HOW TO USE THIS MANUAL
vi
HOW TO USE THIS MANUAL
The contents of this manual are explained briefly on this
page to help you make the best use of the manual. Please
read this page and the rest of the Owner's Manual
carefully to make sure you fully understand the operation
of your vehicle.
This will help you enjoy safe and comfortable driving.
TABLE OF CONTENTS
The table of contents and the pictorial index provide easy
reference to the appropriate pages.
BASIC OPERATION Ð QUICK REFERENCE
Operation of basic equipment is briefly explained in an easily
understandable way for quick reference.
SECTION 1 Ð INSTRUMENTS AND CONTROLS
The vehicle's equipment is divided into the 7 groups listed
below. Use of the equipment is explained, including any points
you should pay particular attention to.
1. Keys and doors
2. Switches
3. Gauges, meters and service reminder indicators
4. Interior equipment
5. Exterior equipment
6. Occupant restraint systems
7. Steering wheel and mirrors
SECTION 2 Ð AIR CONDITIONING AND AUDIO
The features of the vehicle's air conditioning and audio are
explained in detail. Be sure to read this Section so that you can
make full use of them.
SECTION 3 Ð STARTING AND DRIVING
Starting the engine, driving, stopping, operation of features
affecting vehicle handling, hints on vehicle safety and safe
driving techniques are all explained. Please read everything
in this Section, and remember Ð drive safely!
SECTION 4 Ð IN CASE OF AN EMERGENCY
This Section explains what to do in the event of an urgent
situation such as the engine not starting or getting a flat tire,
etc. If such a problem occurs, check the contents of this
Owner's Manual and follow the instructions given.
SECTION 5 Ð MAINTENANCE
This Section explains the importance of regular maintenance.
Regular and periodic inspection and maintenance of your
Lexus will help to keep your vehicle in its best condition.
SECTION 6 Ð SERVICE PROCEDURES AND
SPECIFICATIONS
Simple maintenance procedure and service data are provided
here for your reference should you wish to perform inspection
and maintenance yourself.
INDEX
The page number is listed for each item in the Owner's Manual
so that you can rapidly find the item and page you are
searching for.

KEYS AND DOORS
11
When using a key containing a transponder chip,
observe the following precautions:

When starting the engine, do not use the key with a
key ring resting on the key grip and do not press the
key ring against the key grip. Doing so may prevent
the engine from starting, or may cause the engine to
stop soon after it starts.

KEYS AND DOORS
12

When starting the engine, do not use the key in
proximity with other transponder keys (including the
flat key and keys of other vehicles), and do not press
other key plates against the key grip. Doing so may
prevent the engine from starting, or may cause the
engine to stop soon after it starts. If this happens,
remove the key once and then insert it again after
removing other transponder keys (including the flat
key and keys of other vehicles) from the ring or while
gripping or covering them with your hand to start the
engine.

KEYS AND DOORS
17
Sounding an alarm*
When you push the PANICº button for about 1 second, an
alarm sounds to deter any person trying to break into or
damage your vehicle.
If you want to stop the alarm, push any button.
This function does not work when the ignition key is in the ONº
position.
NOTE:
* The alarm can be set not to sound.
Ask your Lexus dealer for details.
Operating the windows and moon roof
The windows and moon roof can be opened using a
wireless key from outside the vehicle.*
NOTE:
* The windows and moon roof can be set inoperative.
Ask your Lexus dealer for details.
Push the UNLOCKº button until the windows and moon roof
start to move. A beep sounds just before opening. When you
release the button, the windows and moon roof stop opening.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.

KEYS AND DOORS
26

Security indicator light
Setting the system
1. Turn the ignition key to the LOCKº position and
remove it.
The engine immobilizer system causes the indicator light to
flash.
2. Close and lock all the doors and hood using an ignition
key or wireless remote control.
If you lock them with wireless remote control, the turn signals
flash once.
The flashing indicator light will remain on when all the doors
and hood are closed and locked.
3. After 30 seconds, the indicator starts flashing and the
system is set.
Cancelling the system
When you unlock any door using an ignition key or
wireless remote control, the system is cancelled.
If you unlock any door with wireless remote control, the turn
signals flash twice.
Activating the system
The alarm sounds for 60 seconds if any of the following are
operated:
Unlocking any door without using an ignition key or wireless
remote control.
Opening the hood and any doors forcibly.
Reconnecting the battery.
If the battery becomes discharged due to the vehicle being
unused for a long time, etc., when the battery is recharged or
replaced, the system will give the alarm. If this happens,
immediately unlock any of the doors with the key or the
wireless remote control, and the alarm will stop.
If any door is unlocked and the ignition key is not in the ignition
switch during the alarm sounding, its door is automatically
locked.
To stop the alarm: Use either of the following methods.
Unlock the door using an ignition key or wireless remote
control.
Turn the ignition switch on.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
ENGINE COOLANT
TEMPERATURE GAUGE

Normal range
The gauge indicates the engine coolant temperature when
the ignition switch is on. The engine operating
temperature will vary with changes in weather and engine
load.
If the needle points to the red zone or higher, stop your vehicle
and allow the engine to cool.
Your vehicle may overheat during severe operating conditions,
such as:
Driving up a long hill on a hot day.
Reducing speed or stopping after high speed driving.
Idling for a long period with the air conditioning on in
stop-and-go traffic.
Towing a trailer.It is not a malfunction even if the needle of the engine coolant
temperature gauge returns to Cº when the ignition switch is
turned to the STARTº.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
58Any of the following conditions may occur, but do not
indicate the malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the ONº position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns off and
the buzzer stops sounding after a few seconds.
You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Driver's Seat Belt Reminder Light and Buzzer
This light and buzzer remind you to buckle up the driver's seat
belt.
Once the ignition key is turned to ONº or STARTº, the
reminder light flashes and buzzer sounds if the driver's seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.
(c) Front Passenger's Seat Belt Reminder Light
This light reminds you to buckle up the front passenger's seat
belt.
Once the ignition key is turned to ONº or STARTº, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light stays flashing.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built-in sensors in the seat cushion may detect the pressure,
causing the reminder light to come on.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
60At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ACCº or LOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On-Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see Emissions inspection and maintenance (I/M)
programsº on page 493.
(f) ABSº Warning Light
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the ABSº warning light is on (and the brake system
warning light is off), the following systems do not operate, but
the brake system still operates conventionally.
Anti-lock brake system
Brake assist system
Active traction control system
Vehicle stability control system
Downhill assist control system
Hill-start assist control system
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate, so that the wheels will lock up during a sudden braking
or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ONº position, or remains on.
The light comes on while you are driving.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
62
(i) Automatic Transmission Fluid Temperature
Warning Light
This light warns that the automatic transmission fluid
temperature is too high.If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in Pº and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go off, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(j) VSC TRACº Warning Light
The light warns that there is a problem somewhere in the
following.
Vehicle stability control system
Active traction control system
Downhill assist control system
Hill-start assist control system
The light will come on when the ignition key turned to ONº, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the ONº position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the VSC TRACº warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
(k) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
