Master warning light Lexus HS250h 2010 Scheduled Maintenance Guide / LEXUS 2010 HS250H OWNERS MANUAL (OM75006U)

5
When trouble arises
495
5-2. Steps to take in an emergency
Follow the correction procedures.
After taking the specified steps to correct the suspected problem, check
that the warning light goes off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door or the
trunk is not fully closed.
Check that all the doors and
the trunk are closed.
Low fuel level warning light
Indicates remaining fuel is
approximately 2.2 gal. (8.3
L, 1.8 Imp. gal.) or less
Refuel the vehicle.
Driver’s seat belt reminder
light (warning buzzer)
*2
Warns the driver to fasten
his/her seat belt.Fasten the seat belt.
(On the center panel)
Front passenger’s seat belt
reminder light 
(warning buzzer)
*2
Warns the front passenger to
fasten his/her seat belt.
Fasten the seat belt.
Master warning light A buzzer sounds and the
warning light comes on and
flashes to indicate that the
master warning system has
detected a malfunction.
 P. 5 0 1

5
When trouble arises
501
5-2. Steps to take in an emergency
If a warning message is displayed
Stop the vehicle immediately.
A buzzer sounds and a warning message is shown on the multi-informa -
tion display. The following warning ind icates the pos
sibility of damage to
the vehicle that may lead to an acci dent. Immediately stop the vehicle in a
safe place and contact your Lexus dealer.
Wa r n i n g m e s s a g eDetails
Indicates abnormal engine oil pressure
A buzzer also sounds.
The warning message is displayed if the engine oil
pressure is too low.
Indicates a malfunction in the hybrid systemA buzzer also sounds.
If a warning is shown on the multi-information display, stay calm and per-
form the following actions:
Master warning light
The master warning light also
comes on or flashes in order to
indicate that a message is cur -
rently being displayed on the
multi-information display
.
Multi-information display
If any of the warning light comes on again af
ter the following actions
have been performed, contact your Lexus dealer.

602
Alphabetical index
TowingDinghy towing ..................................... 248
Emergency towing ...........................483
Trailer towing........................................247
TRAC......................................................... 225
Traction control ..................................... 225
Trailer towing.......................................... 247
Trip meter ................................................. 162
Trunk Opener ...................................................... 60
Turn signal lights Replacing light bulbs........................ 469
Switch ........................................................ 162
Wattage..................................................556
Vanity lights Vanity lights .......................................... 372
Wattage..................................................556
Vanity mirrors ........................................ 372
Vehicle identification number ........ 548
Vehicle stability control...................... 225
Ventilators ............................................... 375
VSC ............................................................ 225
Warning buzzers Brake system ....................................... 492
Open door ..........................................495
Seat belt reminder.............................495 Warning lights
AFS OFF ............................................... 493
Anti-lock brake system .................. 493
Brake assist system .......................... 493
Brake system ........................................492
Charging system ................................492
Cruise control ..................................... 493
Electric power steering warning light..................................... 493
Electronic engine control 
system.................................................. 493
High coolant temperature .............492
Hybrid battery system .................... 493
LKA .......................................................... 493
Low fuel level....................................... 495
Low tire pressure .............................. 495
Malfunction indicator lamp .......... 493
Master warning light........................ 495
Open door ........................................... 495
Pre-collision system......................... 493
Pretensioner ........................................ 493
Radar cruise control ........................ 493
Seat belt reminder light .................. 495
Slip indicator ........................................ 493
SRS airbags .......................................... 493
Tire pressure warning light .......... 495
V
W

606
What to do if...
■Warning lights
P. 4 9 4
or
P. 4 9 2P. 4 9 4
P. 4 9 2P. 4 9 4
P. 4 9 3P. 4 9 4
P. 4 9 3P. 4 9 4
P. 4 9 5
or
P. 4 9 3P. 4 9 5
P. 4 9 3P. 4 9 5
P. 4 9 5
or
P. 4 9 3P. 4 9 5
P. 4 9 4P. 4 9 6
P. 4 9 4
Brake system warning light
(red indicator)“AFS OFF” indicator light
Slip indicator light
Charging system warning
light“LKA” indicator light
High engine coolant temperature
warning lightCruise control indicator light
Brake system warning light(yellow indicator)Radar cruise control 
indicator light
Malfunction indicator lampOpen door warning light
Low fuel level warning light
SRS warning lightDriver’s seat belt reminder
light
“ABS” warning lightFront passenger’s seat belt
reminder light
Master warning light
Electric power steering system
warning lightTire pressure warning light
Pre-collision system warning
light
