change time Lexus GX470 2004 Audio System / LEXUS 2004 GX470 FROM AUG. 2004 THROUGH SEP. 2004 PROD. (OM60B55U) Owner's Guide

STARTING AND DRIVING
427
VSC TRACº warning light
If there is any abnormality in the system, the VSC TRACº
warning light will come on. When the DACº switch is
pushed, the downhill assist control system indicator light
also flash.
If the VSC TRACº warning light comes on, there may be an
abnormality in any of the following systems in addition to the
downhill assist control system.
Hill-start assist control system
 Active traction control system
 Vehicle stability control system
When the system is normal and the ignition key is turned to
ONº, the warning light will come on and will go off after a few
seconds. It is not a malfunction that the warning light may stay
on for 60 seconds after the ignition key is turned to the ONº
position. Depressing the brake pedal repeatedly may turn on the light.
It is normal if it goes out after a few seconds.
The brake actuator temperature increases during continuous
operation of the above mentioned system on such as slippery
roads. If the brake actuator temperature becomes too high
while any of the systems is operating, a buzzer will start to
sound intermittently to indicate that the downhill assist control
system can no longer operate. In this case, stop your vehicle
immediately at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At this time, the VSC TRACº
warning light will come on and the downhill assist control
system stops operating temporarily in order to protect the
brake actuator. (Although the downhill assist control system
does
not operate, it is no problem to continue your driving.) The
system w ill be automatically restored after a short time and the
VSC TRACº warning light goes out.
If the warning light comes on while driving, the system does not
work. However, as normal braking operates when being
applied, it is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to ONº.
 The warning light remains on after the ignition key is turned
to ONº.
 The warning light comes on while driving.

STARTING AND DRIVING
430Depressing the brake pedal repeatedly may turn on the light.
It is normal if it goes out after a few seconds.
The brake actuator temperature increases during continuous
operation of the above mentioned system on such as slippery
roads. If the brake actuator temperature becomes too high
while any of the systems is operating, a buzzer will start to
sound intermittently to indicate that the hill-start assist control
system can no longer operate. In this case, stop your vehicle
immediately at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At this time, the VSC TRACº
warning light will come on and the hill-start assist control
system stops operating temporarily in order to protect the
brake actuator. (Although the hill-start assist control system
does
not operate, it is no problem to continue your driving.) The
system w ill be automatically restored after a short time and the
VSC TRACº warning light goes out.
If the warning light comes on while driving, the system does not
work. However, as normal braking operates when being
applied, it is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to ONº.
 The warning light remains on after the ignition key is turned
to ONº.
 The warning light comes on while driving.
BRAKE SYSTEM
This brake system has 2 independent hydraulic circuits. If
either circuit should fail, the other will still work. However, the
pedal will be harder to press, and your stopping distance will
increase. Also, the brake system warning light may come on.
CAUTION
Do not drive your vehicle with only a single brake
system. Have your brakes fixed immediately.
Brake booster
The brake booster uses brake fluid pressurized by the pump
to power-assist the brakes. If the brake booster fails during
driving, the brake system warning light comes on and buzzer
sounds continuously. In this case, the brakes may not work
properly. If they do not work well, depress the brake pedal
firmly. If the brake system warning light comes on, immediately
stop your vehicle and contact your Lexus dealer.
The brake system warning light may stay on for about 60
seconds after the ignition key is turned to the ONº position. It
is normal if the light turns off after a while.
Depressing the brake pedal repeatedly may turn on the brake
system warning light and buzzer. It is normal if the light goes
out and the buzzer stops sounding after a few seconds.

STARTING AND DRIVING
443
Selector switch

1Main position22nd position
The selector switch is located in the lower part of the
driver's side instrument panel.
The ID code is given in the sensor. To activate the air
pressure warning system, it is necessary to register the ID
code of the sensor on the selector switch in the vehicle.2 sets of ID codes can be registered. The code of the tires
originally installed on the vehicle is registered on the switch at
MAINº. Have a new tires set with new air pressure sensors
registered at 2ndº by Lexus dealer.
ID codes should be registered by Lexus dealer. Once
registered,
change the setting position each time you purchase
tires and wheels. Re-registration is not required.
When purchasing new tires, consult your Lexus dealer.

IN CASE OF AN EMERGENCY
525
Memo record

1RECº button2PLAYº button
3- VOL +º button
During a service call, you can record a conversation with the
Lexus Link Call Center Advisor. This function is very
convenient for drivers so they do not have to take notes while
driving.
RECº button: Push this button to record information or a
conversation with Lexus Link Call Center. To stop recording,
push the button again. Up to 5 minutes of recording time is
available.
When you push the RECº button, all previous messages are
deleted and the system begins recording your new message.At the start of recording, Recordingº will be announced. At the
end of recording, you will hear Recording completeº. If there
are only 15 seconds left for recording, two chimes sound. If the
recording memory is full, Recording time exceededº will be
announced and recording will be terminated.
If you push this button while you are hearing a playback of
recording, it terminates the playback and recording will start.
At this time, the previous recording will be erased.
PLAYº button:
Push this button to play the recorded
conversation. Playback completeº is announced when the
playback is complete. To stop the operation, push the button
again. Playback cancelledº is announced. The volume has
a total of eight positions/levels available.
- VOL +º button: Push this button on either side to adjust the
volume. When you change the volume, one chime sounds.

ENGINE
561
The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed by high-speed driving and frequent
acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston rings
and cylinder walls have not become conditioned.
Oil consumption:
Max. 1.0 L per 1000 km (1.1 qt./600 miles,
0.9 lmp. qt./600 miles)
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has not
changed.
The diluting ingredients evaporate out when the vehicle is then
driven at high speeds, as on an expressway, making it appear
that oil is excessively consumed after driving at high speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends that
the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil.
For detailed information on oil level check, see Checking the
engine oil levelº described below.USED ENGINE OIL
