STARTING AND DRIVING
421
4Resetting to a slower speed
Press the control lever downward in the ª± SETº direction and
hold it. Release the lever when the desired speed is attained.
While the lever is held downward, the vehicle speed will
gradually decrease.
When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
lowered 1.6 km/h (1 mph) each time by pressing the control
lever downward in the ª± SETº direction quickly.
However, a quicker way to reset is to depress the brake pedal
and then press the control lever downward in the ª± SETº
direction.
Even if you downshift the transmission from the ªDº position to
ª4º position with the cruise control on, engine braking will not
be applied because the cruise control is not cancelled. To
decrease the vehicle speed, reset to a slower speed with the
cruise control lever or depress the brake pedal. If you use the
brake pedal, cruise control is cancelled.
5Resuming the preset speed
If the preset speed is cancelled by pulling the control lever or
by depressing the brake pedal, pushing the lever up in the ª+
RESº direction will restore the speed set prior to cancellation.
Cruise control failure warning
If the ªCRUISEº indicator light in the instrument cluster flashes
when using the cruise control, push the ºON±OFFº button to
turn the system off and then push it again to turn it on.
If any of the following conditions then occurs, there is some
trouble in the cruise control system.
 The indicator light does not come on.
 The indicator light flashes again.
 The indicator light goes out after it comes on.
If this is the case, contact your Lexus dealer and have your
Lexus inspected.

STARTING AND DRIVING
422
REAR HEIGHT CONTROL AIRSUSPENSION
This rear height control air suspension controls the
vehicle height depending on the vehicle driving condition.
Select your desired height among the ªHIº (high), ªNº
(normal) and ªLOº (low) modes with the height select
switch.
(a) Vehicle height modes
ªNº (normal) mode: The vehicle height in this mode is
standard. Regardless of the number of occupants or the
luggage loading condition, the vehicle height is always
automatically adjusted to a fixed height in any mode while the
engine is running.
This mode is suitable for ordinary driving. ªHIº
(high) mode: The vehicle height is about 40 mm (1.6 in.)
higher at the rear than the ªNº mode height.
This mode is suitable when driving on the bumpy roads and
through water.
However, when the vehicle speed exceeds about 30 km/h (19
mph) or over in the ªHIº mode, the ªNº mode is automaticall\
y
selected.
CAUTION
The ªHIº mode should be used for severe off±road
driving condition only. As the vehicle's center of gravity
is higher in this setting, the vehicle may become
unstable when turning abruptly resulting in accident.
ªLOº (low) mode: The vehicle height is about 20 mm (0.8 in.)
lower at the rear than the ªNº mode height.
This mode allows you easy access to the vehicle (getting in and
out) and easy loading and unloading operation.
This mode is available when the vehicle speed is under about
12 km/h (7 mph).

STARTING AND DRIVING
423
NOTICE
Use the ªLOº mode when the vehicle is stopped.Otherwise, when the vehicle speed exceeds about 12km/h (7 mph), ªNº mode is selected automatically. Sobe careful when you drive in any place where theoverhead height is limited.
(b) Vehicle height mode changing condition
To change the vehicle height, it is necessary to meet the
following conditions.
 The engine should be running.
 The height control ªOFFº indicator light should go off.
When selecting a mode, there is a vehicle speed limit. Refer
to the following table.
Yes = The mode can be selected.
No = The mode cannot be selected.
ªLOº
modeªNº
modeªHIº
mode
Under about
12 km/h (7 mph)Ye sYe sYe s
Under about
30 km/h (19 mph)NoYe sYe s
About 30 km/h
(19 mph) or overNoYe sNo

STARTING AND DRIVING
424In the following cases, the rear height control suspension
will not operate.

The underbody of the vehicle has touched the surface on
bumpy roads.
 The area around the rear suspension is coated with ice.
If the vehicle is moved to its usual location or the ice is removed
and the height select switch is pressed, the vehicle height
control cannot be operated. In this case, turn off and restart the
engine, then push the control switches.
(c) Vehicle height adjustment

1Higher2Lower
To change the mode, push the height select switch on
either side of ª º (higher) or ªº (lower). The height control indicator light indicates which mode is
selected. (See ª(e) Height control indicator lightº described
below.)

Selecting the ªHIº mode
Push the height select switch on the ª º side when the vehicle
speed is under about 30 km/h (19 mph).
To change the ªNº mode to ªHIº: Push the switch once.
To change the ªLOº mode to ªHIº: Push the switch twice. It
takes about 30 se conds until the ªLOº mode changes to the ªHIº
mode.
 Selecting the ªNº mode
To change the ªHIº mode to ªNº: Push the height select
switch on the ª º side once.
To change the ªLOº mode to ªNº: Push the height select
switch on the ª º side once.
 Selecting the ªLOº mode
Push the height select switch on the ªº side while the vehicle
is stopped.
To change the ªNº mode to ªLOº: Push the switch once.
To change the ªHIº mode to ªLOº: Push the switch twice.
Even if the engine is stopped while the vehicle height is being
lowered, the operation continues for up to 25 seconds. If within
this 25 seconds, any of the side doors or the back door is
opened, operation will continue for a further 15 seconds.

STARTING AND DRIVING
426
(d) Turning off the rear height control airsuspension
To turn off the rear height control air suspension with the
vehicle stopped, push the ªHEIGHT CONTROL OFFº
switch. The height control ªOFFº indicator light comes on
and the vehicle height is fixed in the same mode as the
height control switch is pushed.
This status is memorized in the system even after the engine
is stopped.
If you push the switch again, the height control ªOFFº indicator
light goes out and the rear height control air suspension is
turned on.
Even after the rear height control air suspension is turned off
with the ªHEIGHT CONTROL OFFº switch, if the vehicle speed
exceeds 30 km/h (19 mph), the rear height control air
suspension automatically selects the ªNº mode.
CAUTION
If you drive through deep water over about 700 mm (28
in.) in depth, put the vehicle height in the ªHIº mode with
the height select switch and then turn off the rear height
control air suspension by pushing the ªHEIGHT
CONTROL OFFº switch.

STARTING AND DRIVING
427
NOTICE
When jacking up or installing tire chains, be sure toturn off the rear height control air suspension withthe ªHEIGHT CONTROL OFFº switch and stop theengine. Otherwise, the vehicle height may changebecause of the automatic leveling function resultingin accident.
If your vehicle must be towed, put the vehicle heightin the ªNº mode and turn off the rear height control airsuspension. Otherwise, the vehicle height may
change because of the automatic leveling functionresulting in accident.
If your vehicle gets ditched, turn off the rear heightcontrol air suspension with the ªHEIGHT CONTROLOFFº switch. Otherwise, the vehicle height maychange because of the automatic leveling functionresulting in accident.

STARTING AND DRIVING
429
(f) Parking and stopping tips
If you immediately stop the engine to park the vehicle after
off±road driving, the vehicle height is lowered slightly as the
vehicle becomes cool. When parking, make sure there is
nothing that will be in contact with the underbody of the vehicle.
When you start the engine, the vehicle returns to the previous
height.
If you park the vehicle for a long time, the vehicle height may
be gradually lowered. When parking for a long time, make sure
there is nothing that will be in contact with the underbody of the
vehicle. When you start the engine, the vehicle returns to the
previous height.
If you stop the engine, the vehicle height may change in
accordance with the change in the temperature. When you
start the engine, the vehicle returns to the previous height.
(g) Rear height control failure warning
If there is a problem somewhere in the rear height control air
suspension, the ªNº mode is automatically selected. If this
occurs, the height control ªOFFº indicator light blinks and the
vehicle height control cannot be activated until the malfunction
is corrected. If this is the case, bring your vehicle to your Lexus
dealer as soon as possible and have it checked.
ELECTRONIC MODULATED SUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1For driving on a bumpy road
2For ordinary driving such as in the city traffic
3For moderate high speed driving
4For sporty type driving such as on winding mountain
roads and high speed driving
5Soft
6Firm

STARTING AND DRIVING
431

Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the active traction control
system is in the self±check mode, but does not indicate a
malfunction.
When the active traction control system is operating, the
following conditions occur:
 The system controls the spinning of the 4 wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly. The slip indicator light comes on for a few seconds when the
ignition key is turned to ªONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
The brake actuator temperature increase during continuous
operation of the following systems.

Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill±start assist control
If the brake actuator temperature becomes too high while any
of the systems is operating, a buzzer will start to sound
intermittently to indicate that the active traction control system
can no longer operate. In this case, immediately stop your
vehicle at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At the time, the slip indicator light
will come on and the active traction control system temporarily
stops operating in order to protect the brake actuator.
(Although the active traction control system does not operate,
there is no problem to continue your driving.) The system will
be automatically restored after a short time and the slip
indicator light goes out.

STARTING AND DRIVING
433
VEHICLE STABILITY CONTROLSYSTEM
The vehicle stability control system helps provide
integrated control of the systems such as anti±lock brake
system, traction control, engine control, etc. This system
automatically controls the output of the brakes or engine
to help prevent the vehicle from skidding when cornering
on a slippery road surface or operating steering wheel
abruptly.
This system activates when the vehicle speed about more than
15 km/h (9mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the system is in the
self±check mode, but does not indicate a malfunction.
CAUTION
 Do not rely excessively on the vehicle stability
control system. Even if the vehicle stability control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks and an alarm sounds,
special care should be taken while driving.
Only use tires of specified size. The size,
manufacturer, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle
stability control system may not function correctly.
When replacing the tires or wheels, contact your
Lexus dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.

Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.

STARTING AND DRIVING
436
The warning light comes on while driving.
DOWNHILL ASSIST CONTROL
SYSTEM
The downhill assist control system is a system that
assists the deceleration of the engine brake when you
drive down a steep hill. When you are driving down a hill
with the four±wheel drive control lever in the ªLº position,
push the ªDACº switch to limit the vehicle's acceleration.
If the vehicle is traveling at a speed of 25 km/h (15 mph) or
less, you can descend at a constant speed.
CAUTION
Do not rely excessively on the downhill assist control
system. It may not be able to maintain a low speed over
road surf aces or off±road surfaces on which sliding can
easily occur, such as extremely steep slopes or icy or
muddy roads.
Turning on the system
1. Shift the four±wheel drive control lever to the ªLº
position.
The system will not operate if the four±wheel drive control lever
is in the ªHº position.
2. In order to make full use of the engine brake, putting the
transmission in ªLº or ª2º is recommended.
The system will operate even if the transmission selector lever
is in ªDº, ª4º, ª3º or ªNº. However, when it is in ªLº or ª2º the
engine brake can also be utilized enabling the system to
operate more effectively.
3. Push the ªDACº switch to turn the system on. The
downhill assist control system indicator light on the
instrument panel will come on.
