brake light Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM NOV. 2003 THROUGH DEC. 2003 PROD. OWNER'S MANUAL (OM60A74U)

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
x
Page
1Driving position memory switches 208. . . . . . . . . . .
2Power window switches 45. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 46. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 213. . . . . .
6Side vents 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 31, 33, 34. . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 34. . . . . . . . . . . . . . . . . . . . . .
9Center vents 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 48. . . . . . . . . . . . . . . . . . . . .
11Car audio 244. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 70. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 224. . . . . . . . . .
14Rear window defogger switch 42. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 61. . . . . .
16Glove box 88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Ashtray 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Cigarette lighter 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Seat heater switches 49. . . . . . . . . . . . . . . . . . . . . . . . . .
20Four-wheel drive control lever 384. . . . . . . . . . . . . . . Page
21Automatic transmission selector lever 376. . . . . . . .
22Parking brake lever 374. . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock switch 384. . . . . . . . . . . . . . .
24Power outlet (12 VDC) 85. . . . . . . . . . . . . . . . . . . . . . . . .
25Downhill assist control switch 408. . . . . . . . . . . . . . .
26Electronic modulated suspension
control switch 402. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control air suspension
switches 395. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Ignition switch 372. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
292nd STRTº switch 384. . . . . . . . . . . . . . . . . . . . . . . . . .
30Tire pressure warning system
selector switch 425. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31Cruise control switch 392. . . . . . . . . . . . . . . . . . . . . . .
32Steering pad switches 265. . . . . . . . . . . . . . . . . . . . . . .
33Instrument panel light control dial 76. . . . . . . . . . . . . .
34Hood lock release lever 103. . . . . . . . . . . . . . . . . . . . .
35Fuel filler door opener 104. . . . . . . . . . . . . . . . . . . . . . .
36Roll sensing of curtain shield airbags
off switch 183. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37Outside rear view mirror defogger switch 44. . . . . . .
38Power outlet (115 VAC) main switch 85. . . . . . . . . . . .

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xii
Page
1Driving position memory switches 208. . . . . . . . . . .
2Power window switches 45. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 46. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 213. . . . . .
6Side vents 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 31, 33, 34. . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 34. . . . . . . . . . . . . . . . . . . . . .
9Center vents 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 48. . . . . . . . . . . . . . . . . . . . .
11Rear view monitor/navigation system display
(See the separate Navigation System
Owner's Manualº.) 388. . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 70. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 224. . . . . . . . . .
14Rear window defogger switch 42. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 61. . . . . .
16Glove box 88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Car audio 244. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Ashtray 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Cigarette lighter 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Seat heater switches 49. . . . . . . . . . . . . . . . . . . . . . . . . . Page
21Four-wheel drive control lever 384. . . . . . . . . . . . . . .
22Automatic transmission selector lever 376. . . . . . . .
23Parking brake lever 374. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock switch 384. . . . . . . . . . . . . . .
25Power outlet (12 VDC) 85. . . . . . . . . . . . . . . . . . . . . . . . .
26Downhill assist control switch 408. . . . . . . . . . . . . . .
27Electronic modulated suspension
control switch 402. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Rear height control air suspension
switches 395. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Ignition switch 372. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
302nd STRTº switch 384. . . . . . . . . . . . . . . . . . . . . . . . . .
31Tire pressure warning system
selector switch 425. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Cruise control switch 392. . . . . . . . . . . . . . . . . . . . . . .
33Steering pad switches 265. . . . . . . . . . . . . . . . . . . . . . .
34Instrument panel light control dial 76. . . . . . . . . . . . . .
35Hood lock release lever 103. . . . . . . . . . . . . . . . . . . . .
36Fuel filler door opener 104. . . . . . . . . . . . . . . . . . . . . . .
37Roll sensing of curtain shield airbags
off switch 183. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
38Outside rear view mirror defogger switch 44. . . . . . .
39Power outlet (115 VAC) main switch 85. . . . . . . . . . . .

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xiv
Page
1Automatic transmission second start
indicator light 384. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 64. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 67. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 376. . . . . .
6Driver's seat belt reminder light 60. . . . . . . . . . . . . . . .
7Turn signal indicator light 33. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 59. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 33. . . . . . . . . . . .
10ABSº warning light 63. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 64. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 31. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 392. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 67. . . . . . . . . .
16Slip indicator light 404, 406, 409, 411. . . . . . . . . . . . .
17Low engine oil pressure warning light 66. . . . . . . . . . Page
18Discharge warning light 65. . . . . . . . . . . . . . . . . . . . . . .
19Engine coolant temperature gauge 54. . . . . . . . . . . . .
20Malfunction indicator lamp 62. . . . . . . . . . . . . . . . . . . .
21Vehicle stability control system off
indicator light 406. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22RSCA OFFº indicator light 183. . . . . . . . . . . . . . . . . .
23KDSSº warning light 65. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock indicator light 384. . . . . . . .
25VSC TRACº warning light 65. . . . . . . . . . . . . . . . . . . . .
26Downhill assist control system
indicator light 408. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control indicator lights 401. . . . . . . . . . .
28Security indicator light 14, 27. . . . . . . . . . . . . . . . . . . .
29SRS warning light 61. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Trip meter reset knob 57. . . . . . . . . . . . . . . . . . . . . . . . .
31Odometer and trip meter 57. . . . . . . . . . . . . . . . . . . . . .
32Low fuel level warning light 67. . . . . . . . . . . . . . . . . . . .
33Low tire pressure warning light 67. . . . . . . . . . . . . . . .
34Fuel gauge 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SWITCHES
32When the headlights are on, they automatically turn off about
30 seconds after any side door is opened and closed with the
ignition key turned to the ACCº or LOCKº position.* If you
want to turn off the lights immediately, push the LOCKº button
on the wireless remote control key twice. The lights also can
be turned off immediately by pushing the LOCKº button on the
wireless remote control key with all the doors locked.
NOTE:
* The time before turning off the lights can be changed.
Ask your Lexus dealer for details.
If any of the side door is kept opened, the lights automatically
turn off after 30 minutes.When the headlight switch is on with all the doors locked,
pushing the LOCKº button on the wireless remote control key
turns off the headlights.
If you are going to park for over one week, make sure the
headlight switch is off.
Daytime Running Light System
The daytime running light system make your front turn signal
lights turn on when the parking brake is released with the
engine started and the headlights are turned off. They will not
go off until the ignition switch is turned off.
NOTICE
To prevent the battery from being discharged, do not
leave the lights on longer than necessary when the
engine is not running.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
58IF THIS INDICATOR OR
BUZZER COMES ON...
DO THIS.
(f)
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(g)Close all side doors
and back door.
(h)Shift four-wheel drive
control out of Nº.
(i)Stop and check.
(j)Take vehicle to Lexus
dealer.
IF THIS INDICATOR OR
BUZZER COMES ON...DO THIS.
(k)Take vehicle to Lexus
dealer.
(l)Stop and check.
(m)Stop and check.
(n)Replace engine oil.
(o)Adjust tire pressure. If
light remains, contact
Lexus dealer.
(p)Fill up tank.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
59 IF THIS INDICATOR OR
BUZZER COMES ON...
DO THIS.
(q)Add washer fluid.
(r)Key reminder buzzerRemove key.
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the ONº position.
When the parking brake is applied...
This light comes on for a few seconds when the ignition key is
in the ONº position even after the parking brake is released.
When the brake fluid level is low...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
When the hydraulic brake booster fails...
If the hydraulic booster causes a problem resulting in poor
braking performance, the warning light comes on and buzzer
sounds continuously.
Have your vehicle checked at your Lexus dealer in the
following cases:
The light does not come on even if the parking brake is
applied when the ignition key is in the ONº position.
The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
60
CAUTION
If any of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
The light does not turn off even after the parking
brake is released while the engine is running.
The warning buzzer comes on together with the
warning light.
In either case, this can indicate that the brakes may not
work properly and your stopping distance will become
longer. Depress the brake pedal firmly and bring the
vehicle to an immediate stop.
The brake system warning light remains on together
with the ABSº warning light.
In this case, not only the anti-lock brake system will fail,
but also the vehicle will become extremely unstable
during braking.
Any of the following conditions may occur, but do not
indicate the malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the ONº position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns off and
the buzzer stops sounding after a few seconds.
You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Driver's Seat Belt Reminder Light and Buzzer
This light and buzzer remind you to buckle up the driver's seat
belt.
Once the ignition key is turned to ONº or STARTº, the
reminder light flashes and buzzer sounds if the driver's seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(f) ABSº Warning Light
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ABSº warning light is on (and the brake system
warning light is off), the following systems do not operate, but
the brake system still operates conventionally.
Anti-lock brake system
Brake assist system
Active traction control system
Vehicle stability control system
Downhill assist control system
Hill-start assist control system
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate, so that the wheels will lock up during a sudden braking
or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ONº position, or remains on.
The light comes on while you are driving.A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti-lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Either of the following conditions may occur, but do not
indicate a malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the ONº position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
65
(j) VSC TRACº Warning Light
This light warns that there is a problem somewhere in the
following.
Vehicle stability control system
Active traction control system
Downhill assist control system
Hill-start assist control system
The light will come on when the ignition key turned to ONº, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the ONº position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the VSC TRACº warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
(k) KDSSº Warning Light (vehicles with kinetic
dynamic suspension system)
This light warns that there is a problem somewhere in the
kinetic dynamic suspension system.
The light will come on when the ignition key is turned to the
ONº position and will go off after a few seconds.
If the light comes on while driving, bring your vehicle to your
Lexus dealer as soon as possible and have it checked.
(l) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
68
(r) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver's door with the ignition key in the ACCº or LOCKº
position.
How to check all the service reminder
indicators (except the low fuel level warning
light)
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four-wheel drive control lever in Nº position and
the selector lever in Pº position and turn the ignition key to
ACCº.
The following service reminder indicator should come on. It
goes off when you place the four-wheel drive control lever in
Hº or Lº position.
