159
2-1. Driving procedures
2
When driving
Turn signal lever
■Turn signals can be operated when
The “POWER” switch is in ON mode.
■If the indicator flashes faster than usual
Check that a light bulb in the front or rear
turn signal lights has not burned out.
The turn signal lever can be used to show the following intention of the
driver:
Right turn
Left turn
Lane change to the right
(push and hold the lever part-
way)
The right hand signals will flash
until you release the lever.
Lane change to the left (push
and hold the lever partway)
The left hand signals will flash
until you release the lever.

469
4-3. Do-it-yourself maintenance
4
Maintenance and care
Light bulbs
You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replacement
seems difficult to perform, contact your Lexus dealer.

For more information about replacing other light bulbs, contact your Lexus
dealer
.
■Preparing for light bulb replacement
Check the wattage of the light bulb to be replaced. ( P.
5 5 6 )
■ R
emove the engine compartment covers
 P.
4 2 3
■ F
ront bulb locations
Halogen headlights
Front side marker lightHeadlight low beam
Parking light
Front turn signal light
Front fog light
Headlight high beam

470
4-3. Do-it-yourself maintenance
LED headlights
■Rear bulb locations
Headlight high beam
Front fog lightFront turn signal light
Parking lightFront side marker light
Rear turn signal lightBack-up light
License plate light

473
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Front turn signal lights (halogen headlights)
Turn the bulb base counterclock-
wise.
Remove the light bulb.
■ F
ront turn signal lights (LED headlights)
Turn the bulb base counterclock-
wise.
Remove the light bulb.

478
4-3. Do-it-yourself maintenance
■Rear turn signal lights
Open the trunk lid and remove the
co
ver.
To prevent damage to the rear
combination assembly, cover the
tip of the screwdriver with a rag.
Remove the bolts, stopper rubber
and rear combination assembly.
Turn the bulb base counterclock -
wise.
Remove the light bulb.

479
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Lights other than the above
If any of the lights listed belo
w has burnt out, have it replaced by your
Lexus dealer.
● Headlight lo
w beams (LED headlight type)
● Side turn signal lights
● Stop
/tail lights
●T
ail lights
●R
ear side marker lights
●High mounted stoplight
● Ou
ter foot lights
■When replacing the front right headlight, fr ont turn signal lights and parking light
bulbs
■LED light bulbs
The headlight low beams (LED headlights type), side tu
rn signal lights, rear side
marker lights, stop/tail lights, tail lights and high mounted stoplight consist of a num -
ber of LEDs. If any of the LEDs burn out, take your vehicle to your Lexus dealer to
hav
e the light replaced.
Remove the securing clip and move the
washer fluid filler opening to allow easy
access to the light bulbs.
After replacing the bulbs, make sure to
secure the washer fluid filler opening with the
clip.

556
6-1. Specifications
Light bulbs
A: HB3 halogen bulbs
B: Double end bulbs 
C: Wedge base bulbs (clear) 
D: Wedge base bulbs (amber) 
E: H11 halogen bulbs 
F: Single end bulbs
Light BulbsBulb No.WTy p e
Exterior
LED headlights
High beam
Halogen headlights
High beam
Low beam
9005
9005 H1160
6055A
A E
Front side marker lightsW5W5C
Front turn signal lights3457NA28 /8F
Parking lightsW5W5C
Front fog lightsH1155E
Rear turn signal lightsWY21W21D
Back-up lightsW16W16C
License plate lightsW5W5C
Outer foot lights5C
Interior
Vanity lights8C
Front interior lights/Personal lights8C
Rear interior light8B
Trunk light3.8C
Door courtesy lights5C

596
Alphabetical index
Engine oilCapacity ................................................ 550
Checking ............................................... 424
Preparing and checking 
before winter .................................... 244
Engine oil maintenance data............ 426
Engine switch............................................147
Enhanced VSC...................................... 225
EPS ............................................................. 225
EV drive mode switch .......................... 152
Event data recorder ............................490
Floor mat ................................................. 380
Fluid Brake........................................................554
Washer ................................................... 432
Fog lights Replacing light bulbs........................ 469
Switch ........................................................194
Wattage..................................................556
Foot light ...................................................360
Foot well lighting ...................................360
Front fog lights
Replacing light bulbs........................ 469
Switch ........................................................194
Wattage..................................................556
Front passenger occupant 
classification system ............................115
Front passenger's seat belt 
reminder light......................................495 Front seats
Adjustment ...............................................64
Driver’s seat po sition memory ...... 68
Front side marker light Replacing light bulbs ....................... 469
Wattage ................................................. 556
Front turn signal lights Replacing light bulbs ....................... 469
Switch ........................................................ 162
Wattage ................................................. 556
Fuel Capacity ................................................550
Fuel gauge .............................................. 162
Gas station information .................608
Information ........................................... 557
Refueling .................................................... 92
Type ......................................................... 557
Fuel door ..................................................... 92
Fuel filler door ........................................... 92
Fuses .......................................................... 455
Garage door opener .......................... 383
Gas station information .....................608
Gauges .......................................................162
Glove box ................................................ 364
Grocery bag hooks .............................. 381
F
G

598
Alphabetical index
Keyless entry.............................................. 54
KeysElectronic key ......................................... 39
Engine switch......................................... 147
If the electronic key does not 
operate properly ............................ 533
If you lose your keys......................... 532
Key number ............................................. 39
Keyless entry ........................................... 54
Keys ............................................................. 39
Mechanical key...................................... 40
Wireless remote control key .......... 54
Lane keeping assist ................................217
License plate lights Replacing light bulbs........................ 470
Wattage..................................................556
Light bulbs Replacing ............................................... 469
Wattage..................................................556
Light Door courtesy lights.........................360
Fog light switch .....................................194
Footwell lights......................................360
Headlight switch ................................. 183
Interior light list ....................................360
Interior light switch ..............................361
Outer foot lights .................................360
Personal light switch ..........................361
Remote touch light............................360
Replacing light bulbs........................ 469
Scuff lighting .........................................360
Turn signal lever ................................... 162
Turn signal light bulbs...................... 469
Turn signal light switch...................... 162 Vanity lights........................................... 372
Wattage ................................................. 556
LKA .............................................................. 217
Load capacity......................................... 243
Maintenance Do-it-yourself maintenance........... 416
General maintenance......................... 411
Maintenance data ............................. 548
Maintenance requirements.......... 409
Meter Instrument panel light control ....... 163
Meters ....................................................... 162
Micro dust and pollen filter .............. 256
Mirrors Inside rear view mirror ........................ 81
Side mirror heater............................. 260
Side mirrors............................................. 83
Vanity mirrors ...................................... 372
Moon roof................................................... 89
MP3 disc ................................................... 281
Multi-information display ....................169
Noise from under vehicle ......................18
Odometer .................................................162
Oil Engine oil................................................424
Opener Fuel filler door ......................................... 92
Hood ......................................................... 419
Trunk........................................................... 60K
L
M
N
O

599
Alphabetical index
Outer foot lightsOuter foot lights................................. 360
Wattage ................................................. 556
Outside rear view mirrors Adjusting and folding ......................... 83
Driving position memory ................. 68
Mirror position memory ................... 68
Outside temperature display ............ 169
Overhead console .............................. 370
Overheating, Engine ............................ 541
Overheating, Hybrid system............. 541
Parking brake .......................................... 163
Parking lights Replacing light bulbs ....................... 469
Switch ........................................................183
Wattage ................................................. 556
PCS.............................................................232
Personal lights Personal lights ....................................... 361
Switch ........................................................ 361
Wattage ................................................. 556
Power outlet ............................................374
Power switch............................................ 147
Power windows........................................ 86
Pre-collision system .............................232 Radar cruise control ............................205
Radiator ....................................................430
Radio ......................................................... 265
Radio data system ................................ 267
RDS ............................................................ 267
Rear side marker lights
Replacing light bulbs ........................ 479
Wattage ................................................. 556
Rear sunshade ....................................... 378
Rear turn signal lights Replacing light bulbs ........................470
Wattage ................................................. 556
Rear view mirror Compass................................................. 391
Rear window defogger ......................260
Replacing Electronic key battery ......................453
Fuses........................................................ 455
Light bulbs ............................................ 469
Tires ........................................................... 521
Reporting safety defects for 
U.S. owners ......................................... 586
Safety connect .......................................395
Scuff lighting ...........................................360
P
R
S
