This device complies with FCC Rules part 15.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference that
may be received, including interference that may
cause undesired operation. WARNING: This trans-
mitter has been tested and complies with FCC
and DOC/MDC rules. Changes or modifications
not expressly approved by the party responsible
for compliance could void the user’s authority to
operate the device.
FCC ID: CB2070NHL3
CANADA: 279 103 1936A
INTERIOR EQUIPMENT
73
(c) Erasing the entire HomeLink memory (all
three programs)
To erase all previously programmed codes at one time, press
and hold down the 2 outside buttons for 20 seconds until the
indicator light flashes.
If you sell your vehicle, be sure to erase the programs stored
in the HomeLink
 memory.
CAUTION
 When programming the HomeLink Universal
Transceiver, you may be operating a garage door or
other device. Make sure people and objects are out
of the way of the garage door or other device to
prevent potential harm or damage.
 Do not use this HomeLink
 Universal Transceiver
with any garage door opener that lacks the safety
stop and reverse feature as required by federal safety
standards. (This includes any garage door opener
model manufactured before April 1, 1982.) A garage
door opener which cannot detect an object (signaling
the door to stop and reverse), does not meet current
federal safety standards. Using a garage door opener
without these features increases risk of serious
injury or death.
CUP HOLDERS
Front
 In front of the rear console box
To use the cup holder, push the cup holder lid.
The cup holder is designed for holding cups or drink −cans
securely.
The cup holder can be adjusted to the size of the cups by
changing the separator position or moving the separator arms.
You can use it as an accessory box by removing the separator
inside.

COMFORT ADJUSTMENT
124
Replace the belt assembly (including bolts) if it has
been used in a severe impact. The entire assembly
should be replaced even if damage is not obvious.
Fastening front, second and third seat belts
Adjust the seat as needed and sit up straight and well back
in the seat. To fasten your belt, pull it out of the retractor
and insert the tab into the buckle.
You will hear a click when the tab locks into the buckle.
The seat belt length automatically adjusts to your size and the
seat position.
The retractor will lock the belt during a sudden stop or on
impact. It also may lock if you lean forward too quickly. A slow,
easy motion will allow the belt to extend, and you can move
around freely. When a passenger’s shoulder belt is completely extended and
is then retracted even slightly, the belt is locked in that position
and cannot be extended. This feature is used to hold the child
restraint system securely.
(For details, see “Child restraint” on
page 150.) To free the belt again, fully retract the belt and then
pull the belt out once more.
If the seat belt cannot be pulled out of the retractor, firmly pull
the belt and release it. You will then be able to smoothly pull
the belt out of the retractor.
CAUTION
 After inserting the tab, make sure the tab and buckle
are locked and that the belt is not twisted.
 Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
 If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed. It cannot protect
an adult occupant or your child from injury.

STARTING AND DRIVING
324
Only use tires of specified size. The size,
manufacturer, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle skid
control system may not function correctly. When
replacing the tires or wheels, contact your Lexus
dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.
 Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving. The slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
Pushing the center differential lock switch automatically
turns
the vehicle skid control system off. At this time, the
“VSC OFF” indicator comes on with the center differential
lock indicator light.
“VSC OFF” indicator light comes on for a few seconds when
the ignition key is turned to “ON”. It will come on again when
you push the center differential lock switch to turn off the
system.
In the following cases, contact your Lexus dealer:
 The indicator light does not come on when the ignition key
is turned “ON”.

STARTING AND DRIVING
333
CAUTION
Do not overestimate the antilock brake system:
Although the antilock brake system assists in
providing vehicle control, it is still important to drive
with all due care and maintain a moderate speed and
safe distance from the vehicle in front of you, because
there are limits to the vehicle stability and effectiveness
of steering wheel operation even with the antilock
brake system on.
If tires grip performance exceeds its capability, or if
hydroplaning occurs during high speed driving in the
rain, the antilock brake system does not provide
vehicle control.
Antilock brake system is not designed to shorten the
stopping distance: Always drive at the moderate speed
and maintain a safe distance from the vehicle in front of
you. Compared with vehicles without an antilock
brake system, your vehicle may require a longer
stopping distance in the following cases:
 Driving on rough, gravel or snowcovered roads.
 Driving with tire chains installed.
Driving over the steps such as the joints on the road.
 Driving on roads where the road surface is pitted or
has other differences in surface height.
Install all 4 tires of specified size at appropriate
pressure: The antilock brake system detects vehicle
speeds using the speed sensors for respective wheels’
turning speeds. The use of tires other than specified
may fail to detect the accurate turning speed resulting
in a longer stopping distance.

STARTING AND DRIVING
336
LIMITEDSLIP DIFFERENTIAL
Your Lexus is equipped with a limited−slip center differential
(transfer).
If one wheel − either front or rear − begins to spin, the transfer
(limited −slip center differential) is designed to aid traction by
automatically transmitting driving force to the wheels on the
other drive axle. It transmits driving force to the front wheels
if a rear wheel spins, and to the rear wheels if a front wheel
spins.
CAUTION
Do not start or run the engine while your vehicle is
supported by a jack. The vehicle could be driven off the
jack and could pose a danger or result in serious injury.
NOTICE
Use only a spare tire of the same size, construction and
load capacity as the original tires on your Lexus
because damage to the limitedslip differential could
possibly occur with another tire type.
TYPES OF TIRES
Determine what kind of tires your vehicle is originally equipped
with.
1. Summer tires
Summer tires are high −speed capability tires best suited to
highway driving under dry conditions.
Since summer tires do not have the same traction performance
as snow tires, summer tires are inadequate for driving on
snow−covered or icy roads. For driving on snow −covered or
icy roads, we recommend using snow tires. If installing snow
tires, be sure to replace all four tires.
2. All season tires
All season tires are designed to provide better traction in snow
and to be adequate for driving in most winter conditions, as well
as for use all year round.
All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow.
Also, all season tires fall short in acceleration and handling
performance compared with summer tires in highway driving.

STARTING AND DRIVING
337
CAUTION
Do not mix summer and all season tires on your
vehicle as this can cause dangerous handling
characteristics, resulting in loss of control.
 Do not use tires other than the manufacturer’s
designated tires, and never mix tires or wheels of the
sizes different from the originals.

CHASSIS
429
CHASSIS LUBRICATION
Propeller shafts Spiders and slide yoke
Lithium base wheel bearing grease, NLGI No.2
STEERING
Free play
Less than 30 mm (1.2 in.)
Power steering fluidAutomatic transmission fluid DEXRONII or III
TIRES AND WHEELS
Tire size
P265/65R17 110S
Tire inflation pressure Recommended cold tire inflation pressure220 kPa (2.2 kgf/cm2 or bar, 32 psi)
Wheel size17 x 7 1/2 JJ
Wheel nut torque112 N·m (11.5 kgf·m, 83 ft·lbf)
NOTE:
For complete information on tires (e.g. replacing tires or replacing wheel\
s), see “Checking tire pressure” through “Aluminum wh eel
precautions” on pages 432 through 440.

CHASSIS
432
CAUTION
The reservoir may be hot so be careful not to burn
yourself.
NOTICE
Avoid overfilling, or the power steering could be
damaged.
 When adding the power steering fluid, avoid spilling
it. The generator under the power steering reservoir
could be damaged if fluid is spilled on it.
CHECKING TIRE PRESSURE
The recommended cold tire pressures, tire size and the
vehicle capacity weight are given on the label.
You should check the tire pressures every two weeks, or at
least once a month. And don’t forget the spare! The pressure
for the spare tire should be 220 kPa (2.2 kgf/cm
2 or bar, 32 psi).
Incorrect tire pressure can reduce tire life and make your
vehicle less safe to drive.
If a tire needs frequent refilling, have it checked by your Lexus
dealer.

CHASSIS
435
If you have tire damage such as cuts, splits, cracks deep
enough to expose the fabric, or bulges indicating internal
damage, the tire should be replaced.
If a tire often goes flat or cannot be properly repaired due to the
size or location of a cut or other damage, it should be replaced.
If you are not sure, consult with your Lexus dealer.
If an air loss occurs while driving, do not continue driving with
a deflated tire. Driving even a short distance can damage a tire
beyond repair.
Any tires which are over 6 years old must be checked by
a qualified technician even if damage is not obvious.
Tires deteriorate with age even if they have never or seldom
been used.
This also applies to the spare tire and tires stored for future use.
Uniform tire quality grading
This information has been prepared in accordance with
regulations issued by the National Highway T
raffic Safety
Administration of the U.S. Department of Transportation.
It provides the purchasers and/or prospective purchasers
of Lexus vehicles with information on uniform tire quality
grading.
Your Lexus dealer will help answer any questions you may
have as you read this information.
DOT quality grades All passenger vehicle tires must
conform to Federal Safety Requirements in addition to
these grades. Quality grades can be found where
applicable on the tire sidewall between tread shoulder and
maximum section width. For example: Treadwear 200
Traction AA Temperature A
Treadwear − The treadwear grade is a comparative rating
based on the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and a half (1 − 1/2)
times as well on the government course as a tire graded 100.
The relative performance of tires depends upon the actual
conditions of their use, however, and may depart significantly
from the norm due to variations in driving habits, service
practices and differences in road characteristics and climate.
Traction AA, A, B, C − The traction grades, from highest to
lowest, are AA, A, B and C, and they represent the tire’s ability
to stop on wet pavement as measured under controlled
conditions on specified government test surfaces of asphalt
and concrete. A tire marked C may have poor traction
performance.

CHASSIS
436Warning: The traction grade assigned to this tire is based on
braking (straight ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, C − The temperature grades are A (the
highest), B, and C, representing the tire’s resistance to the
generation of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor laboratory
test
wheel. Sustained high temperature can cause the material
of the tire to degenerate and reduce tire life, and excessive
temperature can lead to sudden tire failure. The grade C
corresponds to a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle Safety
Standard No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the minimum
required by law.
Warning: The temperature grades for this tire are established
for a tire that is properly inflated and not overloaded. Excessive
speed, underinflation, or excessive loading, either separately
or in combination, can cause heat buildup and possible tire
failure.
Tire selection
When replacing a tire, use a tire of the same size and
construction, and the same or greater load capacity as the
originally installed tires. Also, all the tires must be the
same brand and have the same tread patterns.
Using any other size or type of tire may seriously affect
handling, ride, speedometer/odometer calibration, ground
clearance, and clearance between the body and tires or snow
chains.
CAUTION
Observe the following instructions. Otherwise, an
accident may occur resulting in death or serious
injuries.
 Do not mix radial, bias belted, or biasply tires on
your vehicle, as this may cause dangerous handling
characteristics resulting in loss of control.
 Do not use tires other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
 Do not use tires of different brands, sizes,
construction or tread patterns, as this may cause
dangerous handling characteristics result ing in loss
of control.
