4356-1. Maintenance and care
6
Maintenance and care
■Plated portions
If dirt cannot be removed, clean the parts as follows:
●Use a soft cloth dampened with an approximately 5% solution of neutral detergent and
water to clean the dirt off.
●Wipe the surface with a dry, soft cl oth to remove any remaining moisture.
●To remove oily deposits, use alcohol wet wipes or a similar product.
WARNING
■When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may cause the
electrical components etc. to catch fire.
■When cleaning the windshield (vehicles with rain-sensing windshield wiper)
●When the upper part of the windshield where the raindrop sensor is located is
touched by hand
●When a wet rag or similar is held close to the raindrop sensor
●If something bumps against the windshield
●If you directly touch the raindrop sensor bo dy or if something bumps into the raindrop
sensor
■Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-
ciently, as touching a hot exhaust pipe can cause burns.
■Precautions regarding the Blind Spot Monitor (if equipped)
If the paint of the rear bump er is chipped or scratched, the system may malfunction.
If this occurs, consult your Lexus dealer.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wipers may
operate unexpectedly in the following situa-
tions, and may result in hands being caught or
other serious injuries and cause damage to the
wiper blades.Off
AUTO

5157-2. Steps to take in an emergency
GX460_OM_OM60R27U_(U)
7
When trouble arises
*1: This light illuminates on the multi-information display.
*2: Open door warning buzzer: The open door warning buzzer sounds to al ert hood or one or more of the doors or
glass hatch are not fully closed (with the vehicle having reached a speed of 3 mph [5
km/h]).
*3: Driver’s seat belt warning buzzer:
The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt
is not fastened. Once the engine switch is turned to ON, the buzzer sounds. If the seat
belt is still unfastened, the buzzer sounds intermittently for a certain period of time
after the vehicle reaches a certain speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds
intermittently for a certain period of time after the vehicle reaches a certain speed.
■SRS warning light
This warning light system monitors the airbag sensor assembly, front airbag sensors, side
and curtain shield airbag sensors, rear side and curtain shield airbag sensors, floor sen-
sor, driver’s seat belt buc kle switch, front passenger occupant classification system (ECU
and sensors), “AIR BAG ON” indicator light, “AIR BAG OFF” indicator light, front pas-
senger’s seat belt buckle sw itch, seat belt pretensioner assemblies, airbags, intercon-
necting wiring and power sources. ( P. 36)
■Front passenger detection sensor, seat belt reminder and warning buzzer
●If luggage is placed on the front passenger seat, the front passenger detection sensor
may cause the warning light to flash and the warning buzzer to sound even if a passen-
ger is not sittin g in the seat.
●If a cushion is placed on the seat, the sens or may not detect a passenger, and the warn-
ing light may not operate properly.
■If the malfunction indicator lamp comes on while driving
First check the following:
●Is the fuel tank empty?
If it is, fill the fu el tank immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after several driving trips.
If the light does not go off even after severa l trips, contact your Lexus dealer as soon as
possible.

GX460_OM_OM60R27U_(U)
5818-2. Customization
8
Vehicle specifications
■Automatic light control system (P. 209)
*:Except for Canada
■Interior lights (P. 392)
FunctionDefault settingCustomized setting
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
—OO60 seconds
90 seconds
Light sensor sensitivityStandard-2 to 2—OO
Daytime running light sys-
temOnOff*—OO
Welcome lighting illumina-
tion controlOnOff——O
123
FunctionDefault settingCustomized setting
Time elapsed before the
interior lights turn off15 seconds
Off
—OO7.5 seconds
30 seconds
Operation after the engine
switch is turned to OFFOnOff——O
Operation when the doors
are unlocked with the smart
access system with push-
button start or wireless
remote control
OnOff——O
Operation when you
approach the vehicle with
the electronic key on your
person
OnOff——O
Shift lever lightOnOff——O
Footwell lightingOnOff——O
Lounge illumination controlOnOff——O
123

582
GX460_OM_OM60R27U_(U)8-2. Customization
■Exterior lights (P. 392)
■Front automatic air conditioning system (P. 376)
*: If equipped
FunctionDefault settingCustomized
setting
Time elapsed before the
running board lights turn off15 seconds
Off
—OO7.5 seconds
30 seconds
Operation of the running
board lights when the doors
are unlocked with the smart
access system with push-
button start or wireless
remote control
OnOff——O
Operation of the running
board lights when you
approach the vehicle with
the electronic key on your
person
OnOff——O
Running board lightsOnOff——O
Operation of the running
board lights when the door
is opened
OnOff——O
123
FunctionDefault settingCustomized setting
Switching between outside
air and recirculated air
mode linked to automatic
mode switch operation
*
AutoManual—OO
A/C automatic mode
switch operationAutoManual—OO
Exhaust gas sensor sensitiv-
ityStandard-3 to 3—OO
123

584
GX460_OM_OM60R27U_(U)8-2. Customization
■Intuitive parking assist* (P. 266)
*: If equipped
■In the following situations, customize mode will automatically be turned off.
●A warning message appears after the cu
stomize mode screen is displayed.
●The engine switch is turned to OFF.
●The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault settingCustomized
setting
Intuitive parking assistOnOffO——
Buzzer volumeLevel 3Level 1 to 5—OO
Display settingAll sensors displayedDisplay off—OO
Detection distance of the
front center sensorFarNear—OO
Detection distance of the
rear center sensorFarNear—OO
123
WARNING
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

604What to do if... (Troubleshooting)
GX460_OM_OM60R27U_(U)
●It is locked automatically to prevent theft of the vehicle. ( P. 198)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 156)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 198)
●The seat belt reminder light is flashing
Are the driver and the front passe nger wearing the seat belts?
( P. 513)
●The parking brake indicator is on
Is the parking brake released? ( P. 208)
Depending on the situation, other types of warning buzzer may also sound.
( P. 511, 520)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 78)
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine. The steering wheel cannot be turned after the engine is stopped
The windows do not open or close by operating the power window
switches
The engine switch is turned off automatically
A warning buzzer sounds during driving
An alarm is activated and the horn sounds

612Alphabetical index
GX460_OM_OM60R27U_(U)
MaintenanceDo-it-yourself maintenance.......... 447
Maintenance data ............................. 552
Maintenance requirements.......... 440
Resetting the message indicating maintenance is
required................................................ 441
Malfunction indicator lamp ................. 511
Meter Indicators................................................... 82
Instrument panel light control .........89
Meters........................................................ 88
Multi-information display ....................91
Warning lights ........................................ 82
Micro dust and pollen filter ............... 381
Mirrors Inside rear view mirror ....................... 151
Outside rear view mirror defoggers ............................................ 381
Outside rear view mirrors .............. 153
Vanity mirrors ......................................... 411
Moon roof................................................. 159 Jam protection function ................... 160
Operation ............................................... 159
MP3 disc
*
Multi-information display .......................91 BSM (Blind Spot Monitor)............357
Crawl Control .....................................344
Display contents ......................................91
Drive information .................................. 93
Dynamic radar cruise control......254
Intuitive parking assist ...................... 267
Language ............................................... 577
LDA (Lane Departure Alert) .......249
Multi-terrain Select............................284
Warning message ............................ 520 Multi-terrain Monitor ......................... 288
Multi-terrain Select ............................. 284
Navigation system
*
Odometer .................................................. 88
Off-road precautions ......................... 370
Oil
Engine oil ...............................................554
Front differential oil ........................... 557
Rear differential oil ............................ 557
Transfer.................................................. 558
Opener Back door..................................................112
Fuel filler door.......................................227
Hood........................................................450
Outside rear view mirrors .................. 153 Adjusting and folding ........................153
Blind Spot Monitor ........................... 357
Outside rear view mirror defoggers............................................ 381
Outside temperature display ............. 88
Overheating, Engine .......................... 546
Parking assist sensors (intuitive parking assist)...................266
Parking brake ........................................ 208 Operation..............................................208
Parking brake engaged warning buzzer ...............................208
Parking lights Light switch........................................... 209
Replacing light bulbs ....................... 497
M
N
O
P

614Alphabetical index
GX460_OM_OM60R27U_(U)
Seat heaters ............................................ 390
Seat ventilators ........................................391
Seat position memory............................ 141
Seats.................................................. 128, 130Adjustment ...................................128, 130
Adjustment precautions ........129, 140
Child seats/child restraint system installation............................. 58
Cleaning ................................................. 437
Driving position memory .................. 141
Head restraint ....................................... 146
Properly sitting in the seat ................ 28
Seat position memory......................... 141
Ventilators .............................................. 391
Sensor Automatic headlight system .......... 210
Automatic High Beam system ...... 212
Inside rear view mirror ..................... 152
Intuitive parking assist-sensor .....266
LDA (Lane Departure Alert) .......246
Radar sensor ....................................... 230
Rain-sensing windshield wipers ...................................................220
Service reminder indicators ............... 82
Shift lever Automatic transmission ..................202
If the shift lever cannot be shifted from P .................................. 205
Shift lock system.................................... 204
Side airbags ............................................... 36
Side mirrors ............................................. 153 Adjusting and folding........................ 153
Blind Spot Monitor............................357 Side turn signal lights ...........................207
Replacing light bulbs ....................... 497
Turn signal lever ................................. 207
Smart access system with push-button start...................................121 Antenna location....................................121
Starting the engine ..............................196
Snow tires ................................................ 369
Spare tire ..................................................524 Inflation pressure............................... 560
Storage location ................................. 525
Spark plug ............................................... 556
Specifications......................................... 552
Speedometer ............................................ 88
Steering lock Column lock release .........................199
Steering wheel ........................................ 149 Adjustment..............................................149
Audio switches
*
Heated steering wheel ...................389
Steering wheel position memory...................................................141
Stop/tail lights Replacing light bulbs ....................... 497
Storage feature ..................................... 395
Stuck If the vehicle becomes stuck........ 549
Sunshade Roof ........................................................... 160
Sun visors.....................................................411
Switch Automatic High Beam switch ....... 212
AVS switch ........................................... 339
BSM (Blind Spot Monitor) switch ...................................................358
Center differential lock/ unlock switch...................................... 341
