tow Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM AUG. 2004 THROUGH SEP. 2004 PROD. (OM60B55U) Owner's Guide

OCCUPANT RESTRAINT SYSTEMS
147
Second and third seats
To raise the head restraint, pull it up. To lower it, press the
lock release button and push the head restraint down.
Second center head restraint: When an occupant sits on the
second center seat, always pull up the head restraint to the lock
position.
The head restraint is most effective when it is close to your
head. Therefore, using a cushion on the seatback is not
recommended.
CAUTION
 Adjust the center of the head restraint so that it is
closest to the top of your ears.
 After adjusting the head restraint, make sure it is
locked in position.
 Do not drive with the head restraints removed.
Stowing the third center head restraint
The third center head restraint can be stowed in the right
side third seatback when they are not in use.
To stow the head restraint, unfasten the zippers behind
the seatback and stow it into the seatback.

OCCUPANT RESTRAINT SYSTEMS
156
CAUTION
Do not use the third center seat belt with either buckle
release. Fastening only the shoulder belt or lap belt may
cause severe personal injury in case of sudden braking
or a collision.
STOWING THE THIRD CENTER SEAT BELT
Stow the seat belt tabs into the cover of the roof as shown
above.
Make sure the tabs are securely locked in the cover.
PULLING OUT THE THIRD CENTER SEAT BELT
Pull the belt out a little and pull the tabs out from the cover.

OCCUPANT RESTRAINT SYSTEMS
157
Stowing the second and third seat belt
buckles

Second seat

Third seat
The second and third seat belt buckles can be stowed
when they are not in use.
Hanging the third outside seat belts

Seat belt hanger
The third outside seat belts can be hung when they are not
in use.
CAUTION
The third outside seat belts must be removed from the
hangers when they are in use.

STEERING WHEEL AND MIRRORS
229
Displays
Directions
N
NE E
SE S
SW W
NWNorth
Northeast East
Southeast South
Southwest West
Northwest
The compass may not show the correct direction in the
following conditions:
 The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
 The ignition switch is turned off immediately after turning.
 The vehicle is on an inclined surface.
 The vehicle is in a place where the earth's magnetic field is
subject to interference by artificial magnetic fields
(underground parking, under a steel tower, between
buildings, roof parking, near a crossing, near a large vehicle,
etc.).
 The vehicle is magnetized. (There is a magnet or a metal
object on or near the inside rear view mirror.)
 The battery has been disconnected. If your vehicle is out of the set zone, refer to Calibrating the
compassº in this Section to set the zone number.
If the deviation is small, the compass works to calibrate the
direction automatically while the vehicle is in motion.
For additional precision or for complete calibrating, see
Calibrating the compassº below.

STEERING WHEEL AND MIRRORS
233
Perform
circling calibration just after you have purchased
your Lexus. And then always perform circling calibration
after the battery has been removed, replaced or
disconnected.
 Do not perform circling calibration of the compass in a place
where the earth's magnetic field is subject to interference by
artificial magnetic fields (underground parking, under a steel
tower, between buildings, roof parking, near a crossing,
near a large vehicle, etc.).
 During calibration, do not operate electric systems (moon
roof, power windows, etc.) as they may interfere with the
calibration.
CAUTION
When doing the circling calibration, be sure to secure
a wide space, and watch out for people and vehicles
in the neighborhood. Do not violate any local traffic
rules while performing circling calibration.
 Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
VANITY MIRRORS
To use the vanity mirrors, swing the sun visor down and
slide the cover.
The vanity light comes on when you slide the cover.

AIR CONDITIONING
245

If following another vehicle on a dusty road, or driving in
windy and dusty conditions, it is recommended that the air
intake be temporarily set to the RECIRCULATED AIR
mode, which will close off the outside passage and prevent
outside air and dust from entering the vehicle interior. Heating
For best results, set controls to:
For automatic operation Ð
Push in the AUTOº button.
Temperature Ð To the desired temperature
Air intake Ð OUTSIDE AIR
Air conditioning Ð OFF
For manual operation Ð Fan speed Ð To the desired fan speed
Temperature Ð Towards high temperature
Air intake Ð OUTSIDE AIR
Air flow Ð FLOOR
Air conditioning Ð OFF
 For quick heating, select RECIRCULATED AIR for a few
minutes. To keep the windows from fogging, select
OUTSIDE AIR after the vehicle interior has been warmed.
 Push the A/Cº button on for dehumidified heating.
 Choose floor/windshield air flow to heat the vehicle interior
while defrosting or defogging the windshield. Air conditioning
For best results, set controls to:
For automatic operation Ð
Push in the AUTOº button.
Temperature Ð To the desired temperature
Air intake Ð OUTSIDE AIR
Air conditioning Ð ON
For manual operation Ð

AIR CONDITIONING
246Fan speed Ð
To the desired fan speed
Temperature Ð Towards low temperature
Air intake Ð OUTSIDE AIR
Air flow Ð PANEL
Air conditioning Ð ON
 For quick cooling, select RECIRCULATED AIR for a few
minutes.
Ventilation For best results, set controls to:
For automatic operation Ð
Push in the AUTOº button.
Temperature Ð Towards low temperature
Air intake Ð OUTSIDE AIR
Air conditioning Ð OFF

AIR CONDITIONING
247
For manual operation Ð
Fan speed Ð To the desired fan speed
Temperature Ð Towards low temperature
Air intake Ð OUTSIDE AIR
Air flow Ð PANEL
Air conditioning Ð OFF
Defogging and defrosting
Ð The inside of the windshield For best results, set controls to:
For automatic operation Ð
Temperature Ð Towards high temperature to heat;
low temperature to cool
Air intake Ð OUTSIDE AIR
Air flow Ð WINDSHIELD
For manual operation Ð
Fan speed Ð To the desired fan speed
Temperature Ð Towards high temperature to heat;
low temperature to cool
Air intake Ð OUTSIDE AIR
Air flow Ð WINDSHIELD
When the windshield air flow button is pushed, air flows mainly
from the windshield vents and turns on the defogging function
with the purpose of clearing the front view.
Pushing this button once again returns the air flow mode to the
last one used. This
button allows the air intake to select OUTSIDE AIR mode
automatically. This is to clean up the front view more quickly.
If you want to return the setting to RECIRCULATED AIR mode,
push the air intake control button once again.
Push the A/Cº button for dehumidified heating or cooling. This
setting clears the front view more quickly.
 On humid days, do not blow cold air on the windshield Ð the
difference between the outside and inside temperatures
could make the fogging worse.
Ð The outside of the windshield

AIR CONDITIONING
248For best results, set controls to: For automatic operation Ð
Temperature Ð Towards high temperature
Air intake Ð OUTSIDE AIR
Air flow Ð WINDSHIELD
For manual operation Ð
Fan speed Ð To the desired fan speed
Temperature Ð Towards high temperature
Air intake Ð OUTSIDE AIR
Air flow Ð WINDSHIELD

AUDIO
292(c) Controller holder
The controller can be stowed in the holder when it is not
in use. The holder can be hooked on the back of the
driver's or front passenger's seatback.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop while driving, stow the controller in the
holder when it is not in use.
NOTICE
Do not leave the controller exposed to high
temperatures (such as on the instrument panel) for along time, otherwise the controller may be damaged.
