STARTING AND DRIVING
376
(b) Shifting procedure
To shift between unlock and lock modes in Hº, push the
center differential lock button.
To shift between unlock and lock modes in Lº, push the
center differential lock button.
To shift between Hº and Lº, stop the vehicle, put the
transmission into Nº and move the four-wheel drive control
lever.CAUTION
Never move the four-wheel drive control lever if wheels
are slipping. Stop the slipping or spinning before
shifting.
NOTICE
For normal driving on dry and hard surface roads,
unlock the center differential. To prevent damage to the
center differential lock system, do not push the center
differential lock button when the vehicle is cornering or
when its wheels are spinning freely off the ground. If the
indicator light does not go off when unlocking the
center differential, drive straight ahead while
accelerating or decelerating, or drive in reverse.

STARTING AND DRIVING
381
NOTICE
Use the LOº mode when the vehicle is stopped.
Otherwise, when the vehicle speed exceeds about 12
km/h (7 mph), Nº mode is selected automatically. So
be careful when you drive in any place where the
overhead height is limited.
(b) Vehicle height mode changing condition
To change the vehicle height, it is necessary to meet the
following conditions.
The engine should be running.
The height control OFFº indicator light should go off.When selecting a mode, there is a vehicle speed limit. Refer
to the following table.
Yes = The mode can be selected.
No = The mode cannot be selected.
LOº
modeNº
modeHIº
mode
Under about
12 km/h (7 mph)Ye sYe sYe s
Under about
30 km/h (19 mph)NoYe sYe s
About 30 km/h
(19 mph) or overNoYe sNo

STARTING AND DRIVING
382In the following cases, the rear height control suspension
will not operate.
The underbody of the vehicle has touched the surface on
bumpy roads.
The area around the rear suspension is coated with ice.
If the vehicle is moved to its usual location or the ice is removed
and the height select switch is pressed, the vehicle height
control cannot be operated. In this case, turn off and restart the
engine, then push the control switches.
(c) Vehicle height adjustment

1Higher2Lower
To change the mode, push the height select switch on
either side of º (higher) or º (lower).The height control indicator light indicates which mode is
selected. (See (e) Height control indicator lightº described
below.)
Selecting the HIº mode
Push the height select switch on the º side when the vehicle
speed is under about 30 km/h (19 mph).
To change the Nº mode to HIº: Push the switch once.
To change the LOº mode to HIº: Push the switch twice. It
takes about 30 seconds until the LOº mode changes to the HIº
mode.
Selecting the Nº mode
To change the HIº mode to Nº: Push the height select
switch on the º side once.
To change the LOº mode to Nº: Push the height select
switch on the º side once.
Selecting the LOº mode
Push the height select switch on the º side while the vehicle
is stopped.
To change the Nº mode to LOº: Push the switch once.
To change the HIº mode to LOº: Push the switch twice.
Even if the engine is stopped while the vehicle height is being
lowered, the operation continues for up to 25 seconds. If within
this 25 seconds, any of the side doors or the back door is
opened, operation will continue for a further 15 seconds.

STARTING AND DRIVING
383
NOTICE
If the vehicle height is changed frequently when the
vehicle is heavily loaded, the compressor may
overheat causing the vehicle height adjustment
operation to stop.
Before you lower the vehicle height with the height
select switch, check under the vehicle to make sure
nothing to damage the vehicle or no one to be injured
is there and that the underbody of the vehicle does
not touch the ground.
After unloading, the height of a vehicle equipped with
the rear height control air suspension becomes
slightly higher than the normal vehicle height. Take
sufficient care where the overhead height is
restricted.
Do not select the LOº mode in the bumpy roads. If
the underbody of the vehicle touches the rugged
road surface, the vehicle may be damaged.

STARTING AND DRIVING
384
(d) Turning off the rear height control air
suspension
To turn off the rear height control air suspension with the
vehicle stopped, push the HEIGHT CONTROL OFFº
switch. The height control OFFº indicator light comes on
and the vehicle height is fixed in the same mode as the
height control switch is pushed.
This status is memorized in the system even after the engine
is stopped.
If you push the switch again, the height control OFFº indicator
light goes out and the rear height control air suspension is
turned on.
Even after the rear height control air suspension is turned off
with the HEIGHT CONTROL OFFº switch, if the vehicle speed
exceeds 30 km/h (19 mph), the rear height control air
suspension automatically selects the Nº mode.
CAUTION
If you drive through deep water over about 700 mm (28
in.) in depth, put the vehicle height in the HIº mode with
the height select switch and then turn off the rear height
control air suspension by pushing the HEIGHT
CONTROL OFFº switch.

STARTING AND DRIVING
385
NOTICE
When jacking up or installing tire chains, be sure to
turn off the rear height control air suspension with
the HEIGHT CONTROL OFFº switch and stop the
engine. Otherwise, the vehicle height may change
because of the automatic leveling function resulting
in accident.
If your vehicle must be towed, put the vehicle height
in the Nº mode and turn off the rear height control air
suspension. Otherwise, the vehicle height may
change because of the automatic leveling function
resulting in accident.
If your vehicle gets ditched, turn off the rear height
control air suspension with the HEIGHT CONTROL
OFFº switch. Otherwise, the vehicle height may
change because of the automatic leveling function
resulting in accident.

STARTING AND DRIVING
387
(f) Parking and stopping tips
If you immediately stop the engine to park the vehicle after
off-road driving, the vehicle height is lowered slightly as the
vehicle becomes cool. When parking, make sure there is
nothing that will be in contact with the underbody of the vehicle.
When you start the engine, the vehicle returns to the previous
height.
If you park the vehicle for a long time, the vehicle height may
be gradually lowered. When parking for a long time, make sure
there is nothing that will be in contact with the underbody of the
vehicle. When you start the engine, the vehicle returns to the
previous height.
If you stop the engine, the vehicle height may change in
accordance with the change in the temperature. When you
start the engine, the vehicle returns to the previous height.
(g) Rear height control failure warning
If there is a problem somewhere in the rear height control air
suspension, the Nº mode is automatically selected. If this
occurs, the height control OFFº indicator light blinks and the
vehicle height control cannot be activated until the malfunction
is corrected. If this is the case, bring your vehicle to your Lexus
dealer as soon as possible and have it checked.
ELECTRONIC MODULATED
SUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1For driving on a bumpy road
2For ordinary driving such as in the city traffic
3For moderate high speed driving
4For sporty type driving such as on winding mountain
roads and high speed driving
5Soft
6Firm
We recommend you to select the mode 2
for ordinary
driving. The damping effect will be changed automatically to
provide good riding comfort.

STARTING AND DRIVING
390Depressing the brake pedal repeatedly may turn on the light.
It is normal if it goes out after a few seconds.
The brake actuator temperature increases during continuous
operation of the above mentioned systems such as on slippery
roads. If the brake actuator temperature becomes too high
while any of the systems is operating, a buzzer will start to
sound intermittently to indicate that the active traction control
system can no longer operate. In this case, immediately stop
your vehicle at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At the time, the VSC TRACº
warning light will come on and the active traction control
system temporarily stops operating in order to protect the
brake actuator. (Although the active traction control system
does not operate, there is no problem to continue your driving.)
The system will be automatically restored after a short time and
the VSC TRACº warning light goes out.
If the light comes on while driving, the active traction control
system does not work. However, as normal braking operates
when being applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
VEHICLE STABILITY CONTROL
SYSTEM
The vehicle stability control system helps provide
integrated control of the systems such as anti-lock brake
system, traction control, engine control, etc. This system
automatically controls the output of the brakes or engine
to help prevent the vehicle from skidding when cornering
on a slippery road surface or operating steering wheel
abruptly.
The system activates when the vehicle speed about more than
15 km/h (9mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the system is in the
self-check mode, but does not indicate a malfunction.
CAUTION
Do not rely excessively on the vehicle stability
control system. Even if the vehicle stability control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks and an alarm sounds,
special care should be taken while driving.

STARTING AND DRIVING
394If the indicator light does not come on when the switch is
pushed, contact your Lexus dealer.

Slip indicator light
With the vehicle traveling at a speed of 25 km/h (15 mph) or
less, release your foot from the accelerator or brake pedal to
activate the system. The vehicle will descend the hill at a low
speed. While the system is operating, the slip indicator light on
the instrument panel will flash and the stop lights and high
mounted stoplight will be lit.
If you push the DACº switch to turn the system off while it is
in operation, the system will stop operating gradually. The
downhill assist control system indicator light will flash to alert
the driver. To continue driving at a low speed, push the DACº
switch to turn the system on.
The slip indicator light and downhill assist control system
indicator light come on for a few seconds when the ignition key
is turned to ONº. If any of the indicator lights does not come
on when the ignition is turned on, contact your Lexus dealer.If the system is used frequently, the brake actuator
temperature may become too high and a buzzer will sound
intermittently.
If this happens, the downhill assist control system indicator
light will flash and a buzzer will sound intermittently. When the
temperature of the brake actuator goes down, the system will
begin to operate again. Until it restarts, the active traction
control system and hill-start assist control system will not
operate; however, the conventional brake can be operated.

STARTING AND DRIVING
395
VSC TRACº warning light
If there is any abnormality in the system, the VSC TRACº
warning light will come on. When the DACº switch is
pushed, the downhill assist control system indicator light
also flash.
If the VSC TRACº warning light comes on, there may be an
abnormality in any of the following systems in addition to the
downhill assist control system.
Hill-start assist control system
Active traction control system
Vehicle stability control system
When the system is normal and the ignition key is turned to
ONº, the warning light will come on and will go off after a few
seconds. It is not a malfunction that the warning light may stay
on for 60 seconds after the ignition key is turned to the ONº
position.Depressing the brake pedal repeatedly may turn on the light.
It is normal if it goes out after a few seconds.
The brake actuator temperature increases during continuous
operation of the above mentioned system on such as slippery
roads. If the brake actuator temperature becomes too high
while any of the systems is operating, a buzzer will start to
sound intermittently to indicate that the downhill assist control
system can no longer operate. In this case, stop your vehicle
immediately at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At this time, the VSC TRACº
warning light will come on and the downhill assist control
system stops operating temporarily in order to protect the
brake actuator. (Although the downhill assist control system
does not operate, it is no problem to continue your driving.) The
system will be automatically restored after a short time and the
VSC TRACº warning light goes out.
If the warning light comes on while driving, the system does not
work. However, as normal braking operates when being
applied, it is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
