TABLE OF CONTENTSIndex
4
Power outlet .................................... 241
Seat heaters .................................... 242
Seat heaters and ventilators .... 244
Armrest ............................................ 246
Trunk storage extension............ 247
Coat hooks ..................................... 249
Floor mat......................................... 250
Trunk features................................. 251
Garage door opener .................. 254
Compass.......................................... 259
4-1. Maintenance and care............ 264 Cleaning and protecting the vehicle exterior................... 264
Cleaning and protecting the vehicle interior .................... 267
4-2. Maintenance ............................. 270 Maintenance requ irements ..... 270
General maintenance ................ 272
Emission inspection and maintenance (I/M)
programs ...................................... 275 4-3. Do-it-yourself
maintenance............................ 276
Do-it-yourself service precautions .................................. 276
Hood.................................................. 279
Positioning a floor jack.............. 280
Engine compartment.................. 282
Tires ................................................... 296
Tire inflation pressure................. 307
Wheels................................................. 311
Air conditioning filter................... 313
Electronic key battery ................. 316
Checking and replacing fuses ................................................. 318
Headlight aim................................. 332
Light bulbs ....................................... 334
5-1. Essential information .............. 340 If your vehicle needs to be towed ...................................... 340
If you think something is wrong ......................................... 346
Fuel pump shut off system ........ 347
Event data recorder ................... 348
4Maintenance and care
5When trouble arises

7
: If equipped
Tires
●Replacement
● Inflation pressure
● Information
P. 374
P. 407
P. 412
Tail lights P. 139
Side marker lights P. 139
Trunk P. 41
Rear window defogger P. 194
Doors P. 37
Fuel filler door P. 67
Rear turn signal lights
P. 126

264
4-1. Maintenance and care
Cleaning and protecting the vehicle exterior
■Automatic car washes
●Fold the mirrors back before washing the vehicle.
●Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle’s paint.
●Turn the wipers off before washing the vehicle.
■High pressure car washes
●Do not allow the nozzles of the car wash to come within close proximity of the
windows.
●Before car wash, check that the fuel filler door on your vehicle is closed prop-
erly.
■Aluminum wheels
Remove any dirt immediately by using a neutral detergent. Do not use hard brushes
or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same
mild detergent and wax as used on the paint.
Perform the following to protect the vehicle and maintain it in prime condi-
tion.
● Working from top to bottom, liber ally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.
● Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
● For hard-to-remove marks, use car wash soap and rinse thor-
oughly with water.
● Wipe away any water.
● Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle
body is cool.

309
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Effects of incorrect tire inflation pressure
Driving with incorrect tire inflation pressure may result in the following:
●Reduced fuel efficiency
●Reduced driving comfort and tire life
●Reduced safety
●Damage to the drive train
If a tire needs frequent refilling, have it checked by your Lexus dealer.
■Instructions for checking tire inflation pressure
When checking tire inflation pressure, observe the following:
●Check only when the tires are cold.
If your vehicle has been parked for at least 3 hours and has not been driven for
more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure
reading.
●Always use a tire pressure gauge.
The appearance of the tire can be misleadi ng. In addition, tire inflation pressures
that are even just a few pounds off can degrade ride and handling.
●Do not bleed or reduce tire inflation pressure after driving. It is normal for the
tire inflation pressure to be higher after driving.
●Never exceed the vehicle capacity weight.
Passengers and luggage weight should be placed so that the vehicle is bal-
anced.

5
When trouble arises
355
5-2. Steps to take in an emergency
■If the malfunction indicator lamp comes on while driving
First check the following:
●Is the fuel empty?
If it is, fill the fuel tank immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The lamp will go off after taking several driving trips.
If the lamp does not go off even after several trips, contact your Lexus dealer as
soon as possible.
■Front passenger detection se nsor and passenger seat belt reminder and warning
buzzer
●If luggage is placed on the front passenger seat, the front passenger detection
sensor may cause the warning light to flash and the warning buzzer to sound,
even if a passenger is not sitting in the seat.
●If a cushion is placed on the seat, the sensor may not detect a passenger, and the
warning light may not operate properly.
■When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level. Pushing the tire
pressure warning reset switch does not turn off the tire pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such as natural air
leaks or tire inflation pressure changes caus ed by temperature. In this case, adjust-
ing the tire inflation pressure will turn off the warning light (after a few minutes).
■When a tire is replaced with a spare tire
The compact spare tire is not equipped with the tire pressure warning valve and
transmitter. If a tire goes flat, the tire pressure warning light will not turn off even
though the flat tire is replaced with the spare tire. Replace the spare tire with the
repaired tire and adjust the proper tire inflation pressure. The tire pressure warning
light will turn off after a few minutes.

358
5-2. Steps to take in an emergency
CAUTION
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold
and inflated to the inflation pressure re commended by the vehicle manufacturer on
the vehicle placard or tire inflation pressu re label (tire and load information label).
(If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label [tire and load information label], you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicl e has been equipped with a tire pressure
monitoring system (TPMS-tire pressure warning system) that illuminates a low tire
pressure telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale (tire pres-
sure warning light) illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation
also reduces fuel efficiency and tire tread life, and may affect the vehicle's handling
and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for
proper tire maintenance, and it is the driv er's responsibility to maintain correct tire
pressure, even if under-inflation has not reached the level to trigger illumination of
the TPMS low tire pressure telltale (tire pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning system)
malfunction indicator to indicate when th e system is not operating properly. The
TPMS (tire pressure warning system) malfunction indicator is combined with the
low tire pressure telltale (tire pressure warning light). When the system detects a
malfunction, the telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon subsequent vehicle
start-ups as long as the malfunction exists . When the malfunction indicator is illumi-
nated, the system may not be able to detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of rea-
sons, including the installation of replacem ent or alternate tires or wheels on the
vehicle that prevent the TPMS (tire pres sure warning system) from functioning
properly. Always check the TPMS (tire pressure warning system) malfunction tell-
tale after replacing one or more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS (tire pressure warning
system) to continue to function properly.

447
Alphabetical index
Warning buzzersBrake system .......................................350
Open door .......................................... 353
Seat belt reminder ............................ 353
Warning lights Anti-lock brake system .................... 351
Automatic transmission fluid temperature warning light......... 353
Brake assist system ............................ 351
Brake system .......................................350
Charging system ................................. 351
Electric power steering warning light ....................................... 351
Low fuel level....................................... 353
Malfunction indicator lamp ............351
Master warning light ........................ 353
Open door ........................................... 353
Pre-collision system ........................... 351
Pretensioners ........................................ 351
Seat belt reminder light .................. 353
SRS airbags ............................................ 351
Tire pressure warning light........................................................ 353 Warning messages
Dynamic radar cruise control....................... 362, 365
Engine oil level ................................... 365
Engine oil maintenance ................. 365
Engine oil pressure ............................ 361
Engine oil temperature .................... 361
Hill-start assist control .....................364
Hood ....................................................... 365
Intuitive parking assist ......... 362, 365
Moon roof ............................................ 365
Open door ........................................... 365
Parking brake ..................................... 365
Pre-collision system............. 362, 365
Smart access system with push-button start ............................370
Steering lock.........................................362
Tire pressure warning system................... 362, 365
Traction control ..................................364
Trunk ....................................................... 365
Vehicle stability control ..................364
Washer fluid ........................................ 365
Washer Checking ...............................................295
Preparing and checking before winter .....................................180
Switch........................................................ 143
Washing and waxing ........................... 264W
*: Refer to the “Navigatio n System Owner’s Manual”

450
What to do if...
A warning light or indicator
light comes onP. 3 5 0If a warning light turns on or a warning
buzzer sounds...
■Warning lights
or or
P. 3 5 0P. 3 5 1
P. 3 5 3
or
P. 3 5 1P. 3 5 3
P. 3 5 3P. 3 5 3
P. 3 5 1P. 3 5 1
P. 3 5 3P. 3 5 1
P. 3 5 1P. 3 5 3
P. 3 5 3
Brake system warning lightMalfunction indicator lamp
“ABS” warning lightDriver’s seat belt reminder
light
Front passenger’s seat belt
reminder light
Low fuel level warning lightMaster warning light
SRS warning lightElectric power steering warning
light
Open door warning lightPre-collision system warn-
ing light
Charging system warning
lightTire pressure warning light
Automatic transmission fluid tempera-
ture warning light

452
GAS STATION INFORMATION
Auxiliary catch leverP. 2 7 9Trunk openerP. 4 1Fuel filler door P. 6 7
Hood lock release lever P. 2 7 9Fuel filler door openerP. 6 7Tire inflation pressureP. 4 0 7
Fuel tank capacity16.9 gal. (64 L, 14.0 lmp.gal.)
Fuel typeUnleaded gasoline only P. 68, 401
Cold tire inflation
pressureP. 4 0 7
Engine oil capacity
(Drain and refill)qt. (L, Imp.qt.)
With filter 9.8 (9.3, 8.2)
Without filter 8.7 (8.2
, 7. 2)
Engine oil type
Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 402
Recommended oil viscosity: SAE 5W-30
