STARTING AND DRIVING
374
PARKING BRAKE
To set: Pull up the lever. For better holding power, first
depress the brake pedal and hold it while setting the
parking brake.
To release: Pull up the lever slightly (
1), press the lock
release button (2), and lower the lever (3).
Before leaving your vehicle, firmly apply the parking brake. For
better holding power, first depress the brake pedal and hold it
while setting the parking brake.
CAUTION
Before driving, make sure the parking brake is fully
released and that the parking brake reminder light is off.
HOW TO START THE ENGINE
Cranking hold function
Once you turn the ignition key to STARTº position and release
it, the cranking hold function continues to crank the engine in
ONº position until it starts.
The function stops cranking the engine after about 25 seconds
maximum if the engine has not started yet. When you crank
the engine again, wait a few seconds and restart it.
If you hold the key in STARTº position, the function will keep
cranking for about 30 seconds maximum.
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in Pº. If you need to restart the engine
while the vehicle is moving, put the selector lever in Nº. A
starter safety device will prevent the starter from operating if
the selector lever is in any drive position.
4. Depress the brake pedal and hold it to the floor until driving
off.

STARTING AND DRIVING
375
Starting the engine
Before starting the engine, be sure to follow the instructions in
Before crankingº.
Normal starting procedure
The multiport fuel injection system/sequential multiport fuel
injection system in your engine automatically controls the
proper air-fuel mixture for starting. You can start a cold or hot
engine as follows:
With your foot off the accelerator pedal, turn the ignition key to
STARTº position, then release it.Engine should be warmed up by driving, not in idle. For
warming up, drive with smoothly turning engine until engine
coolant temperature is within normal range.
If the engine stalls...
Simply restart it, using the correct procedure given in normal
starting.
If the engine will not start...
See If your vehicle will not startº on page 462.
NOTICE
Do not race a cold engine.
If the engine becomes difficult to start or stalls
frequently, have the engine checked immediately.

STARTING AND DRIVING
376
AUTOMATIC TRANSMISSION
Your automatic transmission has a shift lock system to
minimize the possibility of incorrect operation. This
means you can only shift out of Pº position when the
brake pedal is depressed with the ignition switch in ONº
position. ()
31PY039

The shift position is displayed beside the selector lever
and on the instrument cluster.
P:Parking, engine starting and key removal position
R:Reverse position
N:Neutral position
D:Normal driving position (Shifting into overdrive possible)
4:Position for engine braking (Shifting into overdrive not
possible)
When the cruise control is being used, even if you
downshift from Dº to 4º, engine braking will not be
enabled because the cruise control is not cancelled. For
the operation to decrease the vehicle speed, see page
394.
3, 2:Position for more powerful engine braking
L:Position for maximum engine braking

STARTING AND DRIVING
377 Correct use of the automatic transmission is explained in
the following parts.
(a) Normal driving
(b) Using engine braking
(c) Using the 3º, 2º and Lº positions
(d) Backing up
(e) Parking
(f) Good driving practice
(g) If you cannot shift the selector lever
(h) Driving in second start mode
(a) Normal driving

1Pº (Park) position2Nº (Neutral) position
1. Start the engine as instructed in How to start the
engineº on page 374.
The transmission must be in Pº or Nº. The engine will not start
in any drive position even if the ignition key is turned to
STARTº.

STARTING AND DRIVING
378

1Brake pedal2Dº (Drive) position
2. With your foot holding down the brake pedal, shift the
selector lever to Dº.
Always use the Dº position to improve fuel economy and quiet
driving. Only in this position, shifting into the overdrive gear is
possible. However, while the engine coolant temperature is
low, the transmission will not shift into the overdrive gear even
in the Dº position. (See (b) Using engine brakingº and (f)
Good driving practiceº for exceptions.)
CAUTION
Never put your foot on the accelerator pedal while
shifting.
3. Release the parking brake and brake pedal. Depress
the accelerator pedal slowly for smooth starting.
In normal cruising, the vehicle will start in first gear and
automatically shift up to the most suitable gear. On inclines,
declines or winding roads, etc., the vehicle shifts up and down
automatically according to the running conditions to obtain the
suitable driving power and engine braking.
When the lever is in the 4º position, the automatic
transmission system will select the most suitable gear for the
running conditions such as hill climbing, hard towing, etc.
If you need to accelerate rapidly while driving, depress the
accelerator pedal to the full throttle position. This provides
more acceleration by automatically downshifting the
transmission to the next lower gear or beyond, depending on
the vehicle speed.
If engine braking is needed, such as in descending a long hill,
see (b) Using engine brakingº.

STARTING AND DRIVING
379
(b) Using engine braking
To use the braking power of the engine, downshift the
transmission in the way described below:
1Shift into the 4º position. The transmission will downshift
to fourth gear and engine braking will be enabled.
When the cruise control is being used, even if you
downshift from Dº to 4º, engine braking will not be
enabled because the cruise control is not cancelled. If
you need to decrease the vehicle speed, see page 394.
2Shift into the 3º position. The transmission will downshift
to third gear when the vehicle speed is or becomes lower
than the speed listed below and stronger engine braking
will be enabled.
Transfer Hº 133 km/h (83 mph)
Lº 52 km/h (32 mph)
3Shift into the 2º position. The transmission will downshift
to second gear when the vehicle speed is or becomes
lower than the speed listed below and more powerful
engine braking than that of 3º position will be enabled.
Transfer Hº 90 km/h (56 mph)
Lº 35 km/h (22 mph)
4Shift into the Lº position. The transmission will downshift
to first gear when the vehicle speed is or becomes lower
than the speed listed below and maximum engine braking
will be enabled.
Transfer Hº 47 km/h (29 mph)
Lº 18 km/h (11 mph)
CAUTION
Be careful when downshifting on a slippery surface.
The abrupt change in engine speed could cause the
vehicle to spin or skid.

STARTING AND DRIVING
380
(c) Using the 3º, 2º and Lº positions
The 3º, 2º and Lº positions are used for strong engine braking
as described previously.
With the selector lever in 3º, 2º or Lº, you can start the vehicle
in motion as with the lever in Dº.
With the selector lever in 3º or 2º, the vehicle will start in first
gear and automatically shift to second gear.
With the selector lever in Lº, the transmission is engaged in
first gear.
NOTICE
Be careful not to over-rev the engine. Watch the
tachometer to keep engine rpm from going into the
red zone. The approximate maximum allowable
speed for each position is given below for your
reference:
Transmission Transfer
Lº Hº
3º 53 km/h (33 mph) 136 km/h (85 mph)
2º 36 km/h (22 mph) 93 km/h (58 mph)
Lº 21 km/h (13 mph) 54 km/h (33 mph)
Do not continue hill climbing or hard towing for a long
time in the 3º, 2º or Lº position. This may cause
severe automatic transmission damage from
overheating. To prevent such damage, 4º position
should be used in hill climbing or hard towing.

STARTING AND DRIVING
381
(d) Backing up

1Brake pedal2Rº (Reverse) position
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the
selector lever to the Rº position.
NOTICE
Never shift into reverse while the vehicle is moving.
When the shift lever is shifted into Rº position, the outside rear
view mirrors automatically down to help backing up. For
details, see page 213.
Vehicles with rear view monitor system Ð
When the selector lever is shifted into Rº position with the
ignition switch in the ONº position, rear view monitor system
will activate. For instructions, see Rear view monitor systemº
on page 388.

STARTING AND DRIVING
382
(e) Parking

1Brake pedal
2Parking brake lever
3Pº (Park) position
1. Bring the vehicle to a complete stop.
2. Apply the parking brake fully.
3. With the brake pedal held down with your foot, shift the
selector lever to the Pº position.
CAUTION
While the vehicle is moving, never attempt to move the
selector lever into Pº under any circumstances.
Serious mechanical damage and loss of vehicle control
may result.
(f) Good driving practice
If the transmission repeatedly shifts up and down between
the fourth and overdrive gears when climbing a gentle slope,
shift the selector lever to the 4º position. Be sure to shift the
selector lever to the Dº position after climbing the slope.

STARTING AND DRIVING
383 When towing a trailer, in order to maintain efficient engine
braking and electrical charging performance, do not use
overdrive.
CAUTION
Always keep your foot on the brake pedal while stopped
with the engine running. This prevents the vehicle from
creeping.
NOTICE
Always use the brake pedal or parking brake to hold the
vehicle on an upgrade. Do not attempt to hold the
vehicle using the accelerator pedal, as this can cause
the transmission to overheat.
