When Driving
Topic 3
Overview
Contents
Entering and Exiting
Topic 1
Before Driving
Topic 2
lStartingP. 2 1
lAutomatic TransmissionP. 2 2
lParking BrakeP. 2 2
lTu r n S i g n a l L e v e rP. 2 3
lEmergency Flasher SwitchP. 2 3
lCruise ControlP. 2 4
lTrip Information DisplayP. 2 5
lRoll Sensing Of Curtain Shield
Airbags Off SwitchP. 2 5
lCenter Differential Lock
SwitchP. 2 6
lTi r e P r e s s u r e Wa r n i n g S e l e c t
SwitchP. 2 6
lKeysP. 7
lTheft Deterrent System P.8
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
lCigarette LighterP. 2 6
lPow e r O u t l e t sP. 2 7
lFour-Wheel Drive Control
LeverP. 2 7
lDamping Mode Select
SwitchP. 2 8
lRear Height Control
SwitchP. 2 8
l“DAC” SwitchP. 2 8
lFront SeatsP.1 1
lSecond SeatsP.1 2
lThird SeatsP.1 3
lDriving Position Memory
SystemP.1 5
lHead RestraintsP.1 6
lSeatbeltsP.1 6
lOutside Rear View MirrorsP.1 7
lInside Rear View MirrorP.1 7
lSteering WheelP.1 8

When DrivingTopic 3
Starting ..................................................................... 21
Automatic Transmission ..................................... 22
Parking Brake ........................................................ 22
Turn Signal Lever .................................................. 23
Emergency Flasher Switch ................................ 23
Cruise Control ...................................................... 24
Trip Information Display ..................................... 25
Roll Sensing Of Curtain Shield Airbags
Off Switch ............................................................... 25
Center Differential Lock Switch...................... 26
Tire Pressure Warning Select Switch ............ 26
Cigarette Lighter.................................................. 26
Power Outlets ....................................................... 27
Four-Wheel Drive Control Lever ................... 27
Damping Mode Select Switch.......................... 28
Rear Height Control Switch ............................. 28
“DAC” Switch ........................................................ 28

Topic 3
When Driving
25
Trip Information Display
nDisplay information
lOutside temperature (shown)
lAverage fuel consumption
lCurrent fuel consumption
lDriving range
lAverage vehicle speed
lBarometer
lAltimeter
lElapsed time
nChanging the trip information display
The display changes sequentially each time the
“MODE” button is pressed.
Roll Sensing Of Curtain Shield Airbags
Off Switch
Push the “RSCA OFF” switch for a few seconds
with the ignition switch in the “ON” position.
The “RSCA OFF” indicator light will come on,
and the curtain shield airbags and seat belt
pretensioners will not activate in the event of a
vehicle rollover.
Push the switch again to turn roll sensing back on.
The following information concerning your vehicle is displayed.
This switch should only be used in situations where airbag inflation is not desired (such as
extreme off-road driving).

Topic 5
Driving Comfort
44
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Lexus Link System (If Equipped)
nButtons
Vo i c e k e y p a d b u t t o n
Sends number tones to an automated phone
system for example to access voicemail, dur-
ing a phone call
Vo l u m e c o n t r o l
Adjusts your Lexus Link System audio volume
Phone button
Makes or answers a phone call using the
hands-free personal calling service
Ends a call
“SERVICES” button
Contacts the Lexus Link Call Center for
information, directions or other services
Records a conversation for later playback
Emergency button
Makes a priority call to the Lexus Link Call
Center
nServices
The Lexus Link System offers the following services. For details about the services and sub-
scription, refer to the Owner’s Manual or call the Lexus Link Call Center at 1-800-25-
LEXUS (1-800-255-3987) (toll-free).
lAirbag deployment notification
If an airbag deploys, an emergency call is automatically placed to the Lexus Link Call
Center with your vehicle’s location. You do not need to press any buttons.
lEmergency assistance
When you press the Emergency button, a priority call is placed to the Lexus Link Call
Center with your vehicle’s location. At the Call Center, the Lexus Link Advisor can deter-
mine your vehicle’s location, communicate with you, and, if appropriate, contact the near-
est emergency service provider.
The Lexus Link System is a communication service that uses the GPS (Global Position-
ing System) data and cellular service to provide you with safety, security and conve-
nience. Button operation and voice commands are used to operate the system. To
operate the system, follow the voice guidance instructions.
1
2
3
4
5

52
Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Have the malfunction repaired immediately.
Open door warning lightTire pressure warning light
Low fuel level warning lightLow washer fluid warning light
aDriver’s seat belt
reminder lightEngine oil replacement
reminder light
(On the cen-
ter panel)
Front passenger’s seat belt
reminder light
See the Owner's Manual
Tu r n s i g n a l i n d i c a t o r“RSCA OFF” indicator
Headlight high beam indicatorCruise control indicator
Headlight indicator (U.S.A.)Downhill assist control system
indicator
Tail light indicator (Canada)“VSC OFF” indicator
Security indicatorCenter differential lock
indicator
Automatic transmission
second start indicatorSlip indicator
Shift position indicators
“A I R B A G O N ” i n d i c a t o r
“AIRBAG OFF” indicator
Height control indicator
For further information, refer to the Owner's Manual.
