center console Lexus GX470 2004 Pictorial Index / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. OWNER'S MANUAL (OM60A87U)

Finish
INTERIOR EQUIPMENT
81

1Foot lights
2Ignition switch light
3Personal lights (with the DOORº position)
4Center console spot lights
5Inside door handle lights
6Center interior light (with the DOORº position)
7Running board lights
All of the lights except the center console spot lights will
come on when any of the side doors are opened.* After all
the doors are closed, the lights remain on for about 15
seconds before fading out.**
NOTE:
* The operating condition can be changed.** The duration of lighting can be changed, and the footlights and inside door handle lights can be set not to comeon.Ask your Lexus dealer for details.
However, in the following cases, the lights go out immediately:
 All of the lights except the center console spot lights Ð All
the side doors and back door are locked.
 Ignition switch light, personal lights and center interior light
Ð All the side doors are closed and the ignition key is in the
ACCº or ONº position.
 Running board lights Ð The vehicle speed exceeds about
8 km/h (5 mph). When
any of the side doors is unlocked, all of the lights except
the center console spot lights will come on and remain on for
about 15 seconds before fading out.
To prevent the battery being discharged, all of the lights will
automatically turn off when the ignition key removed and the
door is left opened for about 30 minutes.
Ignition switch light, personal lights and center interior
light
The ignition switch light, personal lights and center interior light
also come on and remain on for about 15 seconds before
fading out when the ignition switch is turned to the LOCKº
position.
Foot lights and inside door handle lights
The foot lights and inside door handle lights also come on when
the ignition switch is in the ONº position with the selector lever
in the Pº position. When the selector lever is moved out of the
Pº position, the foot lights and inside door handle lights will be
dimmed.*
NOTE: * The foot lights and inside door handle lights can be set toturn off when the selector lever is moved out of the Pºposition.
Ask your Lexus dealer for details.
Center console spot lights
The center console spot lights come on when the ignition
switch is in the ACCº or ONº position.

Finish
INTERIOR EQUIPMENT
87
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.
REAR CONSOLE BOX
To access the rear console box, push the center of the lid.
The rear console box light comes on when the tail lights are
turned on.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the rear console box closed
while driving.

AUDIO
313
After replacing the battery, check that the controller operates
properly. If
the controller still does not operate properly, contact
your Lexus dealer.
DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dts-CDs, DVD audio discs and video CDs.
For appropriate discs for this player, see Car audio/video
system operating hintsº on page 361.
The DVD player works when the ignition key is in the ACCº or
ONº position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc
1. Push the center of the rear console box lid.

IN CASE OF AN EMERGENCY
507
Audible voice prompts
The following table shows the voice responses from the Lexus Link System\
.Voice phrase: Explanation about Lexus Link System
This is the Lexus Link system. Integrating
global positioning satellite and wireless
communication technology into your
Lexus and providing enhanced safety,
security, and convenience. At the touch of
a button, or automatically in the event of
an accident, you are connected to a Lexus
Link Advisor who will assist you Ð 24
hours a day, 7 days a week where GPS
and cellular coverage is available. The
Lexus Link System also has an audio
recorder allowing you to record reminders
to yourself or information from a Lexus
Link Advisor.
To contact a Lexus Link Advisor, press the
SERVICESº button. The Lexus Link
System will inform the advisor of your
vehicle's current location and your
identity. The advisors can handle a wide
variety of services, such as giving
directions to shops, gas stations, ATMs,
restaurants and roadside assistance with
location. Services available will depend
on the service package you selected.In an emergency, press the emergency
services button on your Lexus Link
console. It is marked with a red
ambulance. Upon receiving your call, the
advisor will assess the situation and, if
necessary, alert the nearest emergency
services provider. The emergency button
should only be used in life threatening
situations.
If your Lexus detects that an airbag
deployment may have occurred, the
Lexus Link System will automatically send
an emergency message to the Lexus Link
Call Center.
The system will also automatically contact
the call center if the security system alarm
goes off. An advisor will first contact you
to determine if the alarm is valid. Upon
your confirmation, the advisor will then
provide the vehicle location to the police.If you accidentally set off the alarm, press
the remote door unlock, or insert your key
in the door lock or ignition within 55
seconds. This will prevent the Lexus Link
System from placing a theft call.
The volume control lets you adjust the
volume level for Lexus Link calls, system
prompts, and memos. Press the plus key
to increase volume and the minus key to
decrease it.
To record a memo or a call, press the key
labeled RECº. When you are finished
recording, press the RECº button again.
To listen to the memo, press the PLAYº
button. You can record one message up
to five minutes long. When you record a
new memo, all of the previous memos will
be erased.
For more detailed information on the use,
features and limitations of this system,
please consult your Lexus Link Owner's
Manual.
