Lexus GX460 2016 Multimedia Manual /

71
GX460_QG_OM60M82U_(U)
■Radio
Tuning to preset stations/channels
Using HD Radio
TM Te c h n o l o g y ( f o r
U.S.A., if equipped)
Scanning for receivable stations
Press: Selects a preset station
Press and hold: Seeks for a station
Adjusting the frequency
■Entering station presets
Tune in the desired station.
Select “(add new)”.
Select “Yes” on the confirmation screen.
Select “OK” after setting the new preset station.
Radio mode has a mix preset function, which can store up to 36 stations (6 stations per
page x 6 pages) from any of the AM, FM or SAT bands.
1
2
3
4
5
1
2
3
4

72
GX460_QG_OM60M82U_(U)
■CD player
■
Playing an audio CD
Random playback
Repeat playback
Playback/pause
CD eject
Selecting a track
Disc slot
■Playing a CD with MP3/WMA/AAC files
Displaying a folder list
Random playback
Repeat playback
Playback/pause
CD eject
Selecting a file/fast forward/rewind
Selecting a file
Disc slot
1
2
3
4
5
6
1
2
3
4
5
6
7
8

73
GX460_QG_OM60M82U_(U)
■Operating an iPod
■
Playing an iPod audio
Selecting a play mode
Random playback
Repeat playback
Playback/pause
Selecting a track/fast forward/rewind
■Playing an iPod video
Image display (full screen)
Playback/pause
Selecting a file
1
2
3
4
5
1
2
3

74
GX460_QG_OM60M82U_(U)
Rear Seat Entertainment System (if equipped)
Front audio/visual system
Displays
Rear seat entertainment system controller
Headphone volume control dials and headphone jacks
HDMI port
A/V input port
For details, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIME-
DIA OWNER’S MANUAL”.
The rear seat entertainment system is designed for the rear passengers to enjoy audio
and DVD video separately from the front audio/visual system.
1
2
3
4
5
6

75
GX460_QG_OM60M82U_(U)
■Basic operation
Turns display off
Selects the display to be operated
L: left side display
R: right side display
Power on or off
Turning on the audio source selection
screen
Selecting an icon
Inputting the selected icon
■AM/FM/SAT
Select radio mode on the source screen to
display the control screen.
Selecting a preset station/channel
Press: Tuning the station/channel
Press and hold: Seeking a station/
channel
Press: Tuning the station/channel
Press and hold: Seeking a station/
channel
1
2
3
4
5
6
1
2
3

76
GX460_QG_OM60M82U_(U)
■DISC/USB/iPod/BT-A
Select desired mode on the source screen
to display the control screen.
Selecting a folder/an album
Play/pause
Fa st for wa rd or rewin d
Press: Selecting a track/file
Press and hold: Fast forward or rewind
1
2
3
4

77
GX460_QG_OM60M82U_(U)
■DVD video
Press “DISC” or select disc mode to display DVD video.
Selecting an icon
Turning on the DVD mode
Inputting the selected icon
Playing/pausing a disc
Fast forwarding a disc during playback
and forward slowly during pause.
Stopping a screen
Tu r n i n g o n t h e m e n u
Turning on the option screen
Turning on the title selection screen
Press to select a chapter
Press and hold to fast forward or
rewind a chapter
Rewinding a disc
■Headphone jacks
To listen to the rear audio, use headphones.
To use the headphones, connect them
to the jack.
To adjust the volume.
1
2
3
4
5
6
7
8
9
10
11
1
2

78
GX460_QG_OM60M82U_(U)
Front Air Conditioning System
■Control panel
■Control screen
Without a navigation system With a navigation system

79
GX460_QG_OM60M82U_(U)
■Adjusting the temperature setting
Press to increase the temperature and to decrease the temperature.
■Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan speed.
■Changing the air flow mode
Select an air outlet switch.
■Option control screen
Touch on the climate screen to display the option control screen. The functions
can be switched on and off.Select to set cooling and dehumidifica-
tion function on/off
Adjust the temperature for driver and
passenger seats separately (“DUAL”
mode)/driver, passenger and rear seats
separately (“3-ZONE” mode)
Prevent ice from building up on the
windshield and wiper blades (if
equipped)
Remove pollen from the air
■Using the automatic mode
Press the “AUTO” button to turn on the air flow and adjust the temperature setting.
■Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)/driver, passenger and rear seats separately (“3-ZONE”
mode)
To turn on the “DUAL”/“3-ZONE” mode, perform any of the following procedures:
● Press the “DUAL”/“3-ZONE” button.
● Select “DUAL”/“3-ZONE” on the option control screen.
● Adjust the passenger’s side temperature setting.
1
2
3
4

80
GX460_QG_OM60M82U_(U)
Rear Air Conditioning System (if equipped)
■Control panel
■
Adjusting the temperature setting
Press “ ” on the “TEMP” button to increase the temperature and “ ” to decrease the
temperature.
■Adjusting the fan speed setting
Press “ ” on to increase the fan speed and “ ” to decrease the fan speed.
■Changing the air flow mode
Press .
The air flow mode switch each time the button is pressed.
■Using the automatic mode
Press the “AUTO” button to turn on the air flow and adjust the temperature setting.
