AIR CONDITIONING
229
(a) Rear cooler ONOFF
To turn the rear cooler on, push the “REAR COOL” button
with front air conditioning on. To turn the rear cooler off,
push the button once again.
When you turn the rear cooler on with the front air conditioning
off, the cooling device is not operated.
(b) Air flow control
The fan speed can be set to your desired speed by pushing
the appropriate side of the fan speed control button.
“AUTO” mode: The fan speed is automatically adjusted only
when the air flow setting of the front air conditioning is in the
panel mode.
(c) Temperature control
The temperature of the cooled air can be adjusted between
 10 F ( 5C) of the temperature of the front air
conditioning system. Push the left side of the button to
lower the temperature.
NOTICE
To prevent the battery from being discharged, do not
leave the rear cooler on longer than necessary when the
engine is not running.

AIR CONDITIONING
230

SECTION 2 – 2
231
AIR CONDITIONING AND AUDIO
Audio
Audio system232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Audio system operating hints 252
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat audio system 257
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat entertainment system 271
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 333
. . . . . . . . . . . . . . . . . . . . . . . . .
For vehicles equipped with Navigation System,
please refer to the separate “Navigation System
Owner’s Manual”.

AUDIO
254Caring for your CD player and CDs

Your CD player is intended for use with 12 cm (4.7 in.) CDs
only.
 Extremely high temperature can keep your CD player from
working. On hot days, use air conditioning to cool the
vehicle interior before you listen to a CD.
 Bumpy roads or other vibrations may make your CD player
skip.
 If moisture gets into your CD player, you may not hear any
sound even though your CD player appears to be working.
Eject all CDs from the player and wait until the player dries.
CAUTION
CD players use an invisible laser beam which could
cause hazardous radiation exposure if directed outside
the unit. Be sure to operate the player correctly.
Use only CDs marked as shown above. The following
products may not be playable on your CD player.
Copy− protected CD
CD− R (CD− Recordable)
CD−RW (CD− Re−writable)
CD−ROM
SACD
dts−CD

AUDIO
335
Use high−
quality cassettes.
 Low−quality cassette tapes can cause many problems,
including poor sound, inconsistent playing speed, and
constant auto−reversing. They can also get stuck or tangled
in the cassette player.
 Do not use a cassette if it has been damaged or tangled or
if its label is peeling off.
 Do not leave a cassette in the player if you are not listening
to it, especially if it is hot outside.
 Store cassettes in their cases and out of direct sunlight.
 Avoid using cassettes with a total playing time longer than
100 minutes (50 minutes per side). The tape used in these
cassettes is thin and could get stuck or tangled in the
cassette player.
Caring for your CD player, DVD player and CDs
 Your CD player and DVD player are intended for use with 12
cm (4.7 in.) CDs only.
 Extremely high temperatures can keep your CD player and
DVD player from working. On hot days, use the air
conditioning to cool the vehicle interior before you use the
players.
 Bumpy roads or other vibrations may make your CD player
and DVD player skip.
If moisture gets into your CD player and DVD player, the
players may not play even though they appear to be
working. Remove the CD from the player and wait until it
dries.
CAUTION
CD players and DVD players use an invisible laser beam
which could cause hazardous radiation exposure if
directed outside the unit. Be sure to operate the players
correctly.

DRIVING TIPS
415

Avoid jerky starts or sudden acceleration.
 Avoid jerky steering and sharp turns. The trailer could hit
your vehicle in a tight turn. Slow down before making a turn
to avoid the need of sudden braking.
 Remember that when making a turn, the trailer wheels will
be closer than the vehicle wheels to the inside of the turn.
Therefore, compensate for this by making a larger than
normal turning radius with your vehicle.
 Crosswinds and rough roads will adversely affect handling
of your vehicle and trailer, causing sway. Pay attention to
the rear from time to time to prepare yourself for being
passed by large trucks or buses, which may cause your
vehicle and trailer to sway. If swaying happens, firmly grip
the steering wheel and reduce speed immediately but
gradually. Never increase speed. If it is necessary to
reduce speed, brake slowly. Steer straight ahead. If you
make no extreme correction with the steering or brakes,
your vehicle and trailer will stabilize.
 Be careful when passing other vehicles. Passing requires
considerable distance. After passing a vehicle, do not forget
the length of your trailer and be sure you have plenty of room
before changing lanes.
 In order to maintain efficient engine braking and electrical
charging performance, do not use overdrive. Transmission
must be “4” position.
Because of the added load of the trailer, your vehicle’s
engine may overheat on hot days (at temperatures over
30C [85 F]) when going up a long or steep grade with a
trailer. If the engine coolant temperature gauge indicates
overheating, immediately turn off the air conditioning (if in
use), pull your vehicle off the road and stop in a safe spot.
See “If your vehicle overheats” on page 431.
 Always pl ace wheel blocks under both the vehicle and trailer
wheels when parking. Apply the parking brake firmly. Put
the transmission in “P”. Avoid parking on a slope with a
trailer, but if it cannot be avoided, do so only after performing
the following:
1. Apply the brakes and keep them applied.
2. Have someone place wheel blocks under both the vehicle
and trailer wheels.
3. When the wheel blocks are in place, release your brakes
slowly until the blocks absorb the load.
4. Apply the parking brake firmly.
5. Shift into “P” and turn off the engine.

IN CASE OF AN EMERGENCY
431
IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if you
hear a loud knocking or pinging noise, the engine has
probably overheated.
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in “P” and apply the
parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there is no sign
of steam or coolant. Your engine could have been seriously
damaged already. Call your Lexus dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.
B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.
 Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.

IN CASE OF AN EMERGENCY
4706. Say “Dial”.
Lexus
Link sends tone. The system will respond to the number
1.
INFORMATION
 To differentiate pound and star from other numbers
and commands, you must use the commands
“Pound key” and “Star key”.
 The Lexus Link voiceactivated keypad understands
only numbers, star key and pound key. It does not
understand stored nametags.
 You can erase the last number entered by saying
“Clear”.
STORING/DELETING NUMBERS IN MEMORY
(NAMETAGS)
Your Lexus Link System can store up to 20 phone
numbers. These numbers can be dialed by sim ply saying
“Call”, then saying the nametag.
Tips for creating nametags:
 Short nametags that are similar may be easily confused by
the system. You may get better recognition of your
nametags if you make them longer, for example “George
Washington” (no pause), instead of “George” only.
 The best way to store a nametag is when it is quiet inside the
vehicle. The vehicle should be stationary and the air
conditioning fan turned off.
 When you have finished speaking your phone number, you
do not need to say “Store number” or “Dial” to indicate that\
you are done. If you pause and say nothing, the system will
ask you if you want to store or dial. Say “Yes”.

IN CASE OF AN EMERGENCY
475
General tips for better speech recognition:

Noise may confuse the speech recognition system. You
usually get better performance from the system in quieter
conditions:

The air conditioning/heater fan creates noise. Turn it down
or off for better speech system performance.
 Driving at high speeds creates louder engine noise and wind
noise. You may get better results at lower speeds.
 An open window or an open moon roof results in more noise
in the vehicle. Close all windows for better results.
 Noisy rainstorms can also reduce performance.
 If passengers are talking while you use the speech system,
it may be confused by their speech. You will get better
results if all occupants of the vehicle are quiet while the
system is listening for commands.

Personal calling — the system is only listening for about 5
seconds after it prompts you to speak. If the system does not
hear a response, it will prompt you again, or cancel the
transaction. If you begin to speak too soon, it will tell you
“Slower, please”. Try pausing for a half second before
speaking.

Speak forcefully and clearly. The noisier the environment,
the louder you need to speak. If you are in the driver’s seat,
speak facing the front of the vehicle. If you are a passenger,
speak facing the inside rear view mirror.
 Speak calmly and naturally. The system may sometimes fail
to hear your repeated attempts to give a command. If your
speech is distorted by shouting or frustration, this may
cause more errors.
 People with high− pitched voices may have better results by
speaking in a deeper, lower−pitched voice. However, do not
lower the volume of the voice.
 Avoid speaking with a rising intonation, like asking a
question. Use a flat or falling intonation, like giving an
answer.

MAINTENANCE
488
DOES YOUR VEHICLE NEEDREPAIRING?
Be on the alert for changes in performance and sounds, and
visual tip −offs that indicate service is needed. Some important
clues are:
 Engine missing, stumbling, or pinging
 Appreciable loss of power
 Strange engine noises
 A fluid leak under the vehicle (However, water dripping from
the air conditioning after use is normal.)
 Change in exhaust sound (This may indicate a dangerous
carbon monoxide leak. Drive with the windows open and
have the exhaust system checked immediately.)
 Flat−looking tires, excessive tire squeal when cornering,
uneven tire wear
 Vehicle pulls to one side when driving straight on a level
road
 Strange noises related to suspension movement
 Loss of brake effectiveness, spongy feeling brake pedal,
pedal almost touches floors, vehicle pulls to one side when
braking
 Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Lexus
dealer as soon as possible. It probably needs adjustment or
repair.
CAUTION
Do not continue driving with the vehicle unchecked. It
could result in serious vehicle damage and possibly
personal injury.
