AUDIO
269
NOTICE
Make sure that the positive side of the remote control
battery is facing correctly.
 Do not replace the battery with wet hands. Water may
cause rust.
 Do not touch or move any components inside of the
remote control, or it may interfere with proper
operation.
 Be careful not to bend the electrode of the remote
control battery insertion and that dust or oil does not
adhere to the transmitter case.
 Close the battery case securely.
After replacing the battery, check that the remote control
operates properly. If the remote control still does not operate
properly, contact your Lexus dealer.
Headphone jacks
To use the jack, push the lid.
You can enjoy the rear seat audio system with commercial
headphone.
To use the headphones, connect them to the jack.
The key must be in the “ACC” or “ON” position.

AUDIO
278
Using your audio system: some basics
The following instructions are for the rear passengers.
Please let the rear passengers read and follow the
instructions when the rear passengers use the rear seat
entertainment system.
This section describes some of the basic features of the rear
seat entertainment system. Some information may not pertain
to your system.
Your audio system adjusts to the optimum volume and tone
quality automatically. While the system is adjusting the audio
sound, the audio sound fades out and then fades in.
The rear seat entertainment system is designed for the rear
passengers to enjoy audio and DVD video separately from the
front audio system.
The rear seat entertainment system can be operated when the
ignition key is in the “ACC” or “ON” position.
The rear passengers can enjoy all modes (AM and FM radio,
cassette tape player, CD player with changer and DVD player)
on the rear seat entertainment system only if a cassette tape
and a CD are loaded in the front audio system. The rear seat entertainment system can play DVD video, audio
CD, video CD, CD text, dts
−CD or DVD audio only when a disc
is loaded in the DVD player.
You can enjoy videos and sound when your personal audio
system is connected to the input terminal adapter on the rear
console box. For details, refer to the manufacturer’s
instructions.
You can enjoy the rear seat entertainment system with
commercial headphone. See “Headphone input jacks” on
page 331 for details.
You can also enjoy the rear seat entertainment system with a
wireless headphone. The wireless headphone can be used
within rear seat. If the signal becomes weak, the headphone
will mute. For details, refer to the manufacturer’s instructions.
With some wireless headphone generally available in the
market, it may be difficult to catch sound properly. Lexus
recommends the use of Lexus genuine wireless headphone.
You can purchase a wireless headphone at a Lexus dealer.

AUDIO
289
DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dtsCDs, DVD audio discs and video CDs.
For appropriate discs for this player, see “Audio/video system
operating hints” on page 333.
The DVD player works when the ignition key is in the “ACC” or
“ON” position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc
1. Push the center of the rear console box lid.
2. Push this button to open the cover.
3. Pull the lid forward.

AUDIO
292(c) Selecting the DVD mode
1Remote control button
2Mode selection screen
To select the DVD mode, push the “DVD” button on the
remote control.
You can also select the DVD mode on the mode selection
screen mentioned above.
“DVD” appears on the screen.
The “DVD Hint!” screen appears when the DVD mode is
first selected after you turn the ignition key to the “ACC”
or “ON” position.
Push the “OK” switch when you read the message.

AUDIO
296
1Top page (DVD video operation switch)
2Second page (DVD video operation switch)
3Top page (DVD audio operation switch)
4Second page (DVD audio operation switch)
5Top page (video CD)
6Second page (video CD)
There are operation switches on the “Top Page” and
“Second Page” screens.
To change the screen, push the “Top Page” or “Second
Page” switch on the screen.
If “” appears on the screen when you select a switch,
it indicates that the switch cannot work.
1Remote control button
2Screen switch
To turn off the switches on the screen, push the
“CURSOR” button on the remote control once again or
push the “Hide Keys” on the screen.

AUDIO
299
1Selecting switch on screen
2Selecting switch off screen
To select the menu for the disc, push the “
”, “”, “” or
“
” switches on the screen. Push the “Enter” switch to
select the menu for the disc.
You can also select the menu for the disc by the joy stick
and the “ENT” button on the remote control when the
control switches are not indicated on the screen.
Push the “Shift Keys” on the screen, and the switches (“
”,
“
”, “”, “”, “Enter” and “Shift Keys” switches) will move up
and down.
To turn off the switch, push the “OFF” switch on the screen. To
turn on the switch again, push the “ON” switch on the screen.
To return to the previous screen, push the “Back” switch on the
screen. (b) Operating the “
”, “
”, “\b\b ” and “ ”
switches/buttons
22PY062

AUDIO
303
(e) Selecting the bonus group (DVD audio only)
Enter the bonus group number on the searching group
screen and push the “Enter” switch on the screen. The
“Enter
Key Code” screen will appear. To enter the number
of the group you want to play, push the group number.
If you enter the wrong number, push the “Clear” switch on the
screen to delete the number.
Push the “Enter” switch on the screen. The player starts
playing the disc from the selected bonus group number. (f) Changing the still picture (DVD audio only)Push the “Still Prev.” or “Still Next” switch on the screen
to forward or reverse the still pictures.

AUDIO
320
Video CD/audio CD/CD text player operation
(a) Selecting the disc menu number (video CD only)
1Remote control button
2Screen switch
Push the “SEARCH” button on the remote control or the
“Sel. Number” switch on the screen, and the disc menu
number search screen will appear.
Enter the disc menu number by using the “ −”, “+” and “+10”
switches and push the “Enter” switch. The player starts playing
the disc from the entered disc menu number. The entered disc
menu number will appear on the screen.
Push the “Back” switch to return to the menu screen.
Move up and down the switches by pushing the “Shift keys” on
the screen.

AUDIO
330
Power outlet (115 VAC)
This power outlet is designed for use as a power supply
for the audio device connected to the input terminal
adapter.
The key must be in the “ON” position for the power outlet to be
used.
The maximum capacity for this power outlet is 115 VAC/100W.
If you attempt to use an appliance that requires more than 115
VAC or 100W, the protection circuit will activate and cut the
power supply. The power supply will restart automatically
when you use an appliance that operates within the 115
VAC/100W limits.
 Main switch
To use the power outlet, push the main switch on the
instrument panel.
An indicator light will illuminate to indicate that the power outlet
is ready for use.
Push the main switch once again to turn the power outlet off.
When the power outlet is not in use, make sure that the main
switch is turned off.

AUDIO
331
NOTICE
To prevent the battery from being discharged, do not
use the power outlet longer than necessary when the
engine is not running.
 Close the power outlet lid when the power outlet is
not in use. Inserting anything other than an
appropriate plug that fits the outlet, or allowing any
liquid to get into the outlet may cause electrical
failure or short circuits.
The power outlet is not designed for the following electric
appliances even though their power consumption is
under 115 VAC/100W. These appliances may not operate
properly.
Appliances with high initial peak wattage: Cathode−ray
tube type televisions, compressor −driven refrigerators,
electric pumps, electric tools, etc.
 Measuring devices which process precise data: Medical
equipment, measuring instruments, etc.
 Other appliances requiring an extremely stable power
supply: Microcomputer −controlled electric blankets, touch
sensor lamps, etc.
Certain electrical appliances may cause radio noise.
Headphone jacks
To use the jack, push the lid.
You can enjoy the rear seat entertainment system with
commercial headphones.
To use the headphones, connect them to the jack.
The key must be in the “ACC” or “ON” position.
