3855-1. Using the air conditioning system and defogger
5
Interior features
■Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove raindrops, dew
and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
■Micro dust and pollen filter mode
Pollen is removed from the air and the air flows to the upper part of the body.
Touch on the option control screen.
When the micro dust and pollen filter mode is on, is displayed on the air
conditioning control screen.
In order to prevent the windshield from fo gging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the mi cro dust and pollen filter mode is turned
off.
■Windshield wiper de-icer (if equipped)
This feature is used to prevent ice fr om building up on the windshield and
wiper blades.
Touch on the option control screen.
When the windshield wiper de-icer is on , is displayed on the air condition-
ing control screen.
The windshield wiper de-icer will automati cally turn off after a period of time.

GX460_OM_OM60M73U_(U)
3895-1. Using the air conditioning system and defogger
5
Interior features
CAUTION
■To prevent the windshield from fogging up
●Do not use during cool air operation in extremely humid weather. The differ-
ence between the temperature of the outside air and that of the windshield can cause
the outer surface of the windshield to fog up, blocking your vision.
■To prevent burns
●Do not touch the rear view mirror surfaces when the outside rear view mirror defog-
gers are on.
●Do not touch the glass at lower part of the wi ndshield or to the side of the front pillars
when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is
off.
●Do not place anything on the instrument
panel which may cover the air outlets. Other-
wise, air flow may be obstructed, preventing
the windshield defoggers from defogging.

GX460_OM_OM60M73U_(U)
4055-3. Using the storage features
5
Interior features
■Auxiliary box light (type B)
●The auxiliary box light turns on when the tail lights are on.
●The brightness of the auxiliary box light changes in conjunction with the instrument
cluster light. ( P. 8 0 )
■Closing the auxiliary box lid
Slide the auxiliary box lid forward.
CAUTION
■Caution while driving
Do not place cups, beverage cans or bottles in the box. They may be thrown out of the
box in the event of sudden braking, sudden sw erving or an accident, resulting in injury.
(type B and C)
■Items unsuitable for storing (type A)
●Do not store items heavier than 0.2 kg (0.4 lb.).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.
●Do not put large items in the overhead console.
The overhead console may not be able to be shut from the conversation mirror state.

GX460_OM_OM60M73U_(U)
4155-4. Using the other interior features
5
Interior features
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
Slide the cover to open.
The light turns on when the cover is
opened.
If the vanity lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.
Sun visors
1
2
3
Vanity mirror
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended periods
when the engine is not running.

416
GX460_OM_OM60M73U_(U)5-4. Using the other interior features
The conversation mirror can provide the driver and the front passenger with a
view of the rear seat area without the need to turn around.
Press in the button.
To use the overhead console when the conversation mirror is open, further extend the lid.
(
 P. 4 0 4 )
Vehicles with a navigation system
Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
Vehicles without a navigation system
Adjusts the hours
Adjusts the minutes
■The clock is displayed when
The engine switch is in IGNITION ON mode.
■When disconnecting and reco nnecting battery terminals
The clock data will be reset.
Conversation mirror
Clock
1
2

GX460_OM_OM60M73U_(U)
4235-4. Using the other interior features
5
Interior features
The compass on the inside rear view mirror indicates the direction in which the
vehicle is heading.
■Operation
To turn the compass on or off, push
the switch.
■Displays and directions
Compass (if equipped)
DisplayDirection
“N”North
“NE”Northeast
“E”East
“SE”Southeast
“S”South
“SW”Southwest
“W”We s t
“NW”Northwest

426
GX460_OM_OM60M73U_(U)5-4. Using the other interior features
■Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:
●The vehicle is stopped immediately after turning.
●The vehicle is on an inclined surface.
●The vehicle is in a place where the earth’s ma
gnetic field is subject to interference by
artificial magnetic fields (underground car park/parking lot, under a steel tower,
between buildings, roof car park/parking lot, near an intersection, near a large vehicle,
etc.).
●The vehicle has become magnetized.
(There is a magnet or metal object near the inside rear view mirror.)
●The battery has been disconnected.
●A door is open.
CAUTION
■While driving the vehicle
Do not adjust the display. Adjust the di splay only when the vehicle is stopped.
■When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity. Do not vio-
late any local traffic rules while performing circling calibration.
NOTICE
■To avoid the compass malfunctions
Do not place magnets or any metal object s near the inside rear view mirror.
Doing this may cause the compass sensor to malfunction.
■To ensure normal operation of the compass
●Do not perform a circling calibration of the compass in a place where the earth’s
magnetic field is subject to interfer ence by artificial magnetic fields.
●During calibration, do not operate electric systems (moon roof, power windows, etc.)
as they may interfere with the calibration.

438
GX460_OM_OM60M73U_(U)6-1. Maintenance and care
Cleaning and protecting the vehicle exterior
●Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.
●Wash the vehicle body using a sponge or soft cloth, such as a chamois.
●For hard-to-remove marks, use car wash soap and rinse thoroughly with
water.
●Wipe away any water.
●Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle body is cool.
■Automatic car washes
●Fold the mirrors back before washing the vehicle. Start washing from the front of the
vehicle. Make sure to extend the mirrors before driving.
●Brushes used in automatic car washes may scratch the vehicle surface and harm your
vehicle’s paint.
■High pressure car washes
●Do not allow the nozzles of the car wash to come within close proximity of the windows
and the air suspension unit.
●Before using the car wash, check that the fuel
filler door on your vehicle is closed prop-
erly.
■Aluminum wheels
●Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or
abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild
detergent and wax as used on the paint.
●Do not use detergent on the wheels when they are hot, for example after driving for
long distance in the hot weather.
●Wash detergent from the wheels immediately after use.
■Bumpers and side moldings
Do not scrub with abrasive cleaners.
Perform the following to protect the ve hicle and maintain it in prime condi-
tion:

620Alphabetical index
GX460_OM_OM60M73U_(U)
Condenser ................................................461
Console box ...........................................400
Cool box ....................................................413
Cooling system ..................................... 459Engine overheating.......................... 556
Conversation mirror .............................416
Crawl Control ....................................... 340
Cruise control Cruise control....................................... 218
Dynamic radar cruise control........221
Cup holders ............................................ 402
Curtain shield airbags ........................... 34
Current fuel consumption ................... 83
Customizable features ....................... 586
DAC (Downhill Assist Control system)................................................... 343
Daytime running light system ........... 198
Defogger Front windshield ................................ 384
Outside rear view mirrors ............ 385
Rear window ....................................... 385
Differential ............................................... 567
Dimension ............................................... 562
Display Multi-information display .................. 82
Trip information .....................................83
Warning message ............................ 520
Do-it-yourself maintenance ...............451
Doors ............................................................ 94 Back door ............................................. 101
Door glasses ......................................... 146
Door lock .................................................. 94
Open door warning light................ 514
Outside rear view mirrors .............. 143
Rear door child-protector................ 97 Driver’s seat position memory........... 131
Driving ........................................................ 154
AVS switch ........................................... 335
Break-in tips .......................................... 155
Correct posture .................................... 26
Procedures .............................................154
Winter drive tips .................................. 371
Dynamic radar cruise control ........... 221
Eco Driving Indicator ............................ 86
EDR (Event data recorder)................... 10
Electronic key ........................................... 90 Battery-saving function ......................113
If the electronic key does not operate properly ........................... 550
Replacing the battery ...................... 484
Emergency, in case of If the electronic key does not operate properly ........................... 550
If the engine will not start ............... 547
If the shift lever cannot be shifted from P ................................... 549
If the vehicle has discharged battery ........................553
If the warning buzzer sounds ................................................... 512
If the warning light turns on ............512
If you have a flat tire .......................... 534
If you lose your keys...........................614
If you think something is wrong.................................................... 510
If your vehicle becomes stuck......................................................559
If your vehicle needs to be towed ...................................................504
If your vehicle overheats ................556
D
E

622Alphabetical index
GX460_OM_OM60M73U_(U)
Fuel ............................................................. 564Capacity ................................................ 564
Fuel gauge ................................................ 79
Fuel pump shut off system................ 511
Information ............................................ 572
Refueling...................................................214
Type ............................................... 214, 564
Warning light ........................................ 514
Fuel consumption information ........... 88
Fuel filler door .......................................... 214 Refueling...................................................214
Fuel gauge ...................................................79
Fuel pump shut off system.................... 511
Fuses .......................................................... 486
Garage door opener ...........................427
Gauges .........................................................79
Glass hatch .............................................. 106
Glove box ................................................400
Hands-free system (for cellular phone)
*
Head restraints ........................................136
Headlights .................................................196 Light switch ............................................ 196
Replacing light bulbs ........................493
Wattage ................................................... 571
Headlights cleaner.................................213
Heaters Automatic air conditioning system .................................... 380, 390
Seat heaters ..........................................394
Outside rear view mirrors ............ 385 Height control ......................................... 331
Hill-start assist control ....................... 346
Hood ......................................................... 454
Hooks
Cargo hooks .......................... 406, 407
Coat hooks ............................................. 421
Retaining hooks (floor mat)..............24
Horn............................................................. 139
I/M test ..................................................... 450
Identification Engine ..................................................... 564
Vehicle ....................................................563
Ignition switch (engine switch) .........185
Ignition switch light .............................. 396
Illuminated entry system ................... 398
Immobilizer system ................................ 68
Indicators ..................................................... 74
Initialization Moon roof .............................................. 150
Power windows.................................... 147
Inside rear view mirror...........................141
Instrument panel light control ............ 80
Interior lights .......................................... 396 Switch ...................................................... 397
Wattage ................................................... 571
Jack Vehicle-equipped jack ...................535
Jack handle ............................................. 538
Jam protection function Moon roof .............................................. 150
Power windows.................................... 147
G
H
I
J
