AUDIO
369
Region codes:
Region codes are provided on DVD players
and DVD discs. If the DVD video disc does not have the same
region code as the DVD player, you cannot play the disc on the
DVD player. For region codes, see page 367.
Audio: This DVD player can play liner PCM, Dolby digital, dts
and MPEG audio format DVD. Other decoded type cannot be
played.
Title and chapter: Video and audio programs stored on DVD
video discs are divided in parts by title and chapter.
Title: The largest unit of the video and audio programs stored
on DVD video discs. Usually, one piece of a movie, one album,
or one audio program is assigned as a title.
Chapter: A unit smaller than a title. A title comprises plural
chapters. Manufactured under license from Dolby Laboratories.
Dolbyº, Pro Logicº, and
º are trademarks of Dolby
Laboratories. Confidential unpublished works.
1992 Ð 1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use
of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
dtsº is a trademark of Digital Theater Systems, Inc.

CHASSIS
589
Glossary of tire terminology
Tire related termMeaning
Accessory weightthe combined weight (in excess of those standard items which may be rep\
laced)
of automatic transmission, power steering, power brakes, power windows, \
power
seats, radio, and heater, to the extent that these items are available as
factory-installed equipment (whether installed or not)
Cold tire inflation
pressuretire inflation pressure when the vehicle has been parked for at least 3 \
hours or
more, or it has not been driven more than 1.5 km or 1 mile under that co\
ndition
Curb weightthe weight of a motor vehicle with standard equipment including the maxi\
mum
capacity of fuel, oil, and coolant, and, if so equipped, air conditionin\
g and
additional weight optional engine
Intended outboard
sidewall(a) the sidewall that contains a whitewall, bears white lettering or bearsmanufacturer, brand, and/or model name molding that is higher or deeper
than the same molding on the other sidewall of the tire, or
(b) the outward facing sidewall of an asymmetrical tire that has a particula\
r side that must always face outward when mounted on a vehicle
Maximum inflation
pressurethe maximum cold inflation pressure to which a tire may be inflated and \
it is
shown on the sidewall of the tire
Maximum loaded
vehicle weightthe sum of Ð
(a) curb weight;
(b) accessory weight;
(c) vehicle capacity weight; and
(d) production options weight
Normal occupant
weight68 kg (150 lb.) times the number of occupants specified in the second \
column of
Table 1 that follows

ELECTRICAL COMPONENTS
606
No.FUSEAMPERECIRCUIT
1SPARE10Spare fuse
2ALT140
Charging system and all
components in AM1º,
HEATERº, CDS FANº, FR
FOGº, DEFOGº, AIR SUSº,
AC115V INVº, SEAT HEATERº,
BATT CHGº, TOWING BRKº
and TOWINGº fuses
3SPARE15Spare fuse
4HEATER50Air conditioning system
5AIR
SUS50Rear height control air
suspension
6AM150
All components in ACCº, CIGº,
IG1º, FR WIP-WSHº, RR
WIPº, RR WSHº, DIFFº,
TEMSº and STAº fuses
7TOWING BRK30Trailer brake controller
8J/B50
All components in P FR P/Wº,
P RR P/Wº, D RR P/Wº, D
P/SEATº, P P/SEATº, TAILº,
PANELº and POWER OR
TI&TEº fuses
9BATTCHG30Trailer sub battery
10TOWING40Trailer lights
No.FUSEAMPERECIRCUIT
11CDS FAN20Electric cooling fan
12RR A/C30Rear air conditioning system

ELECTRICAL COMPONENTS
607
13MIR
HEATER10Outside rear view mirror
defogger
14STOP10
Stop lights, high m ounted
stoplight, shift lock control
system, vehicle stability control
system, electronic m odulated
suspension, rear height control
air suspension, multiport fuel
injection system/sequential
multiport fuel injection system
15AC115V
INV15Power outlet (115 VAC)
16FR FOG15Front fog lights
17OBD7.5On- board diagnosis system
18HEAD
(LO RH)10Right-hand headlight (low beam)
19HEAD
(LO LH)10Left-hand headlight (low beam)
No.FUSEAMPERECIRCUIT
20HEAD
(HI RH)10Right-hand headlight (high
beam)
21HEAD
(HI LH)10Left-hand headlight (high beam)
22EFI NO.210Multiport fuel injection
system/sequential multiport fuel
injection system
23HEATER NO.27.5Air conditioning system
24DEFOG30Rear window defogger

ELECTRICAL COMPONENTS
608
25AIRSUSNO.210Rear height control air
suspension
26SEAT
HEATER20Seat heaters
27DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi- information display
28RADIO NO.120Audio system, navigation
system
No.FUSEAMPERECIRCUIT
29ECU-B10
Multiplex communication
system, vehicle stability control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof, rear view
monitor system
30ECU-B NO.210Theft deterrent system
31ABS
MTR40
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
32AM230Starting system, all components
in IGNº, SRSº, GAUGEº and
ST2º fuses

ELECTRICAL COMPONENTS
611
58IG110
Air conditioning system, back-up
lights, rear window defogger,
seat heaters, vehicle stability
control system
59STA7.5Multiport fuel injection
system/sequential multiport fuel
injection system
60P FR P/W20Front passenger's power window
61P RR P/W20Rear right side power window
No.FUSEAMPERECIRCUIT
62D RR P/W20Rear left side power window
63PANEL10Instrument panel lights
64TAIL10Parking lights, tail lights, license
plate lights, front fog lights
65ACC7.5
Shift lock control system, power
outlets, outside rear view
mirrors, audio system, navigation
system, power rear view mirrors,
multi- information display, rear
view monitor system
66CIG10Cigarette lighter
67POWER
OR TI&TE30Power windows, moon roof, tilt
and telescopic steering

ELECTRICAL COMPONENTS
619
2. Make sure the inoperative component is turned off. Pull
the suspected fuse straight out with the pull-out tool and
check it. If it has blown, push a new fuse into the clips.
Good
Blown
a. Look carefully at the fuse. If the thin wire is broken, the fuse
has blown. If you are not sure or if it is too dark to see, try
replacing the suspected fuse with one of the same value that
you know is good.
b. Only install a fuse with the amperage rating designated on
the fuse box lid.
If you do not have a spare fuse, in an emergency you can pull
out the CIGº, RADIO NO.1º or SEAT HEATERº fuse, which
may be dispensable for normal driving, and use it if its
amperage rating is the same.
If you cannot use one of the same amperage, use one that is
lower, but as close to the rating as possible. If the amperage
is lower than that specified, the fuse might blow out again but
this does not indicate anything wrong. Be sure to get the
correct fuse as soon as possible and return the substitute to its
original clips.

BODY
641
NOTICE

Use a good foam-type shampoo to clean the carpets.

Do not use dye or bleach on the belts Ð it mayweaken them.

Do not use the belts until they become dry.

The windows may be cleaned with any household
window cleaner.

Do not apply detergent to or wet the automatic wipercontrol sensor when cleaning the inside of thewindshield.

When cleaning the inside of the quarter and rearwindows, be careful not to scratch or damage the
wire antennas, heater wires or connectors.
