warning light Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM AUG. 2004 THROUGH SEP. 2004 PROD. OWNER'S MANUAL (OM60B55U)

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
x
Page
1Driving position memory switches219
. . . . . . . . . . .
2Power window switches 48
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 24
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 49
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 225 . . . . . .
6Side vents 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 33, 36, 37 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 37
. . . . . . . . . . . . . . . . . . . . . .
9Center vents 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 51
. . . . . . . . . . . . . . . . . . . . .
11Audio system 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 75
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 236
. . . . . . . . . .
14Rear window defogger switch 45
. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 65 . . . . . .
16Glove box 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Ashtray 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
18Cigarette lighter 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Seat heater switches 53
. . . . . . . . . . . . . . . . . . . . . . . . . .
20Four-wheel drive control lever 401
. . . . . . . . . . . . . . . Page
21Automatic transmission selector lever 393
. . . . . . . .
22Parking brake lever 391
. . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock switch 401
. . . . . . . . . . . . . . .
24Power outlet (12 VDC) 93
. . . . . . . . . . . . . . . . . . . . . . . . .
25Downhill assist control switch 425
. . . . . . . . . . . . . . .
26Electronic modulated suspension
control switch 419 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control air suspension
switches 412 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Ignition switch 389
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
292nd STRTº (second start) switch 401
. . . . . . . . . . . .
30Tire pressure warning system
selector switch 443 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31Cruise control switch 409
. . . . . . . . . . . . . . . . . . . . . . .
32Steering switches 280
. . . . . . . . . . . . . . . . . . . . . . . . . . .
33Instrument panel light control dial 86
. . . . . . . . . . . . . .
34Hood lock release lever 112
. . . . . . . . . . . . . . . . . . . . . .
35Fuel filler door opener 113
. . . . . . . . . . . . . . . . . . . . . . . .
36RSCA OFFº (roll sensing of curtain
shield airbags off) switch 193 . . . . . . . . . . . . . . . . . . . .
37Outside rear view mirror defogger switch 47 . . . . . . .
38Power outlet (115 VAC) main switch 95
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xii
Page
1Driving position memory switches219
. . . . . . . . . . .
2Power window switches 48
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 24
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 49
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 225 . . . . . .
6Side vents 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 33, 36, 37 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 37
. . . . . . . . . . . . . . . . . . . . . .
9Center vents 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 51
. . . . . . . . . . . . . . . . . . . . .
11Rear view monitor/navigation system display
(For the navigation system, see the separate Navigation System Owner's Manualº.) 405 . . . . . . .
12Multi-information display 75
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls
(See the separate Navigation System Owner's Manualº.) 236 . . . . . . . . . . . . . . . . . . . . . . . . . .
14Rear window defogger switch 45
. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 65 . . . . . .
16Glove box 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Audio system 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Ashtray 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
19Cigarette lighter 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Seat heater switches 53
. . . . . . . . . . . . . . . . . . . . . . . . . . Page
21Four-wheel drive control lever
401
. . . . . . . . . . . . . . .
22Automatic transmission selector lever 393 . . . . . . . .
23Parking brake lever 391
. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock switch 401
. . . . . . . . . . . . . . .
25Power outlet (12 VDC) 93
. . . . . . . . . . . . . . . . . . . . . . . . .
26Downhill assist control switch 425
. . . . . . . . . . . . . . .
27Electronic modulated suspension
control switch 419 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Rear height control air suspension
switches 412 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Ignition switch 389
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
302nd STRTº (second start) switch 401
. . . . . . . . . . . .
31Tire pressure warning system
selector switch 443 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Cruise control switch 409
. . . . . . . . . . . . . . . . . . . . . . .
33Speech command switch
See the separate
. . . . . . . . .
Navigation System Owner's Manualº.
34Steering switches 280
. . . . . . . . . . . . . . . . . . . . . . . . . . .
35Instrument panel light control dial 86
. . . . . . . . . . . . . .
36Hood lock release lever 112
. . . . . . . . . . . . . . . . . . . . . .
37Fuel filler door opener 113
. . . . . . . . . . . . . . . . . . . . . . . .
38RSCA OFFº (roll sensing of curtain
shield airbags off) switch 193 . . . . . . . . . . . . . . . . . . . .
39Outside rear view mirror defogger switch 47 . . . . . . .
40Power outlet (115 VAC) main switch 95
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xiv
Page
1Automatic transmission second start indicator light 401 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 68
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 73
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 393 . . . . . .
6Driver's seat belt reminder light 65
. . . . . . . . . . . . . . . .
7Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 64
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 36
. . . . . . . . . . . .
10Anti-lock brake system warning light 67
. . . . . . . . . . .
11Open door warning light 68
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 33
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 409
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 72
. . . . . . . . . .
16Slip indicator light 421, 423, 426, 428
. . . . . . . . . . . . .
17Low engine oil pressure warning light 71
. . . . . . . . . .
18Discharge warning light 70
. . . . . . . . . . . . . . . . . . . . . . . Page
19Engine coolant temperature gauge
58
. . . . . . . . . . . . .
20Malfunction indicator lamp 66
. . . . . . . . . . . . . . . . . . . .
21Vehicle stability control system off
indicator light 423 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Roll sensing of curtain shield airbags off
indicator light 193 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Kinetic dynamic suspension system
warning light 70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock indicator light 401
. . . . . . . .
25Vehicle stability control system and active
traction control system warning light 70 . . . . . . . . . . .
26Downhill assist control system
indicator light 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control indicator lights 418
. . . . . . . . . . .
28Security indicator light 14, 29
. . . . . . . . . . . . . . . . . . . .
29SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Trip meter reset knob 61
. . . . . . . . . . . . . . . . . . . . . . . . .
31Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . .
32Low fuel level warning light 72
. . . . . . . . . . . . . . . . . . . .
33Low tire pressure warning light 72
. . . . . . . . . . . . . . . .
34Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xvi
Page
1Automatic transmission second start indicator light 401 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 68
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 73
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 393 . . . . . .
6Driver's seat belt reminder light 65
. . . . . . . . . . . . . . . .
7Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 64
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 36
. . . . . . . . . . . .
10Anti-lock brake system warning light 67
. . . . . . . . . . .
11Open door warning light 68
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Tail light indicator light 33
. . . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 409
. . . . . . . . . . . . . . . .
15Slip indicator light 421, 423, 426, 428
. . . . . . . . . . . . .
16Low engine oil pressure warning light 71
. . . . . . . . . .
17Discharge warning light 70
. . . . . . . . . . . . . . . . . . . . . . .
18Engine coolant temperature gauge 58
. . . . . . . . . . . . . Page
19Malfunction indicator lamp
66
. . . . . . . . . . . . . . . . . . . .
20Vehicle stability control system off
indicator light 423 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Roll sensing of curtain shield airbags off
indicator light 193 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Kinetic dynamic suspension system
warning light 70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock indicator light 401
. . . . . . . .
24Vehicle stability control system and active
traction control system warning light 70 . . . . . . . . . . .
25Downhill assist control system
indicator light 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26Rear height control indicator lights 418
. . . . . . . . . . .
27Security indicator light 14, 29
. . . . . . . . . . . . . . . . . . . .
28SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Trip meter reset knob 61
. . . . . . . . . . . . . . . . . . . . . . . . .
30Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . .
31Low fuel level warning light 72
. . . . . . . . . . . . . . . . . . . .
32Low tire pressure warning light 72
. . . . . . . . . . . . . . . .
33Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

KEYS AND DOORS
28The back door can be locked and unlocked together with the
side doors by means of the power door lock system. (For
instructions, see Locking with power door lock switchº on
page 24.)
See Stowage precautionsº on page 475 for precautions when
loading luggage.
CAUTION

Keep the back door closed while driving. This not
only keeps the luggage from being thrown out but
also prevents exhaust gases from entering the
vehicle.
 If the open back door hides the rear stop and tail
lights or rear turn signal lights while you are parked,
other road users must be warned of the presence of
your vehicle by a warning triangle or other device.
Back door stopper

1Lock2Unlock
For your safety, lock the back door with the door stopper
when you fully open the back door.
When closing the back door, check that the back door stopper
is unlocked.
CAUTION
 When keeping the back door open, use only the lock
lever of the back door stopper without touching the
other parts.
 To avoid serious personal injury, make sure not to get
your hands caught in the back door stay when
closing the back door.

SWITCHES
38Twist the interval adjuster upward to increase the wiping
time
interval between sweeps, and downward to decrease
it.
The wiper lever must be in the INTº position.
The time interval between sweeps is shortened when the
vehicle speed increases. When the vehicle speed reaches
more than about 20 km/h (12 mph) with the interval adjuster in
the full upward position, the time interval becomes the shortest
1.5 seconds.
If you stop the vehicle with the wiper switch in the LOº position,
the wiper speed automatically changes from low speed to
intermittent operation speed.* This function does not work
when the interval adjuster is in the full upward position.
NOTE: * This feature can be deactivated. Ask your Lexus dealer for details.
To make the washer squirt, pull the lever toward you and
release it.
If the wiper lever is in the OFFº position, the wipers will
automatically make 3 wipes and then a single wipe later to
sweep the windshield completely.* The interval between the
3 wipes and the last wipe will depend on the vehicle speed. The
last sweep does not happen if the vehicle speed exceeds about
170 km/h (106 mph).
NOTE: * The last single wipe can be deactivated. Ask your Lexus dealer for details.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.

SWITCHES
42To make the washer squirt, pull the lever toward you and
release it.
If the wiper lever is in the OFFº position, the wipers will
automatically make 3 wipes and then a single wipe later to
sweep the windshield completely.* The interval between the
3 wipes and the last wipe will depend on the vehicle speed. The
last sweep does not happen if the vehicle speed exceeds about
170 km/h (106 mph).
NOTE:
* The last single wipe can be deactivated. Ask your Lexus dealer for details.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It mayscratch the glass.

SWITCHES
43
REAR WINDOW WIPER ANDWASHER SWITCH

1Washer on during wiping
2Washer on
To turn the wipers on, twist the knob at the end of the lever.
The ignition key must be in the ONº position.
There are 2 settings:
INTº position: Intermittent operation
ONº position: Low speed operation
If you stop the vehicle with the rear window wiper switch in the
ONº position, the wiper speed automatically changes from low
speed to intermittent operation speed. To make the washer squirt, twist the knob downward to
position 2.
To make the washer squirt while operating in ONº
position, twist the knob upward to position 1.
The knob automatically returns from these positions after you
release it.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.

SECTION 1 ± 3
56
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder indicators
Fuel gauge57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Multi-information display 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . .

GAUGES, METERS AND SERVICE REMINDER INDICATORS
57
FUEL GAUGE

Low fuel level warning light
The gauge indicates the approximate quantity of fuel
remaining in the tank when the ignition switch is on.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches Eº or the low fuel level warning light
comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.It is not a malfunction even if the needle of the fuel gauge
returns to Eº when the ignition switch is turned to the STARTº
position.
See the inner back cover for fuel capacity and recommended
fuel selection.
