horn Lexus GX460 2020 Owner's Manual / LEXUS 2020 GX460 OWNER'S MANUAL (OM60R27U)

1493-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GX460_OM_OM60R27U_(U)
Steering wheel
Up
Down
Toward the driver
Away from the driver
To sound the horn, press on or close to
the mark.
Adjustment procedure
1
2
3
4
Horn

GX460_OM_OM60R27U_(U)
2714-5. Using the driving support systems
4
Driving
■The intuitive parking assist can be operated when
●Front corner sensors:
• The engine switch is in IGNITION ON mode.
• The shift lever is in a position other than P.
• The vehicle speed is less than approximately 6 mph (10 km/h).
(At any speed when the shift lever is in R)
●Front center sensors:
• The engine switch is in IGNITION ON mode.
• The shift lever is in a position other than P or R.
• The vehicle speed is less than about 6 mph (10 km/h).
●Rear corner and rear center sensors:
• The engine switch is in IGNITION ON mode.
• The shift lever is in R.
■Intuitive parking assist display
When an obstacle is detected while the rear view monitor system, Lexus parking assist
monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the upper
corner of the screen even if the display setting has been set to off.
■Sensor detection information
●The sensor’s detection areas are limited to the areas around the vehicle’s bumper.
●Certain vehicle conditions and the surrounding environment may affect the ability of a
sensor to correctly detect an obstacle. Pa rticular instances where this may occur are
listed below.
• There is dirt, snow or ice on the sensor . (Wiping the sensors will resolve this prob-
lem.)
• The sensor is frozen. (Thawing the area will resolve this problem.) In especially cold weather, if a sensor is frozen the screen may show an abnormal
display, or obstacles may not be detected.
• The sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass.
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines, air brakes of large vehicles, or other loud noises producing ultrasonic waves.
• There is another vehicle equipped with parking assist sensors in the vicinity.
• The sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or wireless antenna.
• The bumper or sensor re ceives a strong impact.
• The vehicle is approaching a tall or curved curb.
• In harsh sunlight or intense cold weather.
• The area directly under the bumpers is not detected.
• If obstacles draw too close to the sensor.
• A non-genuine Lexus suspension (low ered suspension etc.) is installed.
• People may not be detected if they are wearing certain types of clothing.
In addition to the examples above, there ar e instances in which, because of their shape,
signs and other objects may be judged by a sensor to be closer than they are.

538
GX460_OM_OM60R27U_(U)7-2. Steps to take in an emergency
If the engine will not start
One of the following may be the cause of the problem:
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
●The engine may be flooded.
Try to restart the engine again follo
wing correct starting procedures.
( P. 196)
●There may be a malfunction in th e engine immobilizer system. (P. 76)
One of the following may be the cause of the problem:
●The battery may be discharged. ( P. 543)
●The battery terminal connections may be loose or corroded.
The engine starting system may be malfun ctioning due to an electrical problem
such as an open circuit or a blown fuse. However, an interim measure is available
to start the engine. ( P. 539)
If the engine will not start even though correct starting procedures are being
followed ( P. 196), consider each of the following points:
The engine will not start even when the starter motor operates nor-
mally.
The starter motor turns over slowly , the interior lights and headlights
are dim, or the horn does not sound or sounds at a low volume.
The starter motor does not turn over.

5397-2. Steps to take in an emergency
GX460_OM_OM60R27U_(U)
7
When trouble arises
One of the following may be the cause of the problem:
●One or both of the battery terminals may be disconnected.
●The battery may be discharged. ( P. 543)
●There may be a malfunction in the steering lock system.
Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures
are unknown.
When the engine does not start, the follo wing steps can be used as an interim
measure to start the engine if the engine switch is functioning normally.
Set the parking brake.
Shift the shift lever to P.
Turn the engine switch to the ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while depressing the
brake pedal firmly.
Even if the engine can be started using the above steps, the system may be mal-
functioning. Have the vehicle in spected by your Lexus dealer.
The starter motor does not turn over, the interior lights and headlights
do not turn on, or the horn does not sound.
Emergency start function
1
2
3
4

604What to do if... (Troubleshooting)
GX460_OM_OM60R27U_(U)
●It is locked automatically to prevent theft of the vehicle. ( P. 198)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 156)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 198)
●The seat belt reminder light is flashing
Are the driver and the front passe nger wearing the seat belts?
( P. 513)
●The parking brake indicator is on
Is the parking brake released? ( P. 208)
Depending on the situation, other types of warning buzzer may also sound.
( P. 511, 520)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 78)
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine. The steering wheel cannot be turned after the engine is stopped
The windows do not open or close by operating the power window
switches
The engine switch is turned off automatically
A warning buzzer sounds during driving
An alarm is activated and the horn sounds

610Alphabetical index
GX460_OM_OM60R27U_(U)
Fuel ............................................................. 554Capacity ................................................ 554
Fuel gauge ............................................... 88
Fuel pump shut off system.............. 510
Information ............................................562
Refueling................................................. 225
Type ............................................. 554, 562
Warning light ........................................ 513
Fuel consumption information ........... 98
Fuel filler door ........................................ 225 Refueling................................................. 225
Fuel gauge .................................................. 88
Fuel pump shut off system.................. 510
Fuses .......................................................... 486
Garage door opener .......................... 425
Gauges ........................................................ 88
Glass hatch ................................................ 116
Glove box ................................................ 396
Hands-free system (for cellular phone)
*
Head restraints ........................................146
Headlights ............................................... 209 Light switch .......................................... 209
Replacing light bulbs ........................ 497
Headlights cleaner............................... 224
Heaters Automatic air conditioning system ..................................... 376, 386
Seat heaters ......................................... 390
Outside rear view mirrors .............. 381
Height control........................................ 335
Hill-start assist control ........................ 352 Hood ......................................................... 450
Hooks
Cargo hooks ...........................402, 403
Coat hooks ........................................... 420
Retaining hooks (floor mat)............. 26
Horn............................................................. 149
I/M test ......................................................446
Identification Engine .....................................................554
Vehicle ....................................................553
Ignition switch (engine switch) ......... 196
Ignition switch light .............................. 392
Illuminated entry system ................... 394
Immobilizer system ................................. 76
Indicators .................................................... 82
Initialization Items to initialize ................................ 585
Maintenance data....................441, 454
Moon roof .............................................. 160
Power windows.................................... 157
Tire pressure warning system ..... 466
Inside rear view mirror.......................... 151
Instrument panel light control ............ 89
Interior lights .......................................... 392 Switch ...................................................... 393
Wattage ...................................................561
Jack Vehicle-equipped jack ................... 525
Jack handle ............................................. 528
Jam protection function Moon roof .............................................. 160
Power windows.................................... 157
