SWITCHES
40
REAR WINDOW DEFOGGER
SWITCH

Vehicles with navigation system

Vehicles without navigation system
To turn the electric rear window defogger on, push the
switch.
The ignition key must be in the ONº position.
The thin heater wires on the inside of the rear window will
quickly clear the surface. An indicator light will illuminate to
indicate the defogger is operating.
The system will automatically shut off when the defogger has
operated about 15 minutes.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger off. Continuous use may cause
the battery to discharge, especially during stop-and-go
driving. The defogger is not designed to dry rain water or to
melt snow.

SECTION 2 ± 1
214
AIR CONDITIONING AND AUDIO
Air conditioning
Automatic air conditioning controls 215. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear cooler controls232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicles equipped with Navigation System,
please refer to the separate Navigation System
Owner's Manualº.

Finish
SECTION 2 ± 2
234
AIR CONDITIONING AND AUDIO
Audio
Audio system235 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat audio system264 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat entertainment system280 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Audio systemº instructions for vehicles
equipped with Navigation System, please refer to
the separate Navigation System Owner's Manualº.

ELECTRICAL COMPONENTS
558
25AIRSUS
NO.210Rear height control air
suspension
26SEAT
HEATER20Seat heaters
27DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi- information display
28RADIO
NO.120Car audio system, navigation
system
29ECU-B10
Multiplex communication
system, vehicle stability control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof
30ECU-B
NO.210Theft deterrent system
31ABS
MTR40
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
32AM230Starting system, all components
in IGNº, SRSº, GAUGEº and
ST2º fuses
No.FUSEAMPERECIRCUIT

ELECTRICAL COMPONENTS
559
33ABS
SOL50
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
34ALT-S7.5Charging system
35MAYDAY7.5Lexus link system
36HORN10Horns
37TRN-HAZ15Turn signal lights
38ETCS10Electronic throttle control system
39EFI20Multiport fuel injection
system/sequential multiport fuel
injection system
40D FR P/W20Power window
41DR/LCK25Power door lock
42TOWING30Towing converter
43RADIO
NO.230Car audio system, navigation
system
44IGN10
Multiport fuel injection
system/sequential multiport fuel
injection system, vehicle
stability control system
45SRS10SRS airbag system
46GAUGE7.5Gauges and meters
47ST27.5Multiport fuel injection
system/sequential multiport fuel
injection system
No.FUSEAMPERECIRCUIT

ELECTRICAL COMPONENTS
560
48FR
WIP-WSH30Windshield wipers, windshield
washer
49TEMS20Electronic modulated
suspension
50DIFF20Four-wheel drive system
51RR WIP15Rear window wiper
52D P/SEAT30Driver's power seat
53P P/SEAT30Front passenger's power seat
54PWR
OUTLET15Power outlet (12 VDC)
55IG1 NO.210Rear air conditioning system,
inside rear view mirror
56RR WSH15Rear window washer
57ECU-IG10
Shift lock control system, power
windows, outside rear view
mirror defogger, anti-lock brake
system, active traction control
system, vehicle stability control
system, air conditioning system,
navigation system, power
windows, moon roof, Lexus link
system, tilt and telescopic
steering, multi- information
display, driving position
memory system
58IG110
Air conditioning system, back-up
lights, rear window defogger,
seat heaters, vehicle stability
control system
No.FUSEAMPERECIRCUIT

ELECTRICAL COMPONENTS
561
59STA7.5Multiport fuel injection
system/sequential multiport fuel
injection system
60P FR P/W20Front passenger's power window
61P RR P/W20Rear right side power window
62D RR P/W20Rear left side power window
63PANEL10Instrument panel lights
64TAIL10Parking lights, tail lights, license
plate lights, front fog lights
65ACC7.5
Shift lock control system, power
outlets, outside rear view
mirrors, car audio system,
navigation system, power rear
view mirrors, multi- information
display
66CIG10Cigarette lighter
67POWER
OR TI&TE30Power windows, moon roof, tilt
and telescopic steering
