meters
The units used on the speedometer may di
ffer depending on the target region.
Ta c h o m e t e r
Displays the engine speed in revolutions per minute
Engine coolant temperature gauge
Displays the engine coolant temperature
Multi-information display
Presents the driver with a variety of driving-related data (→P. 8 2 )
Fuel gauge
Displays the quantity of fuel remaining in the tank
Speedometer
Displays the vehicle speed
Rear height control air suspension display (if equipped)
Displays the rear height mode selected ( →P. 3 3 1 )
Shift position and shift range display
Displays the selected shift position or selected shift range ( →P. 1 9 0 )
Odometer and trip meter display
Odometer:
Displays the total distance the vehicle has been driven
Tr i p m e t e r :
Displays the distance the vehicle has been driven since the meter was last reset. Trip
meters A and B can be used to record and display different distances independently.
1
2
3
4
5
6
7
8
GX460_OM_OM60L72U_(U).book Page 79 Friday, May 16, 2014 3:03 PM

80
GX 460 _O M_ OM6 0L 72U _( U)2. Instrument cluster
Switches between odometer and trip
meter displays. When the trip meter is
displayed, pressing and holding the
button will reset the trip meter.
The brightness of the instrument cluster lights can be adjusted.
Brighter
Darker
Changing the display
Instrument cluster light control switch
1
2
GX460_OM_OM60L72U_(U).book Page 80 Friday, May 16, 2014 3:03 PM

GX 460 _O M_ OM6 0L 72U _( U)
812. Instrument cluster
2
Instrument cluster
■The meters and display illuminate when
The engine switch is in IGNITION ON mode.
■Instrument cluster brightness adjustment
The instrument cluster brightness levels when the tail lights are on and off can be
adjusted.
■The brightness of the instrument cluster lights
When the tail lights are on, the brightness wi ll change. However, when the surroundings
are bright (daytime, etc.) turning on the tail lights will not change the instrument cluster
brightness.
In addition, the brightness of the instrument cluster lights is automatically adjusted based
on the light sensor detecting ho w bright the surroundings are.
■When disconnecting and reconnecting battery terminals
The trip meter data will be reset.
If the trip meter was displayed last, the odometer will be displayed after resetting.
■Customization
Setting of sensitivity of the ambient light se nsor used for dimming the meter lights can be
changed. (Customizable features: → P. 5 8 6 )
NOTICE
■To prevent damage to the engine and its components
●Do not let the indicator needle of the tachometer enter the red zone, which indicates
the maximum engine speed.
●The engine may be overheating if the engine coolant temperature gauge is in the red
zone (H). In this case, immediately stop the vehicle in a safe place, and check the
engine after it has cooled completely. ( →P. 5 5 5 )
GX460_OM_OM60L72U_(U).book Page 81 Friday, May 16, 2014 3:03 PM

82
GX 460 _O M_ OM6 0L 72U _( U)2. Instrument cluster
Multi-information display
The multi-information display presents the driver with a variety of driving-related
data.
●Trip information contents (
→P. 8 3 )
Displays driving range, fuel consump-
tion and other cruising related informa-
tion
●Electronic features control contents
(→ P. 8 4 )
●Other contents ( →P. 8 5 )
Display contents
GX460_OM_OM60L72U_(U).book Page 82 Friday, May 16, 2014 3:03 PM
