jacking Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM SEP. 2004 PROD. OWNER'S MANUAL (OM60B57U)

STARTING AND DRIVING
416
NOTICE
When jacking up or installing tire chains, be sure toturn off the rear height control air suspension withthe HEIGHT CONTROL OFFº switch and stop theengine. Otherwise, the vehicle height may changebecause of the automatic leveling function resultingin accident.
If your vehicle must be towed, put the vehicle heightin the Nº mode and turn off the rear height control airsuspension. Otherwise, the vehicle height may
change because of the automatic leveling functionresulting in accident.
If your vehicle gets ditched, turn off the rear heightcontrol air suspension with the HEIGHT CONTROLOFFº switch. Otherwise, the vehicle height maychange because of the automatic leveling functionresulting in accident.

IN CASE OF AN EMERGENCY
486B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight
line. Move cautiously off the road to a safe place
Ð well away from the traffic. Avoid stopping on the
center divider of a highway. Park on a level spot with
firm ground.
2. Stop the engine and turn on your emergency
flashers.
3. F i r m l y s e t t h e p a r k i n g b r a k e a n d p u t t h e
transmission in Pº.
4. Have everyone get out of the vehicle on the side
away from traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following
to reduce the possibility of personal injury:
Turn off the active height control suspension
by pushing the active height control switch.
 Follow jacking instructions.

IN CASE OF AN EMERGENCY
488
NOTICE
Do not continue driving with a deflated tire.Driving even a short distance can damage a
tire and wheel beyond repair.
When jacking up or installing tire chains, besure to turn off the rear height control airsuspension with the HEIGHT CONTROL
OFFº switch and stop the engine. Otherwise,the vehicle height may change because of the
automatic leveling function resulting inaccident.

CHASSIS
599
NOTICE
When jacking up or installing tire chains, be sure to turn
off the rear height control air suspension with the HEIGHT CONTROL OFFº switch and stop the engine.Otherwise, the vehicle height may change because ofthe automatic leveling function resulting in accident.
