belt Lexus GX470 2004 Engine / LEXUS 2004 GX470 THROUGH OCT. 2003 PROD. OWNER'S MANUAL (OM60A46U)

IMPORTANT INFORMATION ABOUT YOUR LEXUS
ii
IMPORTANT INFORMATION
ABOUT YOUR LEXUS
Occupant restraint systems
Lexus encourages you and your family to take the time to read
Section 1-6 of this Owner's Manual carefully. In terms of
helping you understand how you can receive the maximum
benefit of the occupant restraint systems this vehicle provides,
Section 1-6 of this Owner's Manual is the most important
Section for you and your family to read.
Section 1-6 describes the function and operation concerning
seats, seat belts, SRS airbags and child restraint systems of
this vehicle and some potential hazards you should be aware
of. These systems work together along with the overall
structure of this vehicle in order to provide occupant restraint
in the event of a crash. The effect of each system is enhanced
when it is used properly and together with other systems. No
single occupant restraint system can, by itself, provide you or
your family with the equal level of restraint which these
systems can provide when used together. That is why it is
important for you and your family to understand the purpose
and proper use of each of these systems and how they relate
to each other.The purpose of all occupant restraint systems is to help reduce
the possibility of death or serious injury in the event of a
collision. None of these systems, either individually or
together, can ensure that there is no injury in the event of
collision. However, the more you know about these systems
and how to use them properly, the greater your chances
become of surviving an accident without death or serious
injury.
Seat belts provide the primary restraint to all occupants of the
vehicle, and every occupant of the vehicle should wear seat
belts properly at all times. Children should always be secured
in child restraint systems that are appropriate for their age and
size. SRS (Supplemental Restraint System) airbags are, as
their names imply, designed to work with, and be supplemental
to, seat belts and are not substitutes for them. SRS airbags
can be very effective in reducing the risk of head and chest
injuries by preventing contact of the head and chest with
interior portions of the vehicle.
In order to be effective, the SRS airbags must deploy with
tremendous speed. The rapid deployment of the SRS airbags
makes the SRS airbags themselves potential sources of injury
if an occupant is too close to an airbag, or if an object or some
part of his or her body has been placed between the occupant
and the airbag at the time of deployment. This is just one
example of how the instructions in Section 1-6 of this Owner's
Manual will help ensure proper use of the occupant restraint
systems, and increase the safety they can provide to you and
your family in the event of an accident.
Lexus recommends you to read the provisions in Section 1-6
carefully and refer to them from time to time during your time
of ownership of this vehicle.

IMPORTANT INFORMATION ABOUT YOUR LEXUS
iv
Accessories, spare parts and modification of
your Lexus
A wide variety of non-genuine spare parts and accessories for
Lexus vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse
effect they may have on, your Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus
products. Modification with non- genuine Lexus products
could affect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance problems resulting from the modification may not
be covered under warranty.
If you install any Genuine Accessories such as a bull-bar,
winch, etc., consult your Lexus dealer.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti-lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Tires and loading on your Lexus
Underinflated or overinflated tire pressure and the
excess load may result in the deterioration of steering
ability and braking ability, leading to an accident.
Check the tire inflation pressure periodically and be
sure to keep the load limits given in this Owner's
Manual. For details about tire inflation pressure and
load limits, see pages 532 and 431.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as a fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
x
Page
1Driving position memory switches 200. . . . . . . . . . .
2Power window switches 43. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 44. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 205. . . . . .
6Side vents 228. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 29, 31, 32. . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switch 32. . . . . . . . . . . . . . . . . . . . . .
9Center vents 228. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 46. . . . . . . . . . . . . . . . . . . . .
11Car audio 235. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multi-information display 67. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 215. . . . . . . . . .
14Rear window defogger switch 40. . . . . . . . . . . . . . . . . .
15Front passenger's seat belt reminder light 58. . . . . .
16Glove box 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Ashtray 79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Cigarette lighter 79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Seat heater switches 47. . . . . . . . . . . . . . . . . . . . . . . . . . Page
20Four-wheel drive control lever 373. . . . . . . . . . . . . . .
21Automatic transmission selector lever 365. . . . . . . .
22Parking brake lever 363. . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock switch 373. . . . . . . . . . . . . . .
24Power outlet (12 VDC) 81. . . . . . . . . . . . . . . . . . . . . . . . .
25Downhill assist control switch 393. . . . . . . . . . . . . . .
26Electronic modulated suspension
control switch 387. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control air suspension
switches 380. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Ignition switch 361. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
292nd STRTº switch 373. . . . . . . . . . . . . . . . . . . . . . . . . .
30Cruise control switch 377. . . . . . . . . . . . . . . . . . . . . . .
31Steering pad switches 256. . . . . . . . . . . . . . . . . . . . . . .
32Hood lock release lever 99. . . . . . . . . . . . . . . . . . . . . . .
33Fuel filler door opener 100. . . . . . . . . . . . . . . . . . . . . . .
34Instrument panel light control dial 73. . . . . . . . . . . . . .
35Outside rear view mirror defogger switch 42. . . . . . .
36Power outlet (115 VAC) main switch 81. . . . . . . . . . . .

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xii
Page
1Automatic transmission second start
indicator light 373. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 61. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 65. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 365. . . . . .
6Driver's seat belt reminder light 58. . . . . . . . . . . . . . . .
7Turn signal indicator light 31. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 57. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 31. . . . . . . . . . . .
10ABSº warning light 60. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 61. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 29. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 377. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 64. . . . . . . . . .
16Engine coolant temperature gauge 52. . . . . . . . . . . . . Page
17Discharge warning light 63. . . . . . . . . . . . . . . . . . . . . . .
18Low engine oil pressure warning light 64. . . . . . . . . .
19Malfunction indicator lamp 59. . . . . . . . . . . . . . . . . . . .
20Slip indicator light 389, 391, 394, 396. . . . . . . . . . . . .
21Vehicle stability control system off
indicator light 391. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Center differential lock indicator light 373. . . . . . . .
23VSC TRACº warning light 63. . . . . . . . . . . . . . . . . . . . .
24Downhill assist control system
indicator light 393. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Rear height control indicator lights 386. . . . . . . . . . .
26Security indicator light 14, 26. . . . . . . . . . . . . . . . . . . .
27SRS warning light 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Trip meter reset knob 55. . . . . . . . . . . . . . . . . . . . . . . . .
29Odometer and trip meter 55. . . . . . . . . . . . . . . . . . . . . .
30Low fuel level warning light 65. . . . . . . . . . . . . . . . . . . .
31Fuel gauge 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

KEYS AND DOORS
22
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.
Closing the door with the lock button pushed in will also lock the
door. Be careful not to lock your keys in the vehicle. Doors
cannot be locked when either front door is open and the key is
in the ignition.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle during an accident.
It also helps prevent the doors from being opened
unintentionally.
Locking with power door lock switch

1Lock2Unlock
To lock all the side doors and back door simultaneously,
push the power door lock switch down on the front side.
Pushing down on the rear side will unlock them.
The same switch is also located on the front passenger's side.
If you do any of the following, no door can be unlocked with the
power door lock switch.
Lock all the doors with the key or wireless remote control
when all the doors are closed.
Open the driver's door or front passenger's door and move
the inside lock buttons of both front doors to the lock
position, then close the front doors.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
55
ODOMETER AND TRIP METER

Trip meter reset knob
This meter displays the odometer and two trip meters. To
change the mode indication, push the trip meter reset
knob briefly. Each time you push the knob, the mode
changes in order from the odometer to trip meter A to trip
meter B, then back to the odometer, etc.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set the A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS
AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON...DO THIS.
(a)
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver's seat
belt.
(c)Fasten front
passenger's seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Take vehicle to Lexus
dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
58Any of the following conditions may occur, but do not
indicate the malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the ONº position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns off and
the buzzer stops sounding after a few seconds.
You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Driver's Seat Belt Reminder Light and Buzzer
This light and buzzer remind you to buckle up the driver's seat
belt.
Once the ignition key is turned to ONº or STARTº, the
reminder light flashes and buzzer sounds if the driver's seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.
(c) Front Passenger's Seat Belt Reminder Light
This light reminds you to buckle up the front passenger's seat
belt.
Once the ignition key is turned to ONº or STARTº, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light stays flashing.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built-in sensors in the seat cushion may detect the pressure,
causing the reminder light to come on.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
59
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ONº position. It goes off after about 6 seconds. This
means the SRS airbags and front seat belt pretensioners
are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver's seat position sensor, driver's seat belt buckle switch,
front seat belt pretensioner assemblies, inflators, warning light,
interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
When the ignition key is turned to the ONº position, the light
does not come on, remains on or flashes.
The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags have a problem. If the light flashes, the side
and curtain shield airbags and/or seat belt pretensioners have
a problem.
(e) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
ONº position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while driving,
first check the followings.
Empty fuel tank
If the fuel tank is empty, refuel immediately.
Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp will not go off even after the several trips, contact
your Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If the engine speed does not increase with the accelerator
pedal depressed down, there may be a problem somewhere
in your electronic throttle control system.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(j) VSC TRACº Warning Light
The light warns that there is a problem somewhere in the
following.
Vehicle stability control system
Active traction control system
Downhill assist control system
Hill-start assist control system
The light will come on when the ignition key turned to ONº, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the ONº position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the VSC TRACº warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
(k) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
64
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
(l) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on Ð
even for one block. It may ruin the engine.
(m) Engine Oil Replacement Reminder Light
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to ONº
and will go off after about a few seconds.
When you drive for about 8000 km (5000 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to ONº position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds 12000 km (7500 miles), the light will come on after the
ignition key is turned to ONº position. The light will remain on
thereafter.If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible.
