Page 410 of 601
STARTING AND DRIVING
389
NOTICE
Do not use liquid sealants for a flat tire as air pressure
sensors will be damaged.
When the tires must be repaired or replaced, have
them repaired or replaced by the nearest Lexus
dealer or authorized tire dealer. The tire pressure
sensors will be affected by the installation or removal
of tires.
The tire pressure warning system is not to be used as
a substitute for regular inspections. Be sure to check
the air pressure in the tires on a regular basis.
When the tires must be replaced, replace the
grommets for air pressure sensors as well.
If the warning light blinks:
The tire pressure warning system may be malfunctioning.
Contact your Lexus dealer.
System malfunction
The tire pressure warning system does not function
properly under certain circumstances. In the following
cases, the low tire pressure warning light may not come
on even if the tire inflation pressure is low, or it may come
on when the tire inflation pressure is actually normal.
Electric devices or facilities using similar radio wave
frequencies are nearby.
A radio set to similar frequencies is in use.
A lot of snow or ice covers the vehicle, in particular, around
the wheels or wheel housings.
The tires are not equipped with an air pressure sensor.
Tire chains are used.
Non −genuine Lexus wheels are used.
Although the tires are equipped with air pressure sensors,
the selector switch (see page 393.) is set to other tire setting.
Page 411 of 601
STARTING AND DRIVING
390
CAUTION
The use of non genuine wheels will cause the air
pressure sensors to transmit the electronic code in
different manner, resulting in the system failure.
The use of different type of tires with genuine wheels
may also cause the malfunction of the system.
CAUTION
Each tire, including the spare (if provided), should be
checked monthly when cold and inflated to the inflation
pressure recommended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure label (tire
and load information label). (If your vehicle has tires of
a different size than the size indicated on the vehicle
placard or tire inflation pressure label (tire and load
information label), you should determine the proper tire
inflation pressure for those tires.)
Page 412 of 601
STARTING AND DRIVING
391
As an added safety feature, your vehicle has been
equipped with a tire pressure monitoring system
(TPMS — tire pressure warning system) that
illuminates a low tire pressure telltale (low tire
pressure warning light) when one or more of your
tires is significantly under inflated. Accordingly,
when the low tire pressure telltale (low tire pressure
warning light) illuminates, you should stop and check
your tires as soon as possible, and inflate them to the
proper pressure. Driving on a significantly
under inflated tire causes the tire to overheat and can
lead to tire failure. Under inflation also reduces fuel
efficiency and tire tread life, and may affect the
vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning
system) is not a substitute for proper tire maintenance,
and it is the driver’s responsibility to maintain correct
tire pressure, even if under inflation has not reached
the level to trigger illumination of the TPMS low tire
pressure telltale (low tire pressure warning light).
For vehicles sold in U.S.A.
This device complies with Part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful in-
terference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is en-
couraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and re-
ceiver.
Connect the equipment into an outlet on a circuit dif ferent
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC WARNING:
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Page 413 of 601
STARTING AND DRIVING
392For vehicles sold in Canada
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this de-
vice must accept any interference, including interference
that may cause undesired operation of the device.
Replacing tires and wheels
When replacing the wheels, be sure to install air pressure
sensors on the wheels.
There are 3 ways to set up the air pressure sensors:
(a) Remove the sensor
from the old wheel and install it to the
new wheel.
(b) Keep the same wheel with air pressure sensor and replace
only the tire.
(c) Use a new wheel and sensor.
You have to register an ID code for a new sensor. Up to 2 sets
of codes can be registered. As one ID for the originally installed
sensor is registered at “MAIN” of the selector switch, use the
“2nd” position to register an ID for the new sensor.
You do not need to re −register the ID code for any other
replacements. For the use of the originally installed tires, put
the selector switch at “MAIN” and for the use of tires set
purchased later, put the switch at “2nd”. For the sensor
selector switch, see page 393.
Page 414 of 601
STARTING AND DRIVING
393
CAUTION
Have the tires, wheels or sensors replaced and ID
codes registered by a Lexus dealer. If you need
sensors, purchase from a Lexus dealer.
The use of non genuine wheels will cause the air
pressure sensors to transmit the electronic code in
different manner, resulting in the failure of the
system.
Selector switch
1Main position22nd position
The selector switch is located in the lower part of the
driver’s side instrument panel.
The ID code is given in the sensor. To activate the air
pressure wa rning system, it is necessary to register the ID
code of the sensor on the selector switch in the vehicle.
Page 415 of 601
STARTING AND DRIVING
3942 sets of ID codes can be registered. The code of the tires
originally
installed on the vehicle is registered on the switch at
“MAIN”. Have a new tires set with new air pressure sensors
registered at “2nd” by Lexus dealer.
ID codes should be registered by Lexus dealer. Once
registered, change the setting position each time you purchase
tires and wheels. Re −registration is not required.
When purchasing new tires, consult your Lexus dealer.
CAUTION
When the tires whose ID code is registered at “MAIN”
are used, the system does not work properly with the
selector switch set at “2nd”. If the tires whose ID code
is registered at “2nd” are stored nearby, the system will
detect their tire pressure (and vice versa).
BRAKE PAD WEAR LIMIT INDICATORS
The brake pad wear limit indicators on your disc brakes
give a warning noise when the brake pads are worn to the
extent that replacement is required.
If you hear a squealing or scraping noise while driving, have the
brake pads checked and replaced by your Lexus dealer as
soon as possible. Expensive rotor damage can result if the
pads are not replaced when needed.
Page 416 of 601
STARTING AND DRIVING
395
LIMITED SLIP DIFFERENTIAL
Your Lexus is equipped with a limited−slip center differential
(transfer).
If one wheel — either front or rear — begins to spin, the transfer
(limited −slip center differential) is designed to aid traction by
automatically transmitting driving force to the wheels on the
other drive axle. It transmits driving force to the front wheels
if a rear wheel spins, and to the rear wheels if a front wheel
spins.
CAUTION
Do not start or run the engine while your vehicle is
supported by a jack. The vehicle could be driven off the
jack and could pose a danger or result in serious injury.
NOTICE
Use only a spare tire of the same size, construction and
load capacity as the original tires on your Lexus
because damage to the limited slip differential could
possibly occur with another tire type.
Page 421 of 601
DRIVING TIPS
400
OPERATION IN FOREIGNCOUNTRIES
If you plan to drive your Lexus in another country...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp −edged objects and other
road hazards. Failure to do so can lead to severe tire
damage such as a tire burst.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the trans mission in “P”. If necessary, block
the wheels.
Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably wet. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safely, pull to the side of the
road and call a Lexus dealer for assistance.
Page 422 of 601
DRIVING TIPS
401
CAUTION
Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
Do not leave your vehicle unattended while the
engine is running.
Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 352.
Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to skid or spin.
Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140 km/h
(85 mph) unless your vehicle has high speed
capability tires. Driving over 140 km/h (85 mph) may
result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are high speed
capability tires or not before driving at such speeds.
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.
If you drive through deep water over about 500 mm
(20 in.) in depth, put the vehicle height in the HI (High)
mode with the active height select switch and then
turn off the active height control suspension by
pushing the height control switch. Drive your vehicle
at 30 km/h (19 mph) or lower speed.
Page 430 of 601
DRIVING TIPS
409
Hitches
If you wish to install a trailer hitch, you should consult with
your Lexus dealer.
Use only a hitch recommended by the hitch manufacture
and the one which conforms to the total trailer weight
requirement.
If you wish to install an aftermarket hitch, the hitch must be
bolted securely to the vehicle frame and installed according
to the hitch manufactures’ instructions.
The hitch ball and king pin should have a light coat of grease.
Lexus recommends the ball mount assembly be removed
when not towing to prevent injury and to prevent damage in
the event of a rear end collision. After removing the ball
mount assembly, install the grommet to the hitch to prevent
entry of dirt and mud.NOTICE
Do not use axle mounted hitches as they can cause
damage to the axle housing, wheel bearings, wheels or
tires. Also, never install a hitch which may interfere with
the normal function of an Energy Absorbing Bumper.
Trailer ball
Follow these easy steps to properly determine the correct
trailer ball for your application:
1. Determine the correct trailer ball size for the trailer coupler.
Most couplers are stamped with the required trailer ball size.
The sizes you’ll most likely find stamped on the coupler are:
Trailer Class
Typical Trailer Ball Size
III 2 in.
II 2 in.
I 1 7/8 in.
2. Select the appropriate trailer ball to match or exceed the
gross trailer weight rating of the trailer. The trailer ball load
rating should be printed on the top of the ball.
