maintenance reset Lexus GX460 2015 TIPS FOR THE NAVIGATION SYSTEM / LEXUS 2015 GX460 OWNERS MANUAL (OM60L72U)

GX460_OM_OM60L72U_(U)
4456-2. Maintenance
6
Maintenance and care
■Repair and replacement
It is recommended that genuine Lexus parts be used for repairs to ensure performance
of each system. If non-Lexus parts are used in replacement or if a repair shop other than
a Lexus dealer performs repairs, confirm the warranty coverage.
■Resetting the message indicating maintenance is required (U.S.A. only)
After the required maintenance is performed according to the maintenance schedule,
please reset the message.
To reset the data, follow the procedures described below:Press the Menu switch ( P. 83) to change the multi-information display to blank.
Turn the engine switch off.
While pressing the ODO/TRIP button ( P. 80), turn the engine switch to IGNITION
ON mode.
Continue to press and hold the button for more than 7 seconds after the engine switch
is turned to IGNITION ON mode.
■Allow inspection and repairs to be performed by a Lexus dealer
●Lexus technicians are well-trained specialists an d are kept up to date with the latest ser-
vice information. They are well informed about the operation of all systems on your
vehicle.
●Keep a copy of the repair order. It proves that the maintenance that has been per-
formed is under warranty coverage. If any problem should arise while your vehicle is
under warranty, your Lexus dealer will promptly take care of it.
The message shown in the illustration will
appear on the display.
After 5 seconds, the sys-
tem reset will be completed.
1
2
3
4

5257-2. Steps to take in an emergency
GX460_OM_OM60L72U_(U)
7
When trouble arises
*: Refer to the separate “Scheduled Mainte nance” or “Owner’s Manual Supplement”
for the maintenance interval applicable to your vehicle.
(If equipped)
Indicates that the pre-collisio n system is not currently
functional because the grille cover or the sensor is dirty
 Check the grille cover and the sensor and clean
them if they are dirty.
(If equipped)
Indicates a malfunction in the rear height control air sus-
pension
A buzzer also sounds.
 Immediately stop the vehicle in a safe place and
contact your Lexus dealer.
(U.S.A. only)
Indicates that all maintenance according to the driven
distance on the maintenance schedule
* should be per-
formed soon.
Comes on approximately 4500 miles (7200 km) after
the message has been reset.
 If necessary, perform maintenance.
(U.S.A. only)
Indicates that all maintenance is required to correspond
to the driven distance on the maintenance schedule*.
Comes on approximately 5000 miles (8000 km) after
the message has been reset. (The indicator will not work
properly unless the message has been reset.)
Perform the necessary maintenance.
Please reset the message after the maintenance is
performed ( P. 4 4 5 )
Wa r n i n g m e s s a g eDetails/Actions

623Alphabetical index
GX460_OM_OM60L72U_(U)
Keyless entrySmart access system with push-button start ...................... 94, 101
Wireless remote control ................... 94
Keys............................................................... 90 Battery-saving function ...................... 113
Electronic key .........................................90
If the electronic key does not operate properly............................ 549
If you lose your keys .......................... 614
Key number plate .................................90
Keyless entry .................................. 94, 101
Mechanical key ........................................91
Replacing the battery ...................... 483
Wireless remote control ...................90
KDSS ......................................................... 346 Warning light ........................................ 512
Lane Departure Alert (LDA) .......... 232
Lever Auxiliary catch lever .........................454
Hood lock release lever .................454
Shift lever ................................................. 190
Turn signal lever .................................. 194
Wiper lever .......................................... 206
License plate lights.................................196 Light switch ............................................ 196 Light
Engine switch light ............................ 396
Fog light switch ................................... 204
Headlight switch ..................................196
Illuminated entry system.................398
Interior light........................................... 397
Interior light list .................................... 396
Personal light ....................................... 397
Replacing light bulbs .......................490
Turn signal lever ...................................194
Vanity lights ............................................415
Wattage ................................................... 571
Light bulbs Replacing ...............................................490
Wattage ................................................... 571
Lock steering column........................... 187
Luggage cover ...................................... 408
Maintenance Do-it-yourself maintenance ...........451
Maintenance data.............................. 562
Maintenance requirements .......... 444
Resetting the message indicating maintenance is
required .............................................. 445
Malfunction indicator lamp ................. 511
Master warning light ............................. 519
K
L
M
*:For vehicles with a navigation system or a multimedia system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIMEDIA OWNER’S MANUAL”.

625Alphabetical index
GX460_OM_OM60L72U_(U)
Power outlet ............................................. 417
Power windows .......................................146Jam protection function ....................147
Operation ............................................... 146
Window lock switch.......................... 146
Pre-Collision System (PCS) ............ 362 Function ..................................................362
PCS OFF switch ................................363
Warning light ........................................ 512
Radiator ......................................................461
Radio
*
Rear seat ................................................... 120 Adjustment ............................................. 120
Rear turn signal lights ...........................194 Replacing light bulbs ....................... 495
Turn signal lever .................................. 194
Wattage ................................................... 571
Rear view mirror Inside rear view mirror ....................... 141
Outside rear view mirrors .............. 143
Rear view monitor system .................247
Rear window defogger ......................385
Rear window wiper................................. 211
Refueling .................................................... 214 Capacity ................................................ 564
Fuel types .................................... 214, 564
Opening the fuel tank cap.............. 216 Replacing
Electronic key battery .....................483
Fuses ........................................................485
Light bulbs.............................................490
Tires .......................................................... 533
Wireless remote control battery ..................................................483
Reporting safety defects for U.S. owners .................................. 600
Reset the maintenance data ............ 445
Safety connect........................................432
Seat belts .................................................... 28 Adjusting the seat belt........................ 29
Automatic Locking Retractor ........ 30
Child restraint system installation ............................................. 57
Cleaning and maintaining the seat belt ....................................... 442
Emergency Locking Retractor................................................ 30
How to wear your seat belt............. 28
How your child should wear the seat belt .......................................... 30
Pregnant women, proper seat belt use........................... 31
Reminder light and buzzer .............513
Seat belt pretensioners...................... 29
Seat belt extender ................................ 30
SRS warning light ................................. 511
R
S
*:For vehicles with a navigation system or a multimedia system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIMEDIA OWNER’S MANUAL”.
