GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
IF THIS INDICATOR OR
BUZZER COMES ON...
DO THIS.
(k)Take vehicle to Lexus
dealer.
(l)Stop and check.
(m)Stop and check.
(n)Replace engine oil.
(o)
Adjust tire inflation
pressure. If light
remains, contact
Lexus dealer.
(p)Fill up tank.
IF THIS INDICATOR ORBUZZER COMES ON...DO THIS.
(q)Add washer fluid.
(r)Key reminder buzzerRemove key.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
64
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the ONº position.
 When the parking brake is applied...
This light comes on for a few seconds when the ignition key is
in the ONº position even after the parking brake is released.
 When the brake fluid level is low...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
When the hydraulic brake booster fails...
If the hydraulic booster causes a problem resulting in poor
braking performance, the warning light comes on and buzzer
sounds continuously.
Have your vehicle checked at your Lexus dealer in the
following cases:
 The light does not come on even if the parking brake is
applied when the ignition key is in the ONº position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If any of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
 The warning buzzer comes on together with the
warning light.
In either case, this can indicate that the brakes may not
work properly and your stopping distance will become
longer. Depress the brake pedal firmly and bring the
vehicle to an immediate stop.
 The brake system warning light remains on together
with the ABSº warning light.
In this case, not only the anti-lock brake system will fail,
but also the vehicle will become extremely unstable
during braking.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
66
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ONº position. It goes off after about 6 seconds. This
means the SRS airbags and front seat belt pretensioners
are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver's seat position sensor, driver's seat belt buckle switch,
front seat belt pretensioner assemblies, inflators, warning light,
RSCA OFFº indicator light, interconnecting wiring and power
sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
 The light does not come on when the ignition key is turned
to the ONº position or remains on for more than 6 seconds
or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags have a problem. If the light flashes, the side
and curtain shield airbags and/or seat belt pretensioners have
a problem.
(e) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
ONº position and goes off after the engine starts. This
means that the warn ing light system is operating properly.
If the lamp remains on, or the lamp comes on while driving,
first check the followings.
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp does not go off even after several trips, contact your
Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
 There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If engine speed does not increase when the accelerator pedal
is depressed, there may be a problem somewhere in the
electronic throttle control system.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ACCº or LOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On-Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see Emissions inspection and maintenance (I/M)
programsº on page 539.
(f) ABSº Warning Light
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ABSº warning light is on (and the brake system
warning light is off), the following systems do not operate, but
the brake system still operates conventionally.

Anti-lock brake system
 Brake assist system
 Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill-start assist control system
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate, so that the wheels will lock up during a sudden braking
or braking on slippery road surfaces.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
70
(j) VSC TRACº Warning Light
This light warns that there is a problem somewhere in the
following.
Vehicle stability control system
 Active traction control system
 Downhill assist control system
 Hill-start assist control system
The light will come on when the ignition key turned to ONº, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the ONº position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the VSC TRACº warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to ONº.
 The warning light remains on after the ignition key is turned
to ONº.
 The warning light comes on while driving.
(k) KDSSº Warning Light (vehicles with kinetic
dynamic suspension system)
This light warns that there is a problem somewhere in the
kinetic dynamic suspension system.
The light will come on when the ignition key is turned to the
ONº position and will go off after a few seconds.
If the light comes on while driving, bring your vehicle to your
Lexus dealer as soon as possible and have it checked.
(l) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
71
NOTICE
Do not continue driving if the engine drive belt is brokenor loose.
(m) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance. The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on Ð
even for one block. It may ruin the engine.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
72
(n) Engine Oil Replacement Reminder Light (for vehicles sold in U.S.A.)
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to ONº
and will go off after about a few seconds.
When you drive for about 7200 km (4500 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to ONº position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds 8000 km (5000 miles), the light will come on after the
ignition key is turned to ONº position. The light will remain on
thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible.
You need to reset the light after the engine oil replacement.
Reset the light by following the procedure below:
1. Turn the ignition key to the ACCº or LOCKº position with
the odometer reading shown. (For details, see Odometer and
trip meterº on page 61.)
2. Turn the ignition key to the ONº position while holding down
the trip meter reset knob.
Hold down the knob until the light goes off. Before the light
goes off, it illuminates for 3 seconds, flashes for 2 seconds and
illuminates for 1 second. If the system fails to reset, the light will remain flashing. In this
case, return to step 1 and try again.(o) Low Tire Pressure Warning Light
This light warns that the tire pressure of one or more of your
tires
(including the spare tire) is low. The light comes on when
the ignition key is turned to the ONº position. It goes off after
a few seconds. This indicates that the tire pressure warning
system is functioning properly.
If the warning light comes on, stop your vehicle in a safe place
as soon as possible and check that the inflation pressure of all
tires (including the spare tire) is as specified on the tire and
loading information label. (See Checking tire inflation
pressureº on page 579.) The light should go off a few minutes
after the tire pressure is adjusted.
If the warning light blinks, the tire pressure warning system
may be malfunctioning. Contact your Lexus dealer.
For details, see Tire pressure warning systemº on page 434.
(p) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.

STARTING AND DRIVING
392
HOW TO START THE ENGINE
Cranking hold function
Once you turn the ignition key to STARTº position and release
it, the cranking hold function continues to crank the engine in
ONº position until it starts.
The function stops cranking the engine after about 25 seconds
maximum if the engine has not started yet. When you crank
the engine again, wait a few seconds and restart it.
If you hold the key in STARTº position, the function will keep
cranking for about 30 seconds maximum.
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in Pº. If you need to restart the engine
while the vehicle is moving, put the selector lever in Nº. A
starter safety device will prevent the starter from operating if
the selector lever is in any drive position.
4. Depress the brake pedal and hold it to the floor until driving
off.
Starting the engine
Before starting the engine, be sure to follow the instructions in
Before crankingº.
Normal starting procedure
The multiport fuel injection system/sequential multiport fuel
injection system in your engine automatically controls the
proper air-fuel mixture for starting. You can start a cold or hot
engine as follows:
With your foot off the accelerator pedal, turn the ignition key to
STARTº position, then release it.
Engine should be warmed up by driving, not in idle. For
warming up, drive with smoothly turning engine until engine
coolant temperature is within normal range.
If the engine stalls...
Simply restart it, using the correct procedure given in normal
starting.
If the engine will not start...
See If your vehicle will not startº on page 481.
NOTICE
Do not race a cold engine.
If the engine becomes difficult to start or stalls frequently, have the engine checked immediately.

STARTING AND DRIVING
419
(f) Parking and stopping tips
If you immediately stop the engine to park the vehicle after
off-road driving, the vehicle height is lowered slightly as the
vehicle becomes cool. When parking, make sure there is
nothing that will be in contact with the underbody of the vehicle.
When you start the engine, the vehicle returns to the previous
height.
If you park the vehicle for a long time, the vehicle height may
be gradually lowered. When parking for a long time, make sure
there is nothing that will be in contact with the underbody of the
vehicle. When you start the engine, the vehicle returns to the
previous height.
If you stop the engine, the vehicle height may change in
accordance with the change in the temperature. When you
start the engine, the vehicle returns to the previous height.
(g) Rear height control failure warning
If there is a problem somewhere in the rear height control air
suspension, the Nº mode is automatically selected. If this
occurs, the height control OFFº indicator light blinks and the
vehicle height control cannot be activated until the malfunction
is corrected. If this is the case, bring your vehicle to your Lexus
dealer as soon as possible and have it checked.
ELECTRONIC MODULATED SUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1For driving on a bumpy road
2For ordinary driving such as in the city traffic
3For moderate high speed driving
4For sporty type driving such as on winding mountain
roads and high speed driving
5Soft
6Firm

STARTING AND DRIVING
421

Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the active traction control
system is in the self-check mode, but does not indicate a
malfunction.
When the active traction control system is operating, the
following conditions occur:
 The system controls the spinning of the 4 wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly. The slip indicator light comes on for a few seconds when the
ignition key is turned to ONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
VSC TRACº warning light
This light warns that there is a problem somewhere in the
following.

Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill-start assist control system
When the system is normal and the ignition key is turned to
ONº, the warning light will come on and will go off after a few
seconds. It is not a malfunction that the warning light may stay
on for 60 seconds after the ignition key is turned to the ONº
position.
