125
2-1. Driving procedures
2
When driving
■If the automatic transmission fluid temperature warning light comes on
■AI-SHIFT
The AI-SHIFT automatically selects the optimal gear according to driver perfor-
mance and driving conditions.
The AI-SHIFT automatically operates when the shift lever is in the D position. How-
ever, operating the “-” paddle shift switch will restrict the function’s operation. (Shift-
ing the shift lever to the M po sition cancels the function.)
CAUTION
■When driving on slippery road surfaces
Be careful of downshifting and sudden accele ration, as this could result in the vehi-
cle skidding to the side or spinning.
If the automatic transmission fluid tempera-
ture warning light comes on while driving,
make sure you return to normal D position
driving and reduce speed by easing off the
accelerator pedal. Stop the vehicle in a safe
place, shift the shift lever to the P position and
let the engine idle until the warning light goes
out.
When the warning light goes out, the vehicle
can be driven again.
If the warning light does not go out after wait-
ing a while, have your vehicle inspected by
your Lexus dealer.

5
When trouble arises
353
5-2. Steps to take in an emergency
Follow the correction procedures.After taking the specified steps to co rrect the suspected problem, check
that the warning light turns off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door or the
trunk is not fully closed.
Check that all doors and the
trunk are closed.
Low fuel level warning light
Remaining fuel
(Approximately 2.9 gal. [11 L,
2.4 Imp.gal.] or less)
Refuel the vehicle.
Automatic transmission fluid
temperature warning lightIndicates that the automatic
transmission fluid tempera-
ture is too high.
 P. 1 2 5
(On the instru-
ment cluster)
Driver’s seat belt reminder
light (warning buzzer)
*2
Warns the driver to fasten
his/her seat belt.Fasten the seat belt.
(On the center panel)
Front passenger’s seat belt
reminder light
(warning buzzer)
*2
Warns the front passenger to
fasten his/her seat belt.
Fasten the seat belt.

405
6-1. Specifications
6
Vehicle specifications
Automatic transmission
*: The fluid capacity is provided as a reference. If replacement is necessary, con-tact your Lexus dealer.
Fluid capacity*11.1 qt. (10.5 L, 9.2 lmp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied by vibra-
tion, and ultimately damage the auto matic transmission of your vehicle.

447
Alphabetical index
Warning buzzersBrake system .......................................350
Open door .......................................... 353
Seat belt reminder ............................ 353
Warning lights Anti-lock brake system .................... 351
Automatic transmission fluid temperature warning light......... 353
Brake assist system ............................ 351
Brake system .......................................350
Charging system ................................. 351
Electric power steering warning light ....................................... 351
Low fuel level....................................... 353
Malfunction indicator lamp ............351
Master warning light ........................ 353
Open door ........................................... 353
Pre-collision system ........................... 351
Pretensioners ........................................ 351
Seat belt reminder light .................. 353
SRS airbags ............................................ 351
Tire pressure warning light........................................................ 353 Warning messages
Dynamic radar cruise control....................... 362, 365
Engine oil level ................................... 365
Engine oil maintenance ................. 365
Engine oil pressure ............................ 361
Engine oil temperature .................... 361
Hill-start assist control .....................364
Hood ....................................................... 365
Intuitive parking assist ......... 362, 365
Moon roof ............................................ 365
Open door ........................................... 365
Parking brake ..................................... 365
Pre-collision system............. 362, 365
Smart access system with push-button start ............................370
Steering lock.........................................362
Tire pressure warning system................... 362, 365
Traction control ..................................364
Trunk ....................................................... 365
Vehicle stability control ..................364
Washer fluid ........................................ 365
Washer Checking ...............................................295
Preparing and checking before winter .....................................180
Switch........................................................ 143
Washing and waxing ........................... 264W
*: Refer to the “Navigatio n System Owner’s Manual”

450
What to do if...
A warning light or indicator
light comes onP. 3 5 0If a warning light turns on or a warning
buzzer sounds...
■Warning lights
or or
P. 3 5 0P. 3 5 1
P. 3 5 3
or
P. 3 5 1P. 3 5 3
P. 3 5 3P. 3 5 3
P. 3 5 1P. 3 5 1
P. 3 5 3P. 3 5 1
P. 3 5 1P. 3 5 3
P. 3 5 3
Brake system warning lightMalfunction indicator lamp
“ABS” warning lightDriver’s seat belt reminder
light
Front passenger’s seat belt
reminder light
Low fuel level warning lightMaster warning light
SRS warning lightElectric power steering warning
light
Open door warning lightPre-collision system warn-
ing light
Charging system warning
lightTire pressure warning light
Automatic transmission fluid tempera-
ture warning light
