STARTING AND DRIVING
379
If you push the “DAC” switch to turn the system off while it is
in operation, the system will stop operating gradually. The
downhill assist control system indicator light will flash to alert
the driver. To continue driving at a low speed, push the “DAC”
switch to turn the system on.
The slip indicator light and downhill assist control system
indicator
light come on for a few seconds when the ignition key
is turned to “ON”. If any of the indicator lights does not come
on when the ignition is turned on, contact your Lexus dealer.
The brake actuator temperature increases during continuous
operation of the following systems.
 Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill −start assist control
If the brake actuator temperature becomes too high while any
of the systems is operating, a buzzer will start to sound
intermittently to indicate that the downhill assist control system
can no longer operate. In this case, stop your vehicle
immediately at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At this time, the slip indicator light
will come on and the downhill assist control system stops
operating temporarily in order to protect the brake actuator.
(Although the downhill assist control system does not operate,
it is no problem to continue your driving.) The system will be
automatically restored after a short time and the slip indicator
light goes out.
“VSC TRAC” warning light
If there is any abnormality in the system, the “VSC TRAC”
warning light will come on. When the “DAC” switch is
pushed, the downhill assist control system indicator light
also flash.

IN CASE OF AN EMERGENCY
460If problems are detected in the Lexus Link System, the warning
light comes on or you will hear “A system error has been
detected. Please contact your Lexus dealer.” In either case,
take your vehicle to your Lexus dealer.
Lexus Link
services may not be available in the following
cases.
 The components or wire harnesses for the system are
damaged.
 The Lexus Link Call Center is not operational.
 The antenna does not work properly due to vehicle damage.
 In a weak or non− cellular coverage area.
 Your vehicle is in area where the GPS signal is weak or
cannot be received.
 The Lexus Link subscription has expired.
NOTICE
Upon subscription expiration, all Lexus Link services
(i.e. automatic notification, emergency call functions,
service call functions, remote door locking/unlocking
function, remote horn and lights function) are
deactivated.
Remote Door Locking/Unlocking by Lexus
Link System
The Lexus Link System will allow your vehicle to be locked
and unlocked remotely.
If you find that your vehicle has not been locked, call the Lexus
Link Call Center 1 −800−25−LEXUS (Toll−Free)
(1−800−255−3987) and select the option for Lexus Link, the
Lexus Link Advisor can assist in locking your vehicle.
In case you are locked out, call the Lexus Link Call Center
1−800−25 Lexus (Toll −Free) (1−800−255−3987) and select
the option for Lexus Link, a Lexus Link Advisor can assist in
unlocking your vehicle.
Remote Horn and Lights by Lexus Link
System
The Lexus Link System can flash your headlights and
sound your horn remotely.
Whether you are parked on a city street or in a stadium parking
lot, Lexus Link makes it easy to locate your vehicle quickly.
Call the Lexus Link Call Center 1− 800−25−LEXUS (Toll −Free)
(1−800−255−3987) and select the option for Lexus Link. A
Lexus Link Advisor will flash your headlights and sound your
horn so you can find your vehicle.

IN CASE OF AN EMERGENCY
463
Lexus Link System indicator and warning
lights
 1
Lexus Link System indicator light (green)
2
Lexus Link System warning light (red)
When the indicator light remains on, you have an active
subscription. You can obtain any of the Lexus Link services
available in your package.
When the indicator light starts flashing, a call to the Lexus
Link Call Center is being connected or in progress. When the warning light remains on,
there is any problem
with the Lexus Link system. Take your vehicle to your Lexus
dealer as soon as possible.
When the indicator and warning lights go off, your
subscription has expired.

MAINTENANCE
486Battery
Check the battery condition by the indicator color. See page
551 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 521 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot. See page 511 for
additional
information.
Power steering fluid level
Check the level through the reservoir. The level should be in
the “HOT” or “COLD” range depending on the fluid
temperature. See page 522 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 343.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlights, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim. Service reminder indicators and warning buzzers
Check
that all service reminder indicators and warning buzzers
function properly.
Steering wheel
Check that it has the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position. For folding −up second and
third seats, and detachable third seat, check that the latches
lock securely.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.
Accelerator pedal
Check the pedal for smooth operation and uneven pedal ef fort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and free play. Check the brake booster function.

ELECTRICAL COMPONENTS
550
No.FUSEAMPERECIRCUIT
47SRS10SRS airbag system, front
passenger occupant
classification system
48GAUGE7.5Gauges and meters
49ST27.5Multiport fuel injection
system/sequential multiport fuel
injection system
50FR
WIPWSH30Windshield wipers, windshield
washer
51TEMS20Electronic modulated
suspension
52DIFF20Four−wheel drive system
53RR WIP15Rear window wiper
54D P/SEAT30Driver’s power seat
55P P/SEAT30Front passenger’s power seat
56PWR
OUTLET15Power outlet (12 VDC)
57IG1 NO.210Rear air conditioning system,
inside rear view mirror, kinetic
dynamic suspension system
58RR WSH15Rear window washer
No.FUSEAMPERECIRCUIT
59ECUIG10
Shift lock control system, power
windows, outside rear view
mirror defogger, anti −lock brake
system, active traction control
system, vehicle stability control
system, air conditioning system,
navigation system, power
windows, moon roof, tilt and
telescopic steering,
multi −information display,
driving position memory
system, rear view monitor
system, tire pressure warning
system
60IG110
Air conditioning system, back −up
lights, rear window defogger,
seat heaters, vehicle stability
control system
61STA7.5Multiport fuel injection
system/sequential multiport fuel
injection system
62P FR P/W20Front passenger’s power window
63P RR P/W20Rear right side power window
