GAUGES, METERS AND SERVICE REMINDER INDICATORS
59
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ONº position. It goes off after about 6 seconds. This
means the SRS airbags and front seat belt pretensioners
are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver's seat position sensor, driver's seat belt buckle switch,
front seat belt pretensioner assemblies, inflators, warning light,
interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
When the ignition key is turned to the ONº position, the light
does not come on, remains on or flashes.
The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags have a problem. If the light flashes, the side
and curtain shield airbags and/or seat belt pretensioners have
a problem.
(e) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
ONº position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while driving,
first check the followings.
Empty fuel tank
If the fuel tank is empty, refuel immediately.
Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp will not go off even after the several trips, contact
your Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If the engine speed does not increase with the accelerator
pedal depressed down, there may be a problem somewhere
in your electronic throttle control system.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
60At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ACCº or LOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On-Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see Emissions inspection and maintenance (I/M)
programsº on page 493.
(f) ABSº Warning Light
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ABSº warning light is on (and the brake system
warning light is off), the following systems do not operate, but
the brake system still operates conventionally.
Anti-lock brake system
Brake assist system
Active traction control system
Vehicle stability control system
Downhill assist control system
Hill-start assist control system
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate, so that the wheels will lock up during a sudden braking
or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ONº position, or remains on.
The light comes on while you are driving.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
61 A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti-lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Either of the following conditions may occur, but do not
indicate a malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the ONº position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.
(g) Open Door Warning Light
This light remains on until all the side doors and back door are
completely closed.
(h) Unengaged Parkº Warning Light
This light warns that the transmission Parkº mechanism is not
engaged. If the four-wheel drive control is in the Nº position
while the selector lever is in the Pº position, the transmission
will disengage and the wheels will not lock.
CAUTION
To restore the park function, shift the four-wheel drive
control out of Nº.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
62
(i) Automatic Transmission Fluid Temperature
Warning Light
This light warns that the automatic transmission fluid
temperature is too high.If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in Pº and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go off, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(j) VSC TRACº Warning Light
The light warns that there is a problem somewhere in the
following.
Vehicle stability control system
Active traction control system
Downhill assist control system
Hill-start assist control system
The light will come on when the ignition key turned to ONº, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the ONº position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the VSC TRACº warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
(k) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
64
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
(l) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on Ð
even for one block. It may ruin the engine.
(m) Engine Oil Replacement Reminder Light
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to ONº
and will go off after about a few seconds.
When you drive for about 8000 km (5000 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to ONº position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds 12000 km (7500 miles), the light will come on after the
ignition key is turned to ONº position. The light will remain on
thereafter.If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
65 You need to reset the light after the engine oil replacement.
Reset the light by following the procedure below:
1. Turn the ignition key to the OFFº position with the odometer
reading shown. (For details, see Odometer and trip meterº on
page 55.)
2. Turn the ignition key to the ONº position while holding down
the trip meter reset knob.
Hold down the knob until the light goes off. Before the light
goes off, it illuminates for 3 seconds, flashes for 2 seconds and
illuminates for 1 second.
If the system fails to reset, the light will remain flashing. In this
case, return to step 1 and try again.
(n) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(o) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(p) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver's door with the ignition key in the ACCº or LOCKº
position.
How to check all the service reminder
indicators (except the low fuel level warning
light)
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four-wheel drive control lever in Nº position and
the selector lever in Pº position and turn the ignition key to
ACCº.
The following service reminder indicator should come on. It
goes off when you place the four-wheel drive control lever in
Hº or Lº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
664. Turn the ignition key to ONº.
The following service reminder indicators should come on.

w72a
w73
The following service reminder indicator goes off after a few
seconds.

The anti-lock brake system warning light, vehicle stability
control system off indicator light and vehicle stability control
system and active traction control system warning light may
stay on for about 60 seconds after the ignition key is turned to
the ONº position. It is normal if they go out after a while.The following service reminder indicator should come on. It
goes off after about 6 seconds.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
MULTI-INFORMA TION DISPLAY
13PY018

1MODEº button2º button
3º button4RESETº button
The multi-information display provides various
information, including clock, outside temperature, and
your vehicle's driving condition.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multi-information display, the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
You can adjust the brightness of the display. To adjust the
brightness, see ADJUSTING THE BRIGHTNESS OF THE
DISPLAYº below.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
68ADJUSTING THE BRIGHTNESS OF THE DISPLAY
The key must be in the ACCº or ONº position. To adjust the
brightness of the display, push and hold the MODEº button for
more than 2 seconds. ILLº will appear on the display.
To increase the brightness Ð Push the
º button.
To decrease the brightness Ð Push the
º button.
You can adjust the brightness to 3 levels (when the tail lights
are off) or 6 levels (when the tail lights are on).
After adjusting, the display automatically return to the previous
display.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
Clock
The digital clock indicates the time when the key is in the
ACCº or ONº position.
To reset the time, push and hold the MODEº button for 2
seconds. ILLº will appear on the display. Then push the
MODEº button once. The time will blink.
To reset the hour Ð Push the
º button.
To reset the minutes Ð Push the
º button.
To adjust the time to the nearest hour, push the RESETº
button. For example, if the RESETº button is depressed when
the time is between 1:01 Ð 1:29, the time will change to 1:00.
If the time is between 1:30 Ð 1:59, the time will change to 2:00.
If the electric power source has been disconnected, the time
display will automatically be set to 1:00.
