ELECTRICAL COMPONENTS
621

Driver's side instrument panel

Good
Blown
If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge type fuses. If any of the cartridge type fuses are
blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses
are designed to blow before the entire wiring harness is
damaged.
NOTICE
Before replacing the fuses, have the cause of electrical overload determined and repaired by your Lexus dealer.

ELECTRICAL COMPONENTS
624The inside of the lens of exterior lights such as headlights may
temporarily
fog up when the lens becomes wet in the rain or in
a car wash. This is not a problem because the fogging is
caused by the temperature difference between the outside and
inside of the lens, just like the windshield fogs up in the rain.
However, if there is a large drop of water on the inside of the
lens, or if there is water pooled inside the light, contact your
Lexus dealer. LIGHT LOCATION

ELECTRICAL COMPONENTS
625
Light Bulbs Bulb No. W Type
1Headlights (High beam) 9005 60 A
2Headlights (Low beam) -- 55 B
3Front side marker lights 168 5 C
4Front turn signal lights 4157NAK 27/8 D
5Parking lights168 5 C
6Fog lights -- 55 E
