change time Lexus GX470 2005 Pictorial Index / LEXUS 2005 GX470 (OM60B11U) Owner's Guide

AUDIO
287
AUDIO SYSTEM OPERATING HINTS
NOTICE
To ensure correct audio system operations:
Be careful not to spill beverages over the audiosystem.
Do not put anything other than a cassette tape or CDinto the cassette tape slot or CD slot.
The use of a cellular phone inside or near the vehiclemay cause a noise from the speakers of the audio
system which you are listening to. However, thisdoes not indicate a malfunction.
Radio reception
Usually, a problem with radio reception does not mean there is
a problem with your radio Ð it is just the normal result of
conditions outside the vehicle.
For example, nearby buildings and terrain can interfere with
FM reception. Power lines or telephone wires can interfere
with AM signals. And of course, radio signals have a limited
range. The farther you are from a station, the weaker its signal
will be. In addition, reception conditions change constantly as
your vehicle moves.
Here are some common reception problems that probably do
not indicate a problem with your radio: FM
Fading
and drifting stations Ð Generally, the effective range
of FM is about 40 km (25 miles). Once outside this range, you
may notice fading and drifting, which increase with the distance
from the radio transmitter. They are often accompanied by
distortion.
Multi±path Ð FM signals are reflective, making it possible for
two signals to reach your antenna at the same time. If this
happens, the signals will cancel each other out, causing a
momentary flutter or loss of reception.
Static and fluttering Ð These occur when signals are
blocked by buildings, trees, or other large objects. Increasing
the bass level may reduce static and fluttering.

AUDIO
294
REAR SEAT AUDIO SYSTEM
The rear seat audio system is designed for the rear seat
passengers to enjoy the audio sound separately between
the front seats and the rear seats.
The rear seat audio system can be turned on with the rear
audio system remote control even if the front audio system is
off. When the front audio is turned off, the rear audio system
will be turned off simultaneously.
The rear passengers can enjoy all the modes (AM and FM
radio, cassette tape player and CD player with changer) with
the rear seat audio system when a cassette tape and a CD are
loaded in the front audio system.
When the same mode is selected on the front and rear audio
systems at the same time, the system can be operated on the
front audio system.
If the radio mode is selected on the front and rear audio
systems at the same time, AM and FM modes cannot be
changed on the rear seat audio system.
22PY142

1Front audio system
2Rear seat audio system display
3Rear seat audio system remote control
4Headphone input jacks
5Headphone volume control dials
6Remote control holder

AUDIO
300Turning the system on and off
Push ªON/SOURCEº button to turn on the rear seat audio
system.
Use ªON/SOURCEº button to select an audio mode when the
rear seat audio system is on. Each time you push this button,
the system changes between the radio, cassette player and
CD player.
When
you change the mode, the display indicates which mode
is selected.
When a cassette tape and CDs are not loaded in the front audio
system, only a radio mode can be selected in the rear seat
audio system.
If you push ªON/SOURCEº button on rear seat audio system
remote control to select the casette tape player mode or CD
player mode in that case, a beep sounds from front audio
system and ªINVALIDº flashes on the screen for 6 seconds,
and then the rear audio system returns to the radio mode. If you push ªON/SOURCEº button while receiving an
emergency
broadcast, a beep sounds and ªINV ALIDº appears
on the screen to indicate that no button can be operated.
Push the ªOFFº button to turn off the rear audio system.

AUDIO
324
Front audio system operation
All the modes of the front audio system can be operated on the
rear seat entertainment system.
When the same mode is selected on the front and rear audio
systems simultaneously, the system can be operated on the
front audio system.
If the radio mode is selected on the front and rear audio
systems at the same time, AM and FM modes cannot be
changed on the rear seat audio system.
Selecting the mode
Use the joy stick to select the mode. Push the ªENTº
button to enter the mode.
The mode display which is selected by the joy stick is
colored blue. When the ªENTº button is pushed, the mode
display changes to green. If the mode display is gray, it
cannot be selected.
The ªSpeaker soundº on the mode display is selected on the
front audio system.
When you select a mode, the screen indicates which is
selected.

AUDIO
342
DVD video/DVD audio player operation
NOTE: The playback condition of some DVD discs may be
determined by a DVD software producer. This DVD player
plays a disc as the software producer intended. So, some
functions may not work properly. Be sure to read the
instruction manual for the DVD disc separately provided.
For the detailed information about DVD video discs, see
ªDVD video disc informationº on page 375.
Precautions for DVD video discs
When recording on a DVD video, DVD audio, video CD or
audio tracks may not record in some cases while the menu is
displayed. As audio will not play in this case, verify that the
video tracks are playing and then activate playback.
When playback of a disc is completed:
 If an audio CD is playing, the first track starts.
 If a DVD video, DVD audio or video CD is playing, playback
will stop or the menu screen will be displayed.
The title/chapter number and playback time display may not
appear while playing back certain DVD video discs.CAUTION
Conversational speech on some DVDs is recorded at a
low volume to emphasize the impact of sound effects.
If you adjust the volume assuming that the
conversations represent the maximum volume level
available for the DVD, you may be startled by louder
sound effects or when you change to a different audio
source. Loud sounds may have a significant impact on
the human body or pose a driving hazard. Keep this in
mind when you adjust the volume.

AUDIO
352(j) Changing angle screen
22PY072

1For DVD video2For DVD audio
3Remote control button
Push the ªAngleº switch on the screen or the ªANGLEº
button on the remote control, and the changing angle
screen will appear.
The angle can be selected for discs that are multi±angle
compatible
when the ªº mark appears on the screen. Each
time you push the ªAngleº switch, the angle changes. The
angle number which you can select will appear on the screen.
Push the ªBackº switch to return to the previous screen.

AUDIO
358
Push the number for the password and the ªEnterº switch. The
ªSelect Restriction Levelº screen will appear.
If you enter a wrong number, push the ªClearº switch to delete
the number.
You cannot change the setting without inputting the password.
When you forget or change the password, push the ªClearº
switch ten times to initialize the password.
To return to the ªSetup Menu 1º screen, push the ªBackº switch.Push a parental level (1 Ð 8). The smaller the level number,
the stricter the age limit. Push the ªBackº switch to return to the
ªSetup Menu 1º screen.

AUDIO
359
(q) Setting the display mode
Each time you push the ªDisplay Modeº switch on the
ªSetup M
enu 2º screen, the display mode is changed from
wide mode to auto mode. (r) Language code list
Code
Language
1001Japanese
0514English
0618French
0405German
0920Italian
0519Spanish
2608Chinese
1412Dutch
1620Portuguese
1922Swedish

AUDIO
384Radio reception
Usually, a
problem with radio reception does not mean there is
a problem with your radio Ð it is just the normal result of
conditions outside the vehicle.
For example, nearby buildings and terrain can interfere with
FM reception. Power lines or telephone wires can interfere
with AM signals. And of course, radio signals have a limited
range. The farther you are from a station, the weaker its signal
will be. In addition, reception conditions change constantly as
your vehicle moves.
Here are some common reception problems that probably do
not indicate a problem with your radio: FM
Fading
and drifting stations Ð Generally, the effective range
of FM is about 40 km (25 miles). Once outside this range, you
may notice fading and drifting, which increase with the distance
from the radio transmitter. They are often accompanied by
distortion.
Multi±path Ð FM signals are reflective, making it possible for
two signals to reach your antenna at the same time. If this
happens, the signals will cancel each other out, causing a
momentary flutter or loss of reception.
Static and fluttering Ð These occur when signals are
blocked by buildings, trees, or other large objects. Increasing
the bass level may reduce static and fluttering.
Station swapping Ð If the FM signal you are listening to is
interrupted or weakened, and there is another strong station
nearby on the FM band, your radio may tune in the second
station until the original signal can be picked up again.

STARTING AND DRIVING
396
ENGINE EXHAUST CAUTIONCAUTION
Avoid inhaling the engine exhaust. It contains
carbon monoxide, which is a colorless and odorless
gas. It can cause unconsciousness or even death.
 Make sure the exhaust system has no holes or loose
connections. The system should be checked from
time to time. If you hit something, or notice a change
in the sound of the exhaust, have the system checked
immediately.
 Do not run the engine in a garage or enclosed area
except for the time needed to drive the vehicle in or
out. The exhaust gases cannot escape, making this
a particularly dangerous situation.
 Do not remain for a long time in a parked vehicle with
the engine running. If it is unavoidable, however, do
so only in an unconfined area and adjust the heating
or cooling system to force outside air into the vehicle.
 Keep the back door closed while driving. An open or
unsealed back door may cause exhaust gases to be
drawn into the vehicle.
