GAUGES, METERS AND SERVICE REMINDER INDICATORS
73
(q) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(r) Key Reminder Buzzer
This buzzer acts as a reminder to remove the key when you
open the driver's door with the ignition key in the ªACCº or
ªLOCKº position.
How to check all the service reminder
indicators (except the low fuel level warning
light)
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four±wheel drive control lever in ªNº position and
the selector lever in ªPº position and turn the ignition key to
ªACCº.
The following service reminder indicator should come on. It
goes off when you place the four±wheel drive control lever in
ªHº or ªLº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
744. Turn the ignition key to ªONº.
The following service reminder indicators should come on.
or

or or
w72a
w73

The following service reminder indicator goes off after a few
seconds.
or


The anti±lock brake system warning light, vehicle stability
control system off indicator light and vehicle stability control
system, slip indicator light and active traction control system
warning light may stay on for about 60 seconds after the
ignition key is turned to the ªONº position. It is normal if they
go out after a while.
The following service reminder indicator should come on. It
goes off after about 6 seconds.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
75
MULTI±INFORMATION DISPLAY
13PY018

1ªMODEº button2ªº button
3ªº button4ªRESETº button
The multi±information display provides various
information, including clock, outside temperature, and
your vehicle's driving condition.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multi±information display, the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
You can adjust the brightness of the display. To adjust the
brightness, see ªADJUSTING THE BRIGHTNESS OF THE
DISPLAYº below.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
76ADJUSTING THE BRIGHTNESS OF THE DISPLAY
The key must be in the ªACCº or ªONº position. To adjust the
brightness of the display, push and hold the ªMODEº button for
more than 2 seconds. ªILLº will appear on the display.
To increase the brightness Ð Push the ª
º button.
To decrease the brightness Ð Push the ª
º button.
You can adjust the brightness to 3 levels (when the tail lights
are off) or 6 levels (when the tail lights are on).
After adjusting, the display automatically return to the previous
display.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
Clock

U.S.A.

Canada

GAUGES, METERS AND SERVICE REMINDER INDICATORS
81

Driving range

U.S.A.

Canada
The distance the vehicle can travel with the remaining fuel
is calculated and displayed based on the quantity of
remaining fuel and past fuel consumption.
The driving range display indicates the approximate distance
that you can drive until the fuel gauge reaches ªEº. It is dif ferent
from the actual distance traveled.
The displayed value is updated every time the fuel required to
travel 1 mile or 1 km is consumed.
Every time you refuel the vehicle, the calculation is reset.
The actual driving range varies with driving habits and road
conditions. If fuel consumption is good, the driving range will
be longer. If fuel consumption is poor, the driving range will be
shorter.
If the low fuel level warning light comes on, refuel even if the
display indicates that the vehicle can be driven further.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
86
INSTRUMENT PANEL LIGHTCONTROL
To adjust the brightness of the instrument panel lights,
turn the dial.
With the dial turned fully up, the intensity of the instrument
panel lights will not be reduced when the headlight switch is on.

SECTION 1 ± 4
87
INSTRUMENTS AND CONTROLS
Interior equipment
Sun visors88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry system 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . .
Power outlets 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box 97
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener 98
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholders 102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead console box 104
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning reflector holder 108
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Coat hooks 108
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover 109
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie±down hookss 11 0
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTERIOR EQUIPMENT
88
SUN VISORS
To block out glare, move the sun visor as shown.
1To block out glare from the front, swing the sun visor
down.
2To block out glare from the side, remove the sun visor
from the hook and swing it to the side.
3To block out glare coming obliquely from behind you,
slide the visor backwards.
At this position, the vanity light does not come on.
4To block out glare from the front with the sun visor in
the position 2
or 3
, swing the other sun visor
down.
INTERIOR LIGHTS
Center
Vehicles without rear seat audio system
Vehicles with rear seat audio system

INTERIOR EQUIPMENT
89
To turn on the interior light, slide the switch.
The interior light switch has the following positions:
ªONº Ð Keeps the light on all the time.
ªOFFº Ð Turns the light off.
ªDOORº Ð Turns the light on when any side door is opened.
The light goes off when all the doors are closed. For details,
see ªIlluminated entry systemº on page 90.
Rear
To turn on the interior light, slide the switch.
The interior light switch has the following positions:
ªONº Ð Keeps the light on all the time.
ªOFFº Ð Turns the light off.
ªDOORº Ð Turn the light on when the back door is opened.
The light goes out immediately when the back door is closed.

INTERIOR EQUIPMENT
90
PERSONAL LIGHTS
1ªDOORº position2ªOFFº position
To turn on the personal light, push the lens. To turn the
light off, push the lens once again.
The personal light switch has the following positions:
ªDOORº Ð Turn the lights on when any side door is opened
without pushing the lens. The light goes off when all the doors
are closed. For details, see ªIlluminated entry systemº on page
90.
ªOFFº Ð Turn the lights on only when you push the lens.
ILLUMINATED ENTRY SYSTEM
14PY027
