INTRODUCTION
544
NOTICE
You should not attempt to remove the theft preventionlabels as it may violate certain state or federal laws.
ENGINE COMPARTMENT OVERVIEW
1Engine oil leveldipstick
2Engine oil filler cap
3Brake fluid reservoir
4Fuse box
5Battery
6Condenser
7Electric cooling fan
8Radiator
9Engine coolantreservoir
10Washer fluid tank
11Power steering fluidreservoir

INTRODUCTION
545
Removing the engine compartment covers
Before checking the power steering fluid or fuses in the
engine compartment, remove the engine compartment
covers as follows:
61PY007
1Turn the plastic nuts counterclockwise and remove them.
2Push the core of the clips using a Phillips-head
screwdriver and remove the clips.

INTRODUCTION
546
3Remove the covers.
Be careful not to lose the removed plastic nuts and clips.
After checking the items, install the engine compartment
covers and insert the plastic nuts and clips in their original
positions.
When inserting the clips, do as shown above.
NOTICE
After installing the engine compartment covers, make sure the covers are securely in their original positions.

INTRODUCTION
547
DO-IT-YOURSELF SERVICEPRECAUTIONS
If you perform maintenance yourself, be sure to follow the
correct procedure given in this Section.
You should be aware that improper or incomplete servicing
may result in operating problems.
Performing do-it-yourself maintenance during the warranty
period may affect your warranty coverage. Read the separate
Lexus Warranty statement for details and suggestions.
This Section gives instructions only for those items that are
relatively easy for an owner to perform. As explained in
Section 5, there are still a number of items that must be
performed by a qualified technician with special tools.
For information on tools and parts for do-it-yourself
maintenance, see Parts and toolsº on page 549.
Utmost care should be taken when working on your vehicle to
prevent accidental injury. Here are a few precautions that you
should be especially careful to observe:
CAUTION

When the engine is running, keep hands, clothing,
and tools away from the moving fan and engine drive
belt. (Removing rings, watches, and ties is
advisable.)

Right after driving, the engine compartment Ð the
engine, radiator, exhaust manifold and power
steering fluid reservoir, etc. Ð will be hot. So be
careful not to touch them. Oil, other fluids and spark
plugs may also be hot.

If the engine is hot, do not remove the radiator cap or
loosen the drain plugs to prevent burning yourself.

Do not leave anything that may burn easily, such as
paper or rags, in the engine compartment.

Do not smoke, cause sparks or allow open flames
around fuel or the battery. Their fumes are
flammable.

Do not get under your vehicle with just the body jack
supporting it. Always use automotive jack stands or
other solid supports.

Use eye protection whenever you work on or under
your vehicle where you may be exposed to flying or
falling material, fluid spray, etc.

Be extremely cautious when working on the battery.
It contains poisonous and corrosive sulfuric acid.

INTRODUCTION
548
NOTICE

Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally causing a short circuit.

Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.

Do not drive with the air cleaner removed, or excessive engine wear could result. Also backfiringcould cause a fire in the engine compartment.

Do not overfill automatic transmission fluid andpower steering fluid, or the transmission and powersteering could be damaged.

Be careful not to scratch the glass surface with thewiper frame.

INTRODUCTION
549
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do-it-yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):

Toyota Genuine Motor Oilº or equivalent
See page 566 for details about engine oil selection.
Tools:

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

Toyota Super Long Life Coolantº or similar high quality
ethylene glycol based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life hybrid organic acid
technology (Coolant with long-life hybrid organic acid
technology is a combination of low phosphates and organic
acids.)
Toyota Super Long Life Coolantº is a mixture of 50% coolant
and 50% deionized water (for the U.S.A.) or 55% coolant
and 45% deionized water (for Canada). This coolant
provides protection down to about -35C (-31F).
Tools:

Funnel (only for adding coolant)

SECTION 6 ± 2
552
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications553
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 557
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 560
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 560
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . .
Used engine oil 561
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine oil level 562
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 567
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Checking the radiator and condenser 569
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Spark plugs 570
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ENGINE
553
SPECIFICATIONS
Ð GENERALModel
2UZ-FE
Type8 cylinder V Type, 4 cycle, gasoline
Bore and stroke94.0
84.0 mm (3.70
3.31 in.)
Displacement4664 cm3 (284.6 cu. in.)
Valve clearance (engine cold)
Intake
Exhaust0.15 Ð 0.25 mm (0.006 Ð 0.010 in.)
0.25 Ð 0.35 mm (0.010 Ð 0.014 in.)
Drive belt tensionAutomatic adjustment

62Z002
Outside temperature
ENGINE
554Ð LUBRICATION SYSTEM
Oil capacity Drain and refillwith filter
without filter
6.2 L (6.5 qt., 5.5 lmp. qt.)
5.7 L (6.0 qt., 5.0 lmp. qt.)
Oil gradeAPI grade SL Energy-Conservingº or ILSAC multigrade engine oil
Recommended oil viscosity (SAE):
NOTE:
Toyota Genuine Motor Oilº is used in your Lexus vehicle. Use Lexus ap\
proved Toyota Genuine Motor Oilº or equivalent to satis fy
the above grade and viscosity. Please contact your Lexus dealer for further details.

ENGINE
555
Ð COOLING SYSTEM
Capacity
12.9 L (13.6 qt., 11.4 lmp. qt.)
Coolant typeToyota Super Long Life Coolantº or similar high quality
ethylene glycol based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life hybrid organic acid
technology (Coolant with long-life hybrid organic acid
technology is a combination of low phosphates and organic
acids.)
Do not use plain water alone.
NOTE:
Toyota Super Long Life Coolantº is used in your Lexus vehicle at facto\
ry fill. In order to avoid technical problems, only use Toyota
Super Long Life Coolantº or similar high quality ethylene glycol base\
d non-silicate, non-amine, non-nitrite, and non-borate coo lant
with long-life hybrid organic acid technology. (Coolant with long-life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Please contact your Lexus dealer for fu\
rther details.
Ð FUEL
Fuel type
Only UNLEADED
Octane rating87 (Research octane number 91) or higher
