audio Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM AUG. 2004 THROUGH SEP. 2004 PROD. OWNER'S MANUAL (OM60B55U)

AUDIO
380

Low quality discs
Labeled discs

AUDIO
381
NOTICE
Do not use special shaped, transparent/translucent, lowquality or labeled discs such as those shown in theillustrations. The use of such discs may damage theplayer or changer, or it may be impossible to eject thedisc.

AUDIO
382

Correct
Wrong
Handle compact discs carefully, especially when you are
inserting them. Hold them on the edge and do not bend
them. Avoid getting fingerprints on them, particularly on the
shiny side.
 Dirt, scratches, warping, pin holes, or other disc damage
could cause the player to skip or to repeat a section of a
track. (To see a pin hole, hold the disc up to the light.)
 Remove discs from the compact disc player when you are
not listening to them. Store them in their plastic cases away
from moisture, heat, and direct sunlight.
To clean a compact disc: Wipe it with a soft, lint-free cloth
that has been dampened with water. Wipe in a straight line
from the center to the edge of the disc (not in circles). Dry it with
another soft, lint-free cloth. Do not use a conventional record
cleaner or anti-static device.

IN CASE OF AN EMERGENCY
526
Audible voice prompts
The following table shows the voice responses from the Lexus Link System\
.Voice phrase: Explanation about Lexus Link System
This is the Lexus Link system. Integrating
global positioning satellite and wireless
communication technology into your
Lexus and providing enhanced safety,
security, and convenience. At the touch of
a button, or automatically in the event of
an accident, you are connected to a Lexus
Link Advisor who will assist you Ð 24
hours a day, 7 days a week where GPS
and cellular coverage is available. The
Lexus Link System also has an audio
recorder allowing you to record reminders
to yourself or information from a Lexus
Link Advisor.
To contact a Lexus Link Advisor, press the
SERVICESº button. The Lexus Link
System will inform the advisor of your
vehicle's current location and your
identity. The advisors can handle a wide
variety of services, such as giving
directions to shops, gas stations, ATMs,
restaurants and roadside assistance with
location. Services available will depend
on the service package you selected.In an emergency, press the emergency
services button on your Lexus Link
console. It is marked with a red
ambulance. Upon receiving your call, the
advisor will assess the situation and, if
necessary, alert the nearest emergency
services provider. The emergency button
should only be used in life threatening
situations.
If your Lexus detects that an airbag
deployment may have occurred, the
Lexus Link System will automatically send
an emergency message to the Lexus Link
Call Center.
The system will also automatically contact
the call center if the security system alarm
goes off. An advisor will first contact you
to determine if the alarm is valid. Upon
your confirmation, the advisor will then
provide the vehicle location to the police.If you accidentally set off the alarm, press
the remote door unlock, or insert your key
in the door lock or ignition within 55
seconds. This will prevent the Lexus Link
System from placing a theft call.
The volume control lets you adjust the
volume level for Lexus Link calls, system
prompts, and memos. Pr ess the plus key
to increase volume and the minus key to
decrease it.
To record a memo or a call, press the key
labeled RECº. When you are finished
recording, press the RECº button again.
To listen to the memo, press the PLAYº
button. You can record one message up
to five minutes long. When you record a
new memo, all of the previous memos will
be erased.
For more detailed information on the use,
features and limitations of this system,
please consult your Lexus Link Owner's
Manual.

ELECTRICAL COMPONENTS
608
25AIRSUSNO.210Rear height control air
suspension
26SEAT
HEATER20Seat heaters
27DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi- information display
28RADIO NO.120Audio system, navigation
system
No.FUSEAMPERECIRCUIT
29ECU-B10
Multiplex communication
system, vehicle stability control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof, rear view
monitor system
30ECU-B NO.210Theft deterrent system
31ABS
MTR40
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
32AM230Starting system, all components
in IGNº, SRSº, GAUGEº and
ST2º fuses

ELECTRICAL COMPONENTS
609
33ABSSOL50
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
No.FUSEAMPERECIRCUIT
34ALT-S7.5Charging system
35MAYDAY7.5Lexus Link System
36HORN10Horns
37TRN-HAZ15Turn signal lights
38ETCS10Electronic throttle control system
39EFI20Multiport fuel injection
system/sequential multiport fuel
injection system
40D FR P/W20Power window
41DR/LCK25Power door lock
42TOWING30Towing converter
43RADIO NO.230Audio system, navigation
system
44IGN10
Multiport fuel injection
system/sequential multiport fuel
injection system, vehicle
stability control system
45SRS10SRS airbag system
46GAUGE7.5Gauges and meters
47ST27.5Multiport fuel injection
system/sequential multiport fuel
injection system
No.FUSEAMPERECIRCUIT

ELECTRICAL COMPONENTS
611
58IG110
Air conditioning system, back-up
lights, rear window defogger,
seat heaters, vehicle stability
control system
59STA7.5Multiport fuel injection
system/sequential multiport fuel
injection system
60P FR P/W20Front passenger's power window
61P RR P/W20Rear right side power window
No.FUSEAMPERECIRCUIT
62D RR P/W20Rear left side power window
63PANEL10Instrument panel lights
64TAIL10Parking lights, tail lights, license
plate lights, front fog lights
65ACC7.5
Shift lock control system, power
outlets, outside rear view
mirrors, audio system, navigation
system, power rear view mirrors,
multi- information display, rear
view monitor system
66CIG10Cigarette lighter
67POWER
OR TI&TE30Power windows, moon roof, tilt
and telescopic steering

BODY
637
CLEANING THE INTERIORCAUTION
Do not wash the vehicle floor with water, or allow water
to get onto the floor when cleaning the vehicle interior
or exterior. Water may get into audio components or
other electrical components above or under the floor
carpet (or mat) and cause a malfunction; and it may
cause body corrosion.
Leather Interior
Remove dirt using a soft cloth dampened with 5% solution of
neutral detergent for wool. Then thoroughly wipe off all traces
of detergent with a clean damp cloth.
After cleaning or whenever any part of the leather gets wet, dry
with a soft clean cloth. Allow the leather to dry in a ventilated
shaded area.

BODY
642
Air Conditioning Control Panel, Audio Panel,
Instrument Panel, Console Panel and
SwitchesUse a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then lightly
wipe off any dirt.
NOTICE

Do not use organic substances (solvents, kerosene,alcohol, gasoline, etc.) or alkaline or acidic solutions.
These chemicals can cause discoloring, staining or peeling of the surface.

If you use cleaners or polishing agents, make suretheir ingredients do not include the substancesmentioned above.

If you use a liquid car freshener, do not spill the liquidonto the vehicle's interior surfaces. It may containthe ingredients mentioned above. Immediately cleanany spill using the method mentioned above.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to answer
them.RAIN CLEARING MIRRORS
The rear view mirrors have been coated to produce a rain
clearingº effect. This coating causes the raindrops to
spread, clearing the driver's rear view when it rains.
It is sufficient to wash the mirrors with water for day to day care.
The rain clearing effect is reduced in drizzle and light rain.
In the following cases, the rain clearing effect will be reduced
temporarily, but will gradually recover.

After wiping dirt off the mirrors

When the mirrors fog up
