2
1-1. Key information ........................... 22Keys ...................................................... 22
1-2. Opening, closing and locking the doors...................................... 24
Wireless remote control .............. 24
Side doors .......................................... 26
Back door ............................................ 31
1-3. Adjustable components (seats, mirrors, steering
wheel, etc.) .................................. 34
Front seats .......................................... 34
Rear seats ........................................... 36
Driving position memory system ............................................... 45
Head restraints................................. 47
Seat belts ............................................ 49
Steering wheel.................................. 57
Inside rear view mirror................. 58
Outside rear view mirrors ........... 59
1-4. Opening and closing the windows and moon roof ........... 61
Power windows................................. 61
Moon roof .......................................... 64
1-5. Refueling ........................................ 67 Opening the fuel tank cap........... 67 1-6. Theft deterrent system............... 70
Engine immobilizer system ......... 70
Alarm.................................................... 72
Theft prevention labels (U.S.A.) ............................................. 74
1-7. Safety information ....................... 75 Correct driving posture ............... 75
SRS airbags ....................................... 77
Front passenger occupant classification system .................... 90
Child restraint sy stems ................. 95
Installing child restraints ............... 98
2-1. Driving procedures.................... 110 Driving the vehicle ......................... 110
Engine (ign ition) switch ............... 118
Automatic transmission................ 121
Turn signal lever............................. 124
Parking brake ................................. 125
2-2. Instrument cluster ..................... 126 Gauges and meters ..................... 126
Indicators and warning lights ... 129
Trip information display .............. 132
1Before driving
2When driving

Before driving1
21
1-1. Key information ............... 22Keys ............................................... 22
1-2. Opening, closing and locking the doors ........... 24
Wireless remote control ......... 24
Side doors.................................... 26
Back door ..................................... 31
1-3. Adjustable components
(seats, mirrors, steering
wheel, etc.) ..................... 34
Front seats ................................... 34
Rear seats .................................... 36
Driving position memory system ........................................ 45
Head restraints .......................... 47
Seat belts ..................................... 49
Steering wheel ........................... 57
Inside rear view mirror ........... 58
Outside rear view mirrors ...... 59 1-4. Opening and closing the
windows and moon
roof .................................. 61
Power windows ............................ 61
Moon roof ................................... 64
1-5. Refueling .......................... 67 Opening the fuel tank cap ...... 67
1-6. Theft deterrent system ... 70 Engine immobilizer system........................................ 70
Alarm............................................ 72
Theft prevention labels (U.S.A.)....................................... 74
1-7. Safety information........... 75 Correct driving posture ......... 75
SRS airbags ................................ 77
Front passenger occupant classification system.............. 90
Child restraint systems ........... 95
Installing child restraints......... 98

28
1-2. Opening, closing and locking the doors
Rear door child-protector lockThe door cannot be opened from
inside the vehicle when the locks
are set.
These locks can be set to prevent
children from opening the rear
doors. Push down rear door
switches to lock the rear doors.
Automatic door locking and unlocking systemsThe following functions can be set or canceled:
FunctionOperation
Shift position linked door
locking functionShifting the shift lever out of “P” locks all doors.
Shift position linked door
unlocking functionShifting the shift lever to “P” unlocks all doors.
Speed linked door locking
functionAll doors are locked when the vehicle speed is
approximately 12 mph (20 km/h) or higher.
Driver’s door linked door
unlocking function
All doors are unlocked when the driver’s door is
opened within 10 seconds after turning the
engine switch to the “ACC” or “LOCK” posi-
tion.

30
1-2. Opening, closing and locking the doors
■Locking the front doors from outside using the inside lock button
Push the inside lock button rearward and close the door while holding the door
handle up.
■If the wrong key is used
The key cylinder rotates freely to isolate the inside mechanism.
■Customization that can be configured at Lexus dealer
Settings (e.g. unlocking function using a key) can be changed. (Customizable fea-
tures P. 4 3 6 )
CAUTION
■To prevent an accident
Observe the following precautions while driving the vehicle.
Failing to do so may result in a door open ing and an occupant falling out, resulting in
death or serious injury.
●Always use a seat belt.
●Always lock all doors.
●Ensure that all doors are properly closed.
●Do not pull the inside handle of the front door while driving.
●Set the rear door child protector locks when children are seated in the rear seat.

52
1-3. Adjustable components (seats, mirrors, steering wheel, etc.)
Seat belt pretensioners (front seats)The pretensioner helps the seat
belt to quickly restrain the occu-
pant by retracting the seat belt
when the vehicle is subjected to
certain types of severe frontal colli-
sion.
The pretensioner may not activate
in the event of a minor frontal
impact, a side impact or a rear
impact.
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudd en stop or on impact. It may also lock if
you lean forward too quickly. A slow, easy motion will allow the belt to extend, and
you can move around fully.
■Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is
used to hold the child restraint system (CRS) firmly. To free the belt again, fully
retract the belt and then pull the belt out once more. ( P. 1 0 2 )

54
1-3. Adjustable components (seats, mirrors, steering wheel, etc.)
CAUTION
Observe the following precautions to reduce the risk of injury in the event of sudden
braking or an accident. Failing to do so may cause death or serious injury.
■Wearing a seat belt
●Ensure that all passengers wear a seat belt.
●Always wear a seat belt properly.
●Each seat belt should be used by one person only. Do not use a seat belt for more
than one person at the same time, including children.
●Children should be seated in the rear se at and always use a seat belt and/or an
appropriate child restraint system.
●Do not recline the seat any more than necessary to achieve a proper seating
position. The seat belt is most effective when the occupants are sitting up straight
and well back in the seats.
●Do not wear the shoulder belt under your arm.
●Always wear your seat belt low and snug across your hips.
■Seat belt precautions
●Do not place anything, such as a cushion, on the front passenger’s seat. Doing so
will disperse the passenger’s weight, wh ich prevents the sensor form detecting
the passenger’s weight properly. As a resu lt, the seat belt pretensioner for the
front passenger’s seat may not activate in the event of a collision.
●If the pretensioner has activated, the seat belt becomes locked: it cannot be fur-
ther extended, nor will it return to the stowed position. The seat belt cannot be
used again and must be replaced at your Lexus dealer.

61
1
Before driving
1-4. Opening and closing the windows and moon roof
Power windows
Lock switch
Press the switch down to lock the
passenger window switches.
Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.
The power windows can be opened and closed using the following
switches.
Closing
One-touch closing
*
Opening
One-touch opening
*
*: Pushing the switch in theopposite direction will stop
window travel partway.

98
1-7. Safety information
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly
secure the child restraint using the seat belt. If using the lower anchorages,
use the top strap as well, and be sure to secure both firmly.
Seat belts equipped with a
child restraint locking mecha-
nism (ALR/ELR belts except
driver’s seat belt) (P. 5 2 )
Child restraint lower anchor-
ages
Lower anchorages are pro-
vided for the right side seat and
between the center and left side
seats. (Buttons displaying the
location of the anchorages are
attached to the seats.)
Anchor bracket
(for top strap)
Anchor brackets are provided
for all second seats.

99
1-7. Safety information
1
Before driving
Installing child restraints using a seat belt (child restraint lock function belt)
■Rear facing Infant seat/convertible seat
Place the child seat on the rear
seat facing the rear of the vehicle.
Run the seat belt through the child
seat and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Fully extend the shoulder belt and
then allow it to retract slightly in
order to activate the ALR lock
mode.
Lock mode allows the seat belt to
retract only.
STEP1
STEP2
STEP3

100
1-7. Safety information
While pushing the child seat down
into the seat, allow the shoulder
belt to retract until the child seat is
securely in place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
■Forward facing Convertible seat
Place the child seat on the seat
facing the front of the vehicle.
Run the seat belt through the child
seat and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Fully extend the shoulder strap and
then allow it to retract slightly into
the ALR lock mode.
Lock mode allows the seat belt to
retract only.
STEP4
STEP1
STEP2
STEP3
