IN CASE OF AN EMERGENCY
463
Lexus Link System indicator and warning
lights
 1
Lexus Link System indicator light (green)
2
Lexus Link System warning light (red)
When the indicator light remains on, you have an active
subscription. You can obtain any of the Lexus Link services
available in your package.
When the indicator light starts flashing, a call to the Lexus
Link Call Center is being connected or in progress. When the warning light remains on,
there is any problem
with the Lexus Link system. Take your vehicle to your Lexus
dealer as soon as possible.
When the indicator and warning lights go off, your
subscription has expired.

IN CASE OF AN EMERGENCY
479
Voice phrase (English)
Voice phrase (Spanish)Explanation
$
Unable to contact Lexus Link$No pude conectarme con Lexus Link $A call is attempted, but failed.
$The Lexus Link system is not active.$$Su servicio Lexus Link no ha sido activa-
do. $The emergency button is pushed without
an active subscription.
$A system error has been detected.
Please contact your Lexus dealer. $$Un error en el sistema ha sido detectado.
Por favor contacte su concesionario
Lexus. $As a substitute of the faulty warning light

MAINTENANCE
486Battery
Check the battery condition by the indicator color. See page
551 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 521 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot. See page 511 for
additional
information.
Power steering fluid level
Check the level through the reservoir. The level should be in
the “HOT” or “COLD” range depending on the fluid
temperature. See page 522 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 343.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlights, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim. Service reminder indicators and warning buzzers
Check
that all service reminder indicators and warning buzzers
function properly.
Steering wheel
Check that it has the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position. For folding −up second and
third seats, and detachable third seat, check that the latches
lock securely.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.
Accelerator pedal
Check the pedal for smooth operation and uneven pedal ef fort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and free play. Check the brake booster function.

CHASSIS
543
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or
heavy corrosion, the wheel should be replaced.
If you fail to replace a damaged wheel, the tire may slip off the
wheel or cause loss of handling control.
Replacement with used wheels is not recommended as they
may have been subjected to rough treatment or high mileage
and could fail without warning. Also, bent wheels which have
been straightened may have hidden structural damage and
therefore should not be used. Never use an inner tube in a
leaking wheel which is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those removed in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability, headlight
aim, bumper height, vehicle ground clearance, and tire or snow
chain clearance to the body and chassis.
CAUTION
Observe the following instructions. Otherwise, an
accident may occur resulting in death or serious
injuries.
 Do not use wheels other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
 Do not use wheels of different brands, sizes and
types, as this may cause dangerous handling
characteristics resulting in loss of control.

ELECTRICAL COMPONENTS
550
No.FUSEAMPERECIRCUIT
47SRS10SRS airbag system, front
passenger occupant
classification system
48GAUGE7.5Gauges and meters
49ST27.5Multiport fuel injection
system/sequential multiport fuel
injection system
50FR
WIPWSH30Windshield wipers, windshield
washer
51TEMS20Electronic modulated
suspension
52DIFF20Four−wheel drive system
53RR WIP15Rear window wiper
54D P/SEAT30Driver’s power seat
55P P/SEAT30Front passenger’s power seat
56PWR
OUTLET15Power outlet (12 VDC)
57IG1 NO.210Rear air conditioning system,
inside rear view mirror, kinetic
dynamic suspension system
58RR WSH15Rear window washer
No.FUSEAMPERECIRCUIT
59ECUIG10
Shift lock control system, power
windows, outside rear view
mirror defogger, anti −lock brake
system, active traction control
system, vehicle stability control
system, air conditioning system,
navigation system, power
windows, moon roof, tilt and
telescopic steering,
multi −information display,
driving position memory
system, rear view monitor
system, tire pressure warning
system
60IG110
Air conditioning system, back −up
lights, rear window defogger,
seat heaters, vehicle stability
control system
61STA7.5Multiport fuel injection
system/sequential multiport fuel
injection system
62P FR P/W20Front passenger’s power window
63P RR P/W20Rear right side power window
