For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xiiPage
1Driving position memory switches
198
. . . . . . . . . . .
2Power window switches 40
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 41
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 204 . . . . . .
6Side vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switches 33
. . . . . . . . . . . . . . . . . . . .
9Center vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . . .
11Audio system 232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multiinformation display 63
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 214
. . . . . . . . . .
14Rear window defogger switch 38
. . . . . . . . . . . . . . . . . .
15Front passenger’s seat belt reminder light 55 . . . . . .
16“AIRBAG ON” and “AIRBAG OFF”
indicator lights 169. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Glove box 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Ashtray 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
19Cigarette lighter 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . . . Page
21Fourwheel drive control lever
356
. . . . . . . . . . . . . . .
22Automatic transmission selector lever 349 . . . . . . . .
23Parking brake lever 347
. . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock switch 356
. . . . . . . . . . . . . . .
25Power outlet (12 VDC) 81
. . . . . . . . . . . . . . . . . . . . . . . . .
26Downhill assist control switch 377
. . . . . . . . . . . . . . .
27Electronic modulated suspension
control switch 371 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Rear height control air suspension
switches 366. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Ignition switch 345
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30“2nd STRT” (second start) switch 355
. . . . . . . . . . . .
31Tire pressure warning system
selector switch 393 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Cruise control switch 362
. . . . . . . . . . . . . . . . . . . . . . .
33Audio remote control switches 250
. . . . . . . . . . . . . . .
34Instrument panel light control dial 74
. . . . . . . . . . . . . .
35Hood lock release lever 100
. . . . . . . . . . . . . . . . . . . . .
36Fuel filler door opener 101
. . . . . . . . . . . . . . . . . . . . . . .
37“RSCA OFF” (roll sensing of curtain
shield airbags off) switch 174 . . . . . . . . . . . . . . . . . . . .
38Outside rear view mirror defogger switch 39 . . . . . . .
39Power outlet (115 VAC) main switch 82
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xivPage
1Driving position memory switches
198
. . . . . . . . . . .
2Power window switches 40
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 22
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 41
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 204 . . . . . .
6Side vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and
fog light switches 30, 32, 33 . . . . . . . . . . . . . . . . . . . . . .
8Wiper and washer switches 33
. . . . . . . . . . . . . . . . . . . .
9Center vents 225
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 43
. . . . . . . . . . . . . . . . . . . . .
11Rear view monitor/navigation system display
including air conditioning controls and audio
system
(For the navigation system, see the separate
“Navigation System Owner’s Manual”.) 358 . . . . . . .
12Multiinformation display 63
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
14Rear window defogger switch 38
. . . . . . . . . . . . . . . . . .
15Front passenger’s seat belt reminder light 55 . . . . . .
16“AIRBAG ON” and “AIRBAG OFF”
indicator lights 169. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Glove box 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Audio system
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
19Ashtray 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. Page
20Cigarette lighter
80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Seat heater switches 44
. . . . . . . . . . . . . . . . . . . . . . . . . .
22Fourwheel drive control lever 356
. . . . . . . . . . . . . . .
23Automatic transmission selector lever 349 . . . . . . . .
24Parking brake lever 347
. . . . . . . . . . . . . . . . . . . . . . . . .
25Center differential lock switch 356
. . . . . . . . . . . . . . .
26Power outlet (12 VDC) 81
. . . . . . . . . . . . . . . . . . . . . . . . .
27Downhill assist control switch 377
. . . . . . . . . . . . . . .
28Electronic modulated suspension
control switch 371 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Rear height control air suspension
switches 366. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Ignition switch 345
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31“2nd STRT” (second start) switch 355
. . . . . . . . . . . .
32Tire pressure warning system
selector switch 393 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33Cruise control switch 362
. . . . . . . . . . . . . . . . . . . . . . .
34Speech command switch
See the separate
. . . . . . . . .
“Navigation System Owner’s Manual”.
35Audio remote control switches 250
. . . . . . . . . . . . . . .
36Instrument panel light control dial 74
. . . . . . . . . . . . . .
37Hood lock release lever 100
. . . . . . . . . . . . . . . . . . . . .
38Fuel filler door opener 101
. . . . . . . . . . . . . . . . . . . . . . .
39“RSCA OFF” (roll sensing of curtain
shield airbags off) switch 174 . . . . . . . . . . . . . . . . . . . .
40Outside rear view mirror defogger switch 39 . . . . . . .
41Power outlet (115 VAC) main switch 82
. . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xviPage
1Automatic transmission second start
indicator light 355
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 58
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 61
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 349 . . . . . .
6Driver’s seat belt reminder light 54
. . . . . . . . . . . . . . . .
7Turn signal indicator light 32
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 53
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 32
. . . . . . . . . . . .
10Antilock brake system warning light 57
. . . . . . . . . . .
11Open door warning light 58
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 30
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 362
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 60
. . . . . . . . . .
16Slip indicator light 373, 375, 378, 381
. . . . . . . . . . . . .
17Low engine oil pressure warning light 60
. . . . . . . . . .
18Charging system warning light 59
. . . . . . . . . . . . . . . . . Page
19Engine coolant temperature gauge
49
. . . . . . . . . . . . .
20Malfunction indicator lamp 56
. . . . . . . . . . . . . . . . . . . .
21Vehicle stability control system off
indicator light 376 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Roll sensing of curtain shield airbags off
indicator light 174. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Kinetic dynamic suspension system
warning light 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock indicator light 356
. . . . . . . .
25Vehicle stability control system and active
traction control system warning light 59 . . . . . . . . . . .
26Downhill assist control system
indicator light 378. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Height control indicator lights 370
. . . . . . . . . . . . . . .
28Security indicator light 12, 27
. . . . . . . . . . . . . . . . . . . .
29SRS warning light 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Trip meter reset knob 50
. . . . . . . . . . . . . . . . . . . . . . . . .
31Odometer and trip meter 50
. . . . . . . . . . . . . . . . . . . . . .
32Low fuel level warning light 61
. . . . . . . . . . . . . . . . . . . .
33Low tire pressure warning light 61
. . . . . . . . . . . . . . . .
34Fuel gauge 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xviiiPage
1Automatic transmission second start
indicator light 355
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 58
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 61
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 349 . . . . . .
6Driver’s seat belt reminder light 54
. . . . . . . . . . . . . . . .
7Turn signal indicator light 32
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 53
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 32
. . . . . . . . . . . .
10Antilock brake system warning light 57
. . . . . . . . . . .
11Open door warning light 58
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Tail light indicator light 30
. . . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 362
. . . . . . . . . . . . . . . .
15Slip indicator light 373, 375, 378, 381
. . . . . . . . . . . . .
16Low engine oil pressure warning light 60
. . . . . . . . . .
17Charging system warning light 59
. . . . . . . . . . . . . . . . .
18Engine coolant temperature gauge 49
. . . . . . . . . . . . . Page
19Malfunction indicator lamp
56
. . . . . . . . . . . . . . . . . . . .
20Vehicle stability control system off
indicator light 376 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Roll sensing of curtain shield airbags off
indicator light 174. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Kinetic dynamic suspension system
warning light 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock indicator light 356
. . . . . . . .
24Vehicle stability control system and active
traction control system warning light 59 . . . . . . . . . . .
25Downhill assist control system
indicator light 378. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26Height control indicator lights 370
. . . . . . . . . . . . . . .
27Security indicator light 12, 27
. . . . . . . . . . . . . . . . . . . .
28SRS warning light 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Trip meter reset knob 50
. . . . . . . . . . . . . . . . . . . . . . . . .
30Odometer and trip meter 50
. . . . . . . . . . . . . . . . . . . . . .
31Low fuel level warning light 61
. . . . . . . . . . . . . . . . . . . .
32Low tire pressure warning light 61
. . . . . . . . . . . . . . . .
33Fuel gauge 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GAUGES, METERS AND SERVICE REMINDER INDICATORS
59
(j) “VSC TRAC” Warning Light
This light warns that there is a problem somewhere in the
following.
Vehicle stability control system
 Active traction control system
 Downhill assist control system
 Hill −start assist control
The light will come on when the ignition key turned to “ON”, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the “ON” position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
When the brake fluid level is too low, the above −mentioned
systems will not operate and the warning light come on.
(k) “KDSS” Warning Light (vehicles with kinetic dynamic suspension system)
This light warns that there is a problem somewhere in the
kinetic dynamic suspension system.
The light will come on when the ignition key is turned to the
“ON” position and will go off after a few seconds.
If the light comes on while driving, bring your vehicle to your
Lexus dealer as soon as possible and have it checked.
(l) Charging System Warning Light
This warning light comes on when the ignition switch is turned
to the “ON” position, and goes off when the engine is started.
When there are problems in the charging system while the
engine is running, the warning light comes on.
NOTICE
When the charging system warning light comes on
while the engine is running, malfunctions such as the
engine drive belt being broken may have occurred. If
the warning light comes on, immediately stop the
vehicle in a safe place and contact your Lexus dealer.

OCCUPANT RESTRAINT SYSTEMS
143
1Front airbag sensors
2Seat belt pretensioner assemblies
3Front passenger occupant classification system
(ECU and sensors)
4SRS warning light
5Front passenger’s seat belt buckle switch
6Airbag sensor assembly
The front seat belt pretensioner system consists mainly of the
above components, and their locations are shown in the
illustration.
The front seat belt pretensioners are controlled by the airbag
sensor assembly. The airbag sensor assembly consists of a
safing sensor and airbag sensor.
When the front seat belt pretensioners are activated, an
operating noise may be heard and a small amount of non −toxic
gas may be released. This does not indicate that a fire is
occurring. This gas is normally harmless. Once
the front seat belt pretensioners have been activated, the
seat belt retractors remain locked.
CAUTION
 Do not modify, remove, strike or open the seat belt
pretensioner assemblies, airbag sensor or
surrounding area or wiring. Failure to follow these
instruction may prevent the seat belt pretensioners
from activating correctly, cause sudden operation of
the system or disable the system, which could result
in death or serious injury. Consult your Lexus dealer
about any repair and modification.
 Do not modify or change the suspension system.
Such changes may cause the curtain shield airbags
to inflate accidentally, which could result in death or
serious injury . Consult your Lexus dealer about any
repair and modification.
 Do not use tires or wheels other than the
manufacture’s recommended size. Such a use may
cause the curtain shield airbags and seat belt
pretensioners to inflate accidentally, which could
result in death or serious injury. For details, see
“Checking and replacing tires” on page 538.

OCCUPANT RESTRAINT SYSTEMS
144
Do not place luggage heavier than specified on the
roof luggage carrier. Such luggage may cause the
curtain shield airbags and seat belt pretensioners to
inflate accidentally, which could result in death or
serious injury. For details, see “Roof luggage
carrier” on page 107.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the seat belt
pretensioners in some cases.
 Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player
 Repairs on or near the front seat belt retractor
assemblies
 Modification of the suspension system
 Modification of the front end structure
 Attachment of a grille guard (bull bar, kangaroo bar,
etc.), snowplow, winches or any other equipment to
the front end
 Repairs made on or near the front fenders, the front
end structure and console
This indicator comes on when the ignition key is turned to
the “ON” position. It goes off after about 6 seconds. This
means the seat belt pretensioners are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
front passenger occupant classification system, “AIRBAG ON”
indicator light, “AIRBAG OFF” indicator light, front passenger’s
seat belt buckle switch, seat belt pretensioner assemblies,
inflators, warning light, “RSCA OFF” indicator light,
interconnecting wiring and power sources. (For details, see
“Service reminder indicators and warning buzzers” on page
51.)

OCCUPANT RESTRAINT SYSTEMS
153
Do not modify or remove any wiring. Do not modify,
remove, st rike or open any components, such as the
steering wheel pad, steering wheel, column cover,
front passenger airbag cover, front passenger airbag
or airbag sensor assembly. Doing so may prevent the
front airbag system from activating correctly, cause
sudden activation of the system or disable the
system, which could result in death or serious injury.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
If you wish to modify your vehicle for a person with a
physical disability, consult your Lexus dealer. It may
dangerously interfere with the SRS front airbags
operation.NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS front airbag
system in some cases.
 Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player
 Modification of the suspension system
 Modification of the front end structure
 Attachment of a grille guard (bull bar, kangaroo bar,
etc.), snowplow, winches or any other equipment to
the front end
 Repairs made on or near the front fenders, front end
structure, console, steering column, steering wheel
or dashboard near the front passenger airbag

OCCUPANT RESTRAINT SYSTEMS
165
Do not attach a microphone or any other device or
object around the area where the curtain shield
airbag activates such as on the windshield glass,
side door glass, front and rear pillars, roof side rail
and assist grips. When the curtain shield airbag
inflates, the microphone or other device or object will
be thrown away with great force or the curtain shield
airbag may not activate correctly, resulting in death
or serious injury.
 Do not hook a hanger , heavy or sharp pointed objects
on the coat hook. If the curtain shield airbag inflates,
those items will be thrown away with great force or
the curtain shield airbag may not activate correctly,
resulting in death or serious injury. When you hang
clothes, hang them on the coat hook directly.
 Do not use seat accessories which cover the parts
where the side airbags inflate. Such accessories may
prevent the side airbags from activating correctly,
causing death or serious injury.
 Do not modify or replace the seats or upholstery of
the seats with side airbags. Such changes may
prevent the side airbag system from activating
correctly, disable the system or cause the side
airbags to inflate accidentally, resulting in death or
serious injury.
 Do not disassemble or repair the front and rear pillars
and roof side rail containing the curtain shield
airbags. Such changes may disable the system or
cause the curtain shield airbags to inflate
accidentally, resulting in death or serious injury.
 Do not modify or change the suspension system.
Such changes may cause the curtain shield airbags
to inflate accidentally, which could result in death or
serious injury . Consult your Lexus dealer about any
repair and modification.
 Do not use tires or wheels other than the
manufacture’s recommended size. Such a use may
cause the curtain shield airbags and seat belt
pretensioners to inflate accidentally, which could
result in death or serious injury. For details, see
“Checking and replacing tires” on page 538.

OCCUPANT RESTRAINT SYSTEMS
166
Do not place luggage heavier than specified on the
roof luggage carrier. Such luggage may cause the
curtain shield airbags and seat belt pretensioners to
inflate accidentally, which could result in death or
serious injury. For details, see “Roof luggage
carrier” on page 107.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
If you wish to modify your vehicle for a person with a
physical disability, consult your Lexus dealer. It may
dangerously interfere with the SRS side airbags and
curtain shield airbags operation.
NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS side airbag
and curtain shield airbag system in some cases.
 Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player
 Modification of the suspension system
 Modification of the structure of the passenger
compartment
 Repairs made on or near the console or front seat
The indicator comes on when the ignition key is turned to
the “ON” position. It goes off after about 6 seconds. This
means the SRS side airbags and curtain shield airbags are
operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
front passenger occupant classification system, “AIRBAG ON”
indicator light, “AIRBAG OFF” indicator light, front passenger’s
seat belt buckle switch, front seat belt pretensioner
assemblies, inflators, warning light, “RSCA OFF” indicator
light, interconnecting wiring and power sources. (For details,
see “Service reminder indicators and warning buzzers” on
page 51 for instructions.)
