remote control Lexus GX470 2005 Scheduled Maintenance Guide / LEXUS 2005 GX470 (OM60B11U) Owner's Guide

AUDIO
308
NOTICE
Make sure that the positive side of the remote control
battery is facing correctly.
Do not replace the battery with wet hands. Water may
cause rust.
Do not touch or move any components inside of the remote control, or it may interfere with properoperation.
Be careful not to bend the electrode of the remotecontrol battery insertion and that dust or oil does not
adhere to the transmitter case.
Close the battery case securely.
After replacing the battery, check that the remote control
operates properly. If the remote control still does not operate
properly, contact your Lexus dealer.Headphone input jacks
To use the jack, push the lid.

AUDIO
311
REAR SEAT ENTERTAINMENTSYSTEM
22PY140

1Front audio system
2Rear seat entertainment system display
3Rear seat entertainment system remote control
4DVD player
5Power outlet
6Input terminal adapter
7Headphone volume control dials
8Headphone input jacks
9Remote control holder
10Power outlet main switch

AUDIO
314
Rear seat entertainment system remote
control
The rear seat entertainment system can be operated with
the rear seat entertainment system remote control. The
system cannot be operated by touching the switches on
the screen directly.
CAUTION
Do not disassemble or modify the remote control. It
may cause an accident, fire or electric shock.
NOTICE
Keep the remote control away from direct sunlight, high
heat and high humidity. These conditions could cause the case to deform or the battery to explode or leak.

AUDIO
315
(a) Before using the remote control (for new vehicle
owners)
A battery is already set in the remote control with an
insulating sheet, which prevents the battery from being
discharged. Before using the remote control, remove the
insulating sheet.
(b) Using the remote controlTo use the rear seat entertainment system remote control,
direct the si
gnal output portion of the remote control to the
signal reception portion of the rear seat entertainment
system display.
The remote control does not operate properly when the signal
reception portion of the display is exposed to direct sunlight.
Block the display from direct sunlight.

AUDIO
316
NOTICE
Observe the followings, otherwise the remote controlmay be damaged.
Do not drop or strongly knock the remote controlagainst hard objects.
Do not sit on or place heavy objects on the remotecontrol.

AUDIO
317
(c) Remote control holder
The remote control can be stowed in the holder when it is
not in use. The holder can be hooked on the back of the
driver's or front passenger's seatback.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop while driving, stow the remote control in
the holder when it is not in use.

AUDIO
318
NOTICE
Do not leave the remote control exposed to hightemperatures (such as on the instrument panel) for along time, otherwise the remote control may bedamaged.

AUDIO
319
Quick reference for your remote control
22PY153

AUDIO
331
Replacing remote control battery
For replacement, use a CR2025 lithium battery or equivalent.CAUTION
Special care should be taken that small children do not
swallow the removed battery or components.
NOTICE
When replacing the battery, be careful not to lose thecomponents.
Replace only with the same or equivalent type ofbattery recommended by a Lexus dealer.
Dispose of used batteries according to localregulations.

AUDIO
333
NOTICE
Be sure that the positive side of the remote controlbattery is facing correctly.
Do not replace the battery with wet hands. Water may
cause rust.
Do not touch or move any components inside of the remote control, or it may interfere with properoperation.
Be careful not to bend the electrode of the remotecontrol battery insertion and that dust or oil does not
adhere to the transmitter case.
Close the battery case securely.
After replacing the battery, check that the remote control
operates properly. If the remote control still does not operate
properly, contact your Lexus dealer.DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dts±CDs, DVD audio discs and video CDs.
For appropriate discs for this player, see ªAudio/video system
operating hintsº on page 383.
The DVD player works when the ignition key is in the ªACCº or
ªONº position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc
