Lexus IS F 2008 Do-It-Yourself Maintenance / LEXUS 2008 IS F QUICK GUIDE (OM53613U) User Guide

Topic 2
Before Driving
11
Seats
■Adjusting seat position
Moves the seat forward
Moves the seat backward
■Adjusting seatback angle
Tilts the seatback forward
Reclines the seatback
■Adjusting seat cushion
Raises and lowers the front of the cushion
Raises and lowers the entire seat
■Adjusting lumbar support
Firmer
Softer
1
2
1
2
1
2
1
2

Topic 2
Before Driving
12
Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Outside Rear View Mirrors
Selects a mirror to adjust (“L”: left or “R”: right)
Adjusts the mirror up, down, in, or out using
the switch
The mirrors will automatically angle downwards
when the vehicle is reversing.
To disable this function, set the mirror select switch
in the neutral position (between “L” and “R”).
Steering Wheel
Up
Down
Aw a y f ro m t h e d r i v e r
Toward the driver1
2
3
4
The steering wheel retracts automatically when the “ENGINE START STOP” switch is
turned OFF to allow for easy exit and entry. The steering wheel returns automatically to its
previously set position when the “ENGINE START STOP” switch is switched to ACCES-
SORY or IGNITION ON mode.

Topic 2
Before Driving
13
Driving and Seat Position Memory System
■Setting memory positions
While holding down the “SET” button, press and
hold one of the memory buttons (“1”, “2”, or “3”)
until you hear a beep.
The current position of the seat, as well as the
position of the steering wheel and the outside
rear view mirrors (for the driver's seat only) is
recorded.
■Recalling memory positions
Press one of the memory buttons (“1”, “2”, or “3”).
■Linking driving position memory with door unlock operation
While holding down the desired memory button,
press and hold on the wireless remote control
until you hear a beep.
To prevent triggering of the alarm, open one of
the doors within 60 seconds after the beep is
heard.
Your preferred driving position (the position of the driver's seat, steering wheel and the
outside rear view mirrors) and front passenger seat position can be memorized and
recalled with the touch of a button.
Linking driving position memory to the door unlock operation allows the memory position
to be recalled automatically when the driver's door is opened. (The linked function does not
operate if the driver's door is unlocked using the mechanical key or manually from inside
the vehicle.)

Topic 2
Before Driving
14
Entering and Exiting
Before Driving
When Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Head Restraints
To r a i s e: push the head restraint upward.
To l o w e r: push the head restraint down while
pressing the lock release button.
Seat Belts
■Adjusting shoulder belt height (front seats only)
To r a i s e: push the anchor upward.
To l o w e r: depress the button and push the anchor
down.
■Seat belt comfort guides (rear seats only)
If the shoulder belt sits close to the neck, slide the
comfort guide forward.
Lock
release
button

Topic 2
Before Driving
15
Anti-glare Inside Rear View Mirror
To turn automatic mode on/off, press the “AUTO”
button.
The indicator comes on when automatic mode is
turned on.
The anti-glare mirror uses a sensor to detect light from vehicles behind and automatically
reduces glare.

When DrivingTopic 3
Engine (Ignition) Switch....................................... 17
Automatic Transmission ...................................... 18
F-Sport Mode Total Control Switch ................ 21
Parking Brake ........................................................ 22
Turn Signal Lever .................................................. 22
Multi-information Display.................................. 23
Satellite Switches ................................................. 24
Emergency Flasher Switch ................................ 25
Intuitive Parking Assist ....................................... 25
Cruise Control ...................................................... 26
Dynamic Radar Cruise Control....................... 27

Topic 3
When Driving
17
Engine (Ignition) Switch
■Starting the engine
Make sure the parking brake is set and the shift
lever is in P.
Depress the brake pedal.
The “ENGINE START STOP” switch indi-
cator light turns green.
Press the “ENGINE START STOP” switch.
■Stopping the engine
Set the parking brake and shift the shift lever to P.
Press the “ENGINE START STOP” switch.
■Changing “ENGINE START STOP” switch modes
To change the “ENGINE START STOP” switch mode without turning on the engine, press
the “ENGINE START STOP” switch without depressing the brake pedal. The mode can be
changed in the following order:
With the electronic key on your person, the engine can be started by simply pressing the
“ENGINE START STOP” switch while depressing the brake pedal.
(The mechanical key cannot be used to start the engine.)
ACCE SSORY modeIGNITION ON mode
(Indicator light: amber) OFF
(Indicator light: off)

Topic 3
When Driving
18
Entering and Exiting
Before DrivingBefore Driving
When DrivingWhen Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Automatic Transmission
■Shift positions
PPa r k
RReverse
NNeutral (drive not engaged)
DDrive
MM mode
The vehicle can only be shifted out of P when
the “ENGINE START STOP” switch is in
IGNITION ON mode and the brake pedal is
depressed.

Topic 3
When Driving
19
■Changing shift ranges in the D position
Operating the paddle shift switches allows shift ranges to be selected to suit the driving con-
ditions.
Pull the “-” paddle shift switch toward you.
The indicator in the meter cluster will
change to display the selected shift range.
Higher shift range:
Pull the “+” paddle shift switch toward you.
Lower shift range:
Pull the “-” paddle shift switch toward you.
Pulling and holding the “+” paddle shift switch for a certain period of time allows you to
return to normal D position driving. If the accelerator pedal is depressed for more than a
certain period of time in one range, shift range selection in the D position will be automati-
cally deactivated.

Topic 3
When Driving
20
Entering and Exiting
Before DrivingBefore Driving
When DrivingWhen Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
■Changing gears in the M position
Operating the shift lever or paddle shift switches allows a gear to be selected and held,
enabling you to time gear shifts as you please while driving.
Shift the shift lever to M.
The indicator in the meter cluster will
change to display the selected gear.
To u p s h i f t :
Move the shift lever in the “+” direction, or
pull the “+” paddle shift switch toward you.
To d o w n s h i f t :
Move the shift lever in the “-” direction, or
pull the “-” paddle shift switch toward you.
In M mode, the gear will change only when the shift lever or paddle shift switches are oper-
ated. However, when the vehicle speed drops the gear will be automatically downshifted.
