OCCUPANT RESTRAINT SYSTEMS
194
FRONT PASSENGER OCCUPANTCLASSIFICATION SYSTEM
Your vehicle is equipped with a front passenger occupant
classification system. This system detects the conditions
1 Ð 4 in the table shown below, and based on these
conditions activates or deactivates the airbags. The
system monitors the weight and load on the front
passenger seat, and the seat belt buckle switch in
determining conditions 1 Ð 4.
In order for the system to detect the conditions correctly,
do not do any of the following:
 Apply a heavy load to the front passenger seat or equipment
(e.g. armrest).
 Attach a commercial seatback table, etc. to the front
passenger seatback.
 Put weight on the front passenger seat by putting your
hands or feet on the seat seatback from the rear passenger
seat.
The ªAIRBAG OFFº indicator lights will be illuminated
when the ignition switch is in the ªONº position and a child
or child restraint system is in the front passenger seat (see
table±condition 2). This indicates that in the event of a
severe frontal or passenger's side impact, the front
passenger airbag and side airbag on the front passenger
seat are deactivated and will not deploy.

OCCUPANT RESTRAINT SYSTEMS
196
Condition and operation in the front passenger occupant classification s\
ystem
Indicator/warning lightDevices
Condition detectedby the front
passenger occupant
classification systemªAIRBAG ONº and
ªAIRBAG OFFº
indicator lights
SRS
warning light
Front
passenger's seat belt
reminder light
Front
passenger airbagSide airbag
on the frontpassenger seatCurtain
shield airbag in the frontpassenger sideFront
passenger's seat belt
pretensioner
1Adult*1ªAIRBAG ONºOffFlashing*4Activated
2Child *2 or child
restraint system*3ªAIRBAG OFFºOffFlashing*4DeactivatedActivated
3UnoccupiedNot
illuminatedOffOffDeactivatedActivatedDeactivated
4There is a
malfunction in the
systemªAIRBAG OFFºOnOffDeactivatedActivated
*1: The system judges a person of adult size as an adult. When a smaller ad\
ult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture.
*
2: When a lar ger child who has outgrown a child restraint system sits in the front pa\
ssenger seat, the system may recognize him/her
as an adult depending on his/her physique or posture.
*
3: Never install a rear±facing child restraint system on the front passe\
nger seat. A forward±facing child restraint system shoul d
only be installed on the front passenger seat when it is unavoidable. (\
See ªChild restraint systemº on page 202 as for install ing
the child restraint system.)
*
4: In the event the front passenger does not wear a seat belt.

STEERING WHEEL AND MIRRORS
234
Folding rear view mirrors
To fold the rear view mirror, push backward.
The rear view mirrors can be folded backward for parking in
compact areas.
CAUTION
Do not drive with the mirrors folded backward. Both the
driver and passenger side rear view mirrors must be
extended and properly adjusted before driving.
INSIDE REAR VIEW MIRROR
Adjust the mirror so that you can just see the rear of your
vehicle in the mirror.
Pushing the ªMIRRORº switch changes the mode
between AUTO and DAY.
The indicator comes on when the automatic function mode is
selected.
DAY mode: The mirror surface is normal.
AUTO mode: If the mirror detects light from the headlights
of the vehicle behind you, the mirror surface darkens
slightly to reduce the reflected light.
When the ignition key is inserted and turned on, the inside rear
view mirror always turns on in the automatic function mode.

STEERING WHEEL AND MIRRORS
235
When the outside air temperature is low, it may take a little
longer for the mirror to darken in response to the detection of
headlights.
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the vehicle
and an accident may occur resulting in death or serious
injuries.
To ensure correct functioning of anti±glare mirror sensors
located on both sides of the mirror, do not touch or cover
the sensors with your finger or a piece of cloth, etc.
Compass
The compass indicates the direction in which the vehicle
is heading. The illustration shown above indicates the
vehicle is heading north.
Push the ªCOMPº switch to turn the compass system on
and off.
If the ignition switch was turned off with the system on, the
system
will automatically turn back on when the ignition switch
is turned on.

STARTING AND DRIVING
401
To set: Pull up the lever. For better holding power, first
depress the brake pedal and hold it while setting the
parking brake.
To release: Pull up the lever slightly (
1), press the lock
release button (2), and lower the lever (3).
Before leaving your vehicle, firmly apply the parking brake. For
better holding power, first depress the brake pedal and hold it
while setting the parking brake.
CAUTION
Before driving, make sure the parking brake is fully
released and that the parking brake reminder light is off.
HOW TO START THE ENGINE
Cranking hold function
Once you turn the ignition key to ªSTARTº position and release
it, the cranking hold function continues to crank the engine in
ªONº position until it starts.
The function stops cranking the engine after about 25 seconds
maximum if the engine has not started yet. When you crank
the engine again, wait a few seconds and restart it.
If you hold the key in ªSTARTº position, the function will keep
cranking for about 30 seconds maximum.
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in ªPº. If you need to restart the engine
while the vehicle is moving, put the selector lever in ªNº. A
starter safety device will prevent the starter from operating if
the selector lever is in any drive position.
4. Depress the brake pedal and hold it to the floor until driving
off.

STARTING AND DRIVING
411
(g) If you cannot shift the selector lever
If you cannot shift the selector lever even though the brake
pedal is depressed, use the shift lock override button. For
instructions, see ªIf you cannot shift automatic transmission
selector leverº on page 524.
(h) Driving in second start mode
In the second start mode, the transmission system shifts up
from second gear. Use this mode when starting your vehicle
in sand, mud, ice or snow.
To set the second start mode, push the ª2nd STRTº switch. In
the second start mode, the ª2nd STRTº indicator light comes
on. To cancel the second start mode, push the ª2nd STRTº
switch once again.
FOUR±WHEEL DRIVE SYSTEM
(a) Four±wheel drive control
Use the four±wheel drive control lever and center
differential lock switch to select the following transfer and
center differential modes.
The ªHº and ªLº position of the four±wheel drive control leve\
r
provides either lock or unlock mode of the center differential
depending on the center differential lock switch position.
Use the center differential lock system if your wheels get stuck
in a ditch, or when you are driving on a slippery or bumpy
surface. When the center differential is locked, the vehicle
stability control system is automatically turned off and the
center dif ferential lock and ªVSC OFFº indicator lights come on
because the function that controls engine performance
interferes with the process of freeing your wheels.

STARTING AND DRIVING
418THE REAR VIEW MONITOR SYSTEM CAMERA
The rear view monitor system camera is located on the back
door as shown in the illustration. The camera uses a special
lens. The distance of the image that appears on the screen
differs from the actual distance.
In the following cases, it may become difficult to
see the images
on the screen, even when the system is functioning.
 In the dark (for example, at night)
 When the temperature near the lens is extremely high or low
 When water droplets are adhering to the camera, or when
humidity is high (for example, when it rains)
 When foreign matter (for example, snow or mud) adheres
to the camera lens
 When the sun or the beam of headlights is shining directly
into the camera lens
Check surroundings for safety.
If a bright light (for example, sunlight reflected off the vehicle
body) is picked up by the camera, the smear effect* peculiar to
the camera may occur.
*: Smear effect Ð A phenomenon that occurs when a bright
light (for example, sunlight reflected off the vehicle body) is
picked up by the camera; when transmitted by the camera, the
light source appears to have a vertical streak above and below
it.

STARTING AND DRIVING
428
(e) Height control indicator lights

1Height control indicator lights
2Height control ªOFFº indicator light
When the ignition switch is turned on, all the indicator lights
come on. Only the indicator light showing the present mode
remains on and all other lights go off after a few seconds. This
means the system operates correctly.
When you change the vehicle height mode, the indicator lights
change as follows:
When changing the vehicle height from the ªNº mode to
ªHIº:
1. The ªNº mode indicator light goes off and the ªHIº mode
indicator light blinks.
2. After the vehicle height control reaches the ªHIº mode, the
ªHIº mode indicator light remains on. If the underbody of the vehicle has touched the surface on
bumpy roads or the area around the rear suspension is
coated with ice, the height control suspension will not
operate and the indicator lights change as follows:
1. The present mode indicator light goes off and the selected
mode indicator light blinks.
2. The selected mode indicator light goes off. (The vehicle
height does not change.) The present mode indicator light
comes on again.
Height control ªOFFº indicator light: When the ignition
switch is t
urned on, this light comes on. If it goes out after a few
seconds, the rear height control air suspension operates
correctly. If you push the ªHEIGHT CONTROL OFFº switch,
the rear height control air suspension is turned off. The height
control ªOFFº indicator light comes on.
In the following cases, there is a problem somewhere in the
rear height control air suspension. Although there is no
problem to continue normal driving, have the rear height
control air suspension checked by your Lexus dealer as soon
as possible.
 The height control ªOFFº indicator light does not come on
when the ignition switch is turned on.
 The height control ªOFFº indicator light blinks.

STARTING AND DRIVING
437
If the downhill assist control system indicator light flashes, the
transmission selector lever may be in ªNº or four±wheel drive
control lever may be in the ªHº position.
If the indicator light does not come on when the switch is
pushed, contact your Lexus dealer.

Slip indicator light
With the vehicle traveling at a speed of 25 km/h (15 mph) or
less, release your foot from the accelerator or brake pedal to
activate the system. The vehicle will descend the hill at a low
speed. While the system is operating, the slip indicator light on
the instrument panel will flash and the stop lights and high
mounted stoplight will be lit.
If you push the ªDACº switch to turn the system off while it is
in operation, the system will stop operating gradually. The
downhill assist control system indicator light will flash to alert
the driver. To continue driving at a low speed, push the ªDACº
switch to turn the system on.
The slip indicator light and downhill assist control system
indicator l
ight come on for a few seconds when the ignition key
is turned to ªONº. If any of the indicator lights does not come
on when the ignition is turned on, contact your Lexus dealer.
The brake actuator temperature increases during continuous
operation of the following systems.
 Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill±start assist control
If the brake actuator temperature becomes too high while any
of the systems is operating, a buzzer will start to sound
intermittently to indicate that the downhill assist control system
can no longer operate. In this case, stop your vehicle
immediately at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At this time, the slip indicator light
will come on and the downhill assist control system stops
operating temporarily in order to protect the brake actuator.
(Although the downhill assist control system does not operate,
it is no problem to continue your driving.) The system will be
automatically restored after a short time and the slip indicator
light goes out.

DRIVING TIPS
478
Tires
Ensure that your vehicle's tires are properly inflated. Adjust
the tire inflation pressure to the recommended cold tire
inflation pressure indicated below.
Tire inflation pressure: 220 kPa (2.2 kgf/cm
2 or bar, 32 psi)
 The trailer tires should be inflated to the pressure
recommended by the trailer manufacturer in respect to the
total trailer weight.
Trailer lights
Your vehicle is equipped with a wire harness stored in the rear
end underbody. Use either of them to connect and operate the
trailer lights. However, the trailer lights must comply with
federal, state/provincial and local regulations. See your local
recreational vehicle dealer or rental agency for the correct type
of wiring and relays for your trailer. Check for correct operation
of the turn signals and stop lights each time you hitch up. Direct
splicing may damage your vehicle's electrical system and
cause a malfunction of your lights.
Break±in schedule
Lexus recommends that you do not tow a trailer with a new
vehicle or a vehicle with any new power train component
(engine, transmission, differential, wheel bearing, etc.) for the
first 800 km (500 miles) of driving.
Maintenance
 If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. For this
information, please refer to the scheduled maintenance
information in the ªOwner's Manual Supplement/Scheduled
Maintenanceº.
 Retighten all fixing bolts of the towing ball and bracket after
approximately 1000 km (600 miles) of trailer driving.
