seat memory Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. OWNER'S MANUAL (OM60A87U)

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
x
Page
1Driving position memory switches208
. . . . . . . . . . .
2Power window switches 48
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 24
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 49
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 214 . . . . . .
6Side vents 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 33, 36, 37 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 37
. . . . . . . . . . . . . . . . . . . . . .
9Center vents 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 51
. . . . . . . . . . . . . . . . . . . . .
11Car audio 246
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 65
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 226
. . . . . . . . . .
14Rear window defogger switch 45
. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 56 . . . . . .
16Glove box 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Ashtray 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
18Cigarette lighter 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Seat heater switches 53
. . . . . . . . . . . . . . . . . . . . . . . . . .
20Four-wheel drive control lever 386
. . . . . . . . . . . . . . . Page
21Automatic transmission selector lever 378
. . . . . . . .
22Parking brake lever 376
. . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock switch 386
. . . . . . . . . . . . . . .
24Power outlet (12 VDC) 83
. . . . . . . . . . . . . . . . . . . . . . . . .
25Downhill assist control switch 410
. . . . . . . . . . . . . . .
26Electronic modulated suspension
control switch 404 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control air suspension
switches 397 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Ignition switch 374
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
292nd STRTº (second start) switch 386
. . . . . . . . . . . .
30Tire pressure warning system
selector switch 427 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31Cruise control switch 394
. . . . . . . . . . . . . . . . . . . . . . .
32Steering switches 268
. . . . . . . . . . . . . . . . . . . . . . . . . . .
33Instrument panel light control dial 76
. . . . . . . . . . . . . .
34Hood lock release lever 102
. . . . . . . . . . . . . . . . . . . . .
35Fuel filler door opener 103
. . . . . . . . . . . . . . . . . . . . . . .
36RSCA OFFº (roll sensing of curtain
shield airbags off) switch 183 . . . . . . . . . . . . . . . . . . . .
37Outside rear view mirror defogger switch 47 . . . . . . .
38Power outlet (115 VAC) main switch 85
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xii
Page
1Driving position memory switches208
. . . . . . . . . . .
2Power window switches 48
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 24
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 49
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 214 . . . . . .
6Side vents 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 33, 36, 37 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 37
. . . . . . . . . . . . . . . . . . . . . .
9Center vents 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 51
. . . . . . . . . . . . . . . . . . . . .
11Rear view monitor/navigation system display
(See the separate Navigation System Owner's Manualº.) 390 . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 65
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 226
. . . . . . . . . .
14Rear window defogger switch 45
. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 56 . . . . . .
16Glove box 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Car audio 246
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Ashtray 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
19Cigarette lighter 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Seat heater switches 53
. . . . . . . . . . . . . . . . . . . . . . . . . .
21Four-wheel drive control lever 386
. . . . . . . . . . . . . . . Page
22Automatic transmission selector lever 378
. . . . . . . .
23Parking brake lever 376
. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock switch 386
. . . . . . . . . . . . . . .
25Power outlet (12 VDC) 83
. . . . . . . . . . . . . . . . . . . . . . . . .
26Downhill assist control switch 410
. . . . . . . . . . . . . . .
27Electronic modulated suspension
control switch 404 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Rear height control air suspension
switches 397 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Ignition switch 374
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
302nd STRTº (second start) switch 386
. . . . . . . . . . . .
31Tire pressure warning system
selector switch 427 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Cruise control switch 394
. . . . . . . . . . . . . . . . . . . . . . .
33Speech command switch
See the separate
. . . . . . . . .
Navigation System Owner's Manualº.
34Steering switches 268
. . . . . . . . . . . . . . . . . . . . . . . . . . .
35Instrument panel light control dial 76
. . . . . . . . . . . . . .
36Hood lock release lever 102
. . . . . . . . . . . . . . . . . . . . .
37Fuel filler door opener 103
. . . . . . . . . . . . . . . . . . . . . . .
38RSCA OFFº (roll sensing of curtain
shield airbags off) switch 183 . . . . . . . . . . . . . . . . . . . .
39Outside rear view mirror defogger switch 47 . . . . . . .
40Power outlet (115 VAC) main switch 85
. . . . . . . . . . . .

SECTION 1 ± 6
11 4
INSTRUMENTS AND CONTROLS
Occupant restraint systems
Seats11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front seats 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints 136
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrests 138
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS driver airbag and front passenger airbag 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
SRS side airbags and curtain shield airbags 168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Child restraint 184
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 208
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .

OCCUPANT RESTRAINT SYSTEMS
208
DRIVING POSITION MEMORYSYSTEM
A microcomputer will memorize the position of the driver's
seat, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two dif ferent driving position profiles
can be entered into the computer's memory.
Recording the driving position in the computer's memory can
only be done when the ignition key is in the ONº position and
the selector lever is in the Pº position.
Setting the driving position
1. Adjust the driver's seat, tilt and telescopic steering and
outside rear view mirrors to the desired position.
2. While pushing the SETº button, push button 1º or 2º
until the signal beeps. The beep sound means that the positions are recorded in the
computer's memory.
By repeating these two steps and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
When
you push button 1º or 2º, the driving position will
be automatically adjusted to the position recorded for that
button.

OCCUPANT RESTRAINT SYSTEMS
209
Conditions for memorized position activation

Ignition key ONº and selector lever in Pº position.
All parts of the memorized positions can be activated.
 Key not in ignition switch and within 30 seconds of opening
driver's door.
The memorized position can be activated, except for the tilt
and telescopic steering.
If any driving position memory switch is pushed while one of the
memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (1º or 2º)
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle's battery is disconnected, the computer's
memory will be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.

ELECTRICAL COMPONENTS
588
25AIRSUSNO.210Rear height control air
suspension
26SEAT
HEATER20Seat heaters
27DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi- information display
28RADIO NO.120Car audio system, navigation
system
29ECU-B10
Multiplex communication
system, vehicle stability control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof, rear view
monitor system
30ECU-B NO.210Theft deterrent system
No.FUSEAMPERECIRCUIT
31ABS
MTR40
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
32AM230Starting system, all components
in IGNº, SRSº, GAUGEº and
ST2º fuses

ELECTRICAL COMPONENTS
590
48FR
WIP-WSH30Windshield wipers, windshield
washer
49TEMS20Electronic modulated
suspension
50DIFF20Four-wheel drive system
51RR WIP15Rear window wiper
52D P/SEAT30Driver's power seat
53P P/SEAT30Front passenger's power seat
54PWR
OUTLET15Power outlet (12 VDC)
55IG1 NO.210Rear air conditioning system,
inside rear view mirror, kinetic
dynamic suspension system
56RR WSH15Rear window washer
No.FUSEAMPERECIRCUIT
57ECU-IG10
Shift lock control system, power
windows, outside rear view
mirror defogger, anti-lock brake
system, active traction control
system, vehicle stability control
system, air conditioning system,
navigation system, power
windows, moon roof, Lexus link
system, tilt and telescopic
steering, multi- information
display, driving position
memory system, rear view
monitor system, tire pressure
warning system
