Lexus GX470 2005 Pictorial Index / LEXUS 2005 GX470 OWNER'S MANUAL (OM60B11U)

AUDIO
330(b) Selecting a desired CD
Searching for a desired CD:
Push the ªº and ªº
(DISC/CH/PROG) button to select the CD number.
Push the button several times until the desired CD number
appears on the display. When you release the button, the
player will start playing the selected CD from the first track. (c) Selecting a desired trackTo select a desired track: Push the ªº or ªº
(TUNE/TRACK) button until the number of the track you want
to listen to appears on the screen. If you want to return to the
beginning of the current track, quickly push the ª
º
(TUNE/TRACK) button one time.
ªFast forwardº button: Push the ª
º (TUNE/TRACK) button
and hold it to fast forward the CD. When you release the
button, the CD player will resume playing from that position.
ªReverseº button: Push the ª
º (TUNE/TRACK) button and
hold it to reverse the CD. When you release the button, the CD
player will resume playing.

AUDIO
331
Replacing remote control battery
For replacement, use a CR2025 lithium battery or equivalent.CAUTION
Special care should be taken that small children do not
swallow the removed battery or components.
NOTICE
When replacing the battery, be careful not to lose thecomponents.
Replace only with the same or equivalent type ofbattery recommended by a Lexus dealer.
Dispose of used batteries according to localregulations.

AUDIO
332
1. Pull the case out while pushing the lock release button to the
side.2. Remove the discharged battery.
3. Put in a new battery with the positive (+) side up.
4. Put it in the case securely.

AUDIO
333
NOTICE
Be sure that the positive side of the remote controlbattery is facing correctly.
Do not replace the battery with wet hands. Water may
cause rust.
Do not touch or move any components inside of the remote control, or it may interfere with properoperation.
Be careful not to bend the electrode of the remotecontrol battery insertion and that dust or oil does not
adhere to the transmitter case.
Close the battery case securely.
After replacing the battery, check that the remote control
operates properly. If the remote control still does not operate
properly, contact your Lexus dealer.DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dts±CDs, DVD audio discs and video CDs.
For appropriate discs for this player, see ªAudio/video system
operating hintsº on page 383.
The DVD player works when the ignition key is in the ªACCº or
ªONº position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc

AUDIO
334
1. Push the center of the rear console box lid.2. Push this button to open the cover.
3. Pull the lid forward.

AUDIO
335
4. Insert a disc with the label side backward and close the
lid.
The player is intended for the use with 12 cm (4.7 in.) discs only.
If the label faces forward, the disc cannot be played. In this
case, ªDISC CHECKº appears on the screen.
If a disc which is not playable is inserted, ªDISC CHECKº will
also appear on the screen. For appropriate discs for this
player, see ªAudio/video system operating hintsº on page 383.The indicator light turns on while the disc is loaded.
The player will play the track or chapter, and it will play from the
beginning of the track or chapter again after it reaches the end.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the console box closed
while driving.
NOTICE
Never try to disassemble or oil any part of the DVD
player. Do not insert anything other than a disc into the
slot.
5. Close the cover and console box. (b) Ejecting the disc

AUDIO
336
Pull the lid forward to open the DVD player. Push the disc
eject button to eject a disc.
NOTICE
Do not place anything on the opened cover. It could
damage the cover.

AUDIO
337
(c) Selecting the DVD mode

1Remote control button
2Mode selection screen
To select the DVD mode, push the ªDVDº button on the
remote control.
You can also select the DVD mode on the mode selection
screen mentioned above.
ªDVDº appears on the screen.
The ªDVD Hint!º screen appears when the DVD mode is
first selected after you turn the ignition key to the ªACCº
or ªONº position.
Push the ªOKº switch when you read the message.

AUDIO
338(d) DVD player operation switches
The DVD player can be operated with the remote control
buttons directly.
The player can also be operated with the switches on the
screen.
To operate the switches on the screen, select the switch by the
joy stick and push the ªENTº button. You cannot select the
switches on the screen by touching them directly.
When the switch is selected by the joy stick, the outline of the
switch
changes to blue. Push the ªENTº button, and the switch
will be highlighted in green.

AUDIO
339
(e) Turning the operation switches on and off
To turn on the operation switches, push the ªCURSORº
button on the remote control.
