check engine light Lexus GX470 2006 Starting and Driving / LEXUS 2006 GX470 OWNER'S MANUAL (OM60B99U)

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52IF THIS INDICATOR OR
BUZZER COMES ON...
DO THIS.
(e)orTake vehicle to Lexus
dealer.
(f)or
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(g)Close all side doors
and back door.
(h)Shift four− wheel drive
control out of “N”.
(i)Stop and check.
IF THIS INDICATOR OR BUZZER COMES ON...DO THIS.
(j)Take vehicle to Lexus
dealer.
(k)Take vehicle to Lexus
dealer.
(l)Stop immediately and
contact Lexus dealer.
(m)Stop and check.
(n)Replace engine oil.
(o)
Adjust tire inflation
pressure. If light
remains, contact
Lexus dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
56
(e) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
“ON” position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while driving,
first check the followings.
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp does not go off even after several trips, contact your
Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
 There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If engine speed does not increase when the accelerator pedal
is depressed, there may be a problem somewhere in the
electronic throttle control system. At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to “ACC” or “LOCK” position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (On−Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions inspection and maintenance (I/M)
programs” on page 489.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
59
(j) “VSC TRAC” Warning Light
This light warns that there is a problem somewhere in the
following.
Vehicle stability control system
 Active traction control system
 Downhill assist control system
 Hill −start assist control
The light will come on when the ignition key turned to “ON”, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the “ON” position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
When the brake fluid level is too low, the above −mentioned
systems will not operate and the warning light come on.
(k) “KDSS” Warning Light (vehicles with kinetic dynamic suspension system)
This light warns that there is a problem somewhere in the
kinetic dynamic suspension system.
The light will come on when the ignition key is turned to the
“ON” position and will go off after a few seconds.
If the light comes on while driving, bring your vehicle to your
Lexus dealer as soon as possible and have it checked.
(l) Charging System Warning Light
This warning light comes on when the ignition switch is turned
to the “ON” position, and goes off when the engine is started.
When there are problems in the charging system while the
engine is running, the warning light comes on.
NOTICE
When the charging system warning light comes on
while the engine is running, malfunctions such as the
engine drive belt being broken may have occurred. If
the warning light comes on, immediately stop the
vehicle in a safe place and contact your Lexus dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
60
(m) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on —
even for one block. It may ruin the engine.
(n) Engine Oil Replacement Reminder Light (for vehicles sold in U.S.A.)
This light acts as a reminder to replace the engine oil.
This light will come on when the ignition key is turned to “ON”
and will go off after about a few seconds.
When you drive for about 7200 km (4500 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to “ON” position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds 8000 km (5000 miles), the light will come on after the
ignition key is turned to “ON” position. The light will remain on\
thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible.
You need to reset the light after the engine oil replacement.
Reset the light by following the procedure below:
1. Turn the ignition key to the “ACC” or “LOCK” position with
the odometer reading shown. (For details, see “Odometer and
trip meter” on page 50.)
2. Turn the ignition key to the “ON” position while holding down
the trip meter reset knob.
Hold down the knob until the light goes off. Before the light
goes off, it illuminates for 3 seconds, flashes for 2 seconds and
illuminates for 1 second.

STARTING AND DRIVING
348
HOW TO START THE ENGINE
Cranking hold function
Once you turn the ignition key to “START” position and release
it, the cranking hold function continues to crank the engine in
“ON” position until it starts.
The function stops cranking the engine after about 25 seconds
maximum if the engine has not started yet. When you crank
the engine again, wait a few seconds and restart it.
If you hold the key in “START” position, the function will keep
cranking for about 30 seconds maximum.
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in “P”. If you need to restart the engine
while the vehicle is moving, put the selector lever in “N”. A
starter safety device will prevent the starter from operating if
the selector lever is in any drive position.
4. Depress the brake pedal and hold it to the floor until driving
off.
Starting the engine
Before starting the engine, be sure to follow the instructions in
“Before cranking”.
Normal starting procedure
The multiport fuel injection system/sequential multiport fuel
injection system in your engine automatically controls the
proper air −fuel mixture for starting. You can start a cold or hot
engine as follows:
With your foot off the accelerator pedal, turn the ignition key to
“START” position, then release it.
Engine should be warmed up by driving, not in idle. For
warming up, drive with smoothly turning engine until engine
coolant temperature is within normal range.
If the engine stalls...
Simply restart it, using the correct procedure given in normal
starting.
If the engine will not start...
See “If your vehicle will not start” on page 426.
NOTICE
 Do not race a cold engine.
 If the engine becomes difficult to start or stalls
frequently, have the engine checked immediately.

STARTING AND DRIVING
362
Check surroundings for safety.
If a bright light (for example, sunlight reflected off the vehicle
body) is picked up by the camera, the smear effect* peculiar to
the camera may occur.
*: Smear effect — A phenomenon that occurs when a bright
light (for example, sunlight reflected off the vehicle body) is
picked up by the camera; when transmitted by the camera, the
light source appears to have a vertical streak above and below
it.
CRUISE CONTROL
The cruise control is designed to maintain a set cruising
speed without requiring the driver to operate the
accelerator. Cruising speed can be set to any speed above
40 km/h (25 mph).
Within the limits of the engine’s capabilities, cruising speed can
be maintained up or down grades. However, changes in
vehicle speed may occur on steeper grades.
CAUTION
 To help maintain maximum control of your vehicle,
do not use the cruise control when driving in heavy
or varying traffic, or on slippery (rainy, icy or
snowcovered) or winding roads.
 Avoid vehicle speed increases when driving
downhill. If the vehicle speed is too fast in relation to
the cruise control set speed, cancel the cruise
control then downshift the transmission to use
engine braking to slow down.

STARTING AND DRIVING
368The height control indicator light indicates which mode is
selected. (See “(e) Height control indicator light” described
below.)

Selecting the “HI” mode
Push the height select switch on the “ ” side when the vehicle
speed is under about 30 km/h (19 mph).
To change the “N” mode to “HI”: Push the switch once.
To change the “LO” mode to “HI”: Push the switch twice. It
takes about 30 seconds until the “LO” mode changes to the “HI”
mode.
 Selecting the “N” mode
To change the “HI” mode to “N”: Push the height select
switch on the “
” side once.
To change the “LO” mode to “N”: Push the height select
switch on the “ ” side once.
 Selecting the “LO” mode
Push the height select switch on the “
” side while the vehicle
is stopped.
To change the “N” mode to “LO”: Push the switch once.
To change the “HI” mode to “LO”: Push the switch twice.
Even if the engine is stopped while the vehicle height is being
lowered, the operation continues for up to 25 seconds. If within
this 25 seconds, any of the side doors or the back door is
opened, operation will continue for a further 15 seconds.
NOTICE
 If the vehicle height is changed frequently when the
vehicle is heavily loaded, the compressor may
overheat causing the vehicle height adjustment
operation to stop.
 Before you lower the vehicle height with the height
select switch, check under the vehicle to make sure
nothing to damage the vehicle or no one to be injured
is there and that the underbody of the vehicle does
not touch the ground.
 After unloading, the height of a vehicl e equipped with
the rear height control air suspension becomes
slightly higher than the normal vehicle height. Take
sufficient care where the overhead height is
restricted.
 Do not select the “LO” mode in the bumpy roads. If
the underbody of the vehicle touches the rugged
road surface, the vehicle may be damaged.

STARTING AND DRIVING
371
(f) Parking and stopping tips
If you immediately stop the engine to park the vehicle after
off−road driving, the vehicle height is lowered slightly as the
vehicle becomes cool. When parking, make sure there is
nothing that will be in contact with the underbody of the vehicle.
When you start the engine, the vehicle returns to the previous
height.
If you park the vehicle for a long time, the vehicle height may
be gradually lowered. When parking for a long time, make sure
there is nothing that will be in contact with the underbody of the
vehicle. When you start the engine, the vehicle returns to the
previous height.
If you stop the engine, the vehicle height may change in
accordance with the change in the temperature. When you
start the engine, the vehicle returns to the previous height.
(g) Rear height control failure warning
If there is a problem somewhere in the rear height control air
suspension, the “N” mode is automatically selected. If this
occurs, the height control “OFF” indicator light blinks and the
vehicle height control cannot be activated until the malfunction
is corrected. If this is the case, bring your vehicle to your Lexus
dealer as soon as possible and have it checked.
ELECTRONIC MODULATED SUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1For driving on a bumpy road
2For ordinary driving such as in the city traffic
3For moderate high speed driving
4For sporty type driving such as on winding mountain
roads and high speed driving
5Soft
6Firm

STARTING AND DRIVING
373
Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the active traction control
system is in the self−check mode, but does not indicate a
malfunction.
When the active traction control system is operating, the
following conditions occur:
 The system controls the spinning of the 4 wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly. The slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
The brake actuator temperature increase during continuous
operation of the following systems.

Active traction control system
 Vehicle stability control system
 Downhill assist control system
 Hill −start assist control
If the brake actuator temperature becomes too high while any
of the systems is operating, a buzzer will start to sound
intermittently to indicate that the active traction control system
can no longer operate. In this case, immediately stop your
vehicle at a safe place.
If the system continues to operate, the buzzer sound changes
from intermittent to continuous. (The continuous buzzer
sounds for about 3 seconds.) At the time, the slip indicator light
will come on and the active traction control system temporarily
stops operating in order to protect the brake actuator.
(Although the active traction control system does not operate,
there is no problem to continue your driving.) The system will
be automatically restored after a short time and the slip
indicator light goes out.

STARTING AND DRIVING
375
VEHICLE STABILITY CONTROLSYSTEM
The vehicle stability control system helps provide
integrated control of the systems such as antilock brake
system, traction control, engine control, etc. This system
automatically controls the output of the brakes or engine
to help prevent the vehicle from skidding when cornering
on a slippery road surface or operating steering wheel
abruptly.
This system activates when the vehicle speed about more than
15 km/h (9mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the system is in the
self−check mode, but does not indicate a malfunction.
CAUTION
 Do not rely excessively on the vehicle stability
control system. Even if the vehicle stability control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks and an alarm sounds,
special care should be taken while driving.
Only use tires of specified size. The size,
manufacturer, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle
stability control system may not function correctly.
When replacing the tires or wheels, contact your
Lexus dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.
 Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.
