display Lexus IS F 2008 Scheduled Maintenace Guide / LEXUS 2008 IS F QUICK GUIDE OWNER'S MANUAL (OM53613U)

1
When Driving
Topic 3
Entering and Exiting
Topic 1
Before Driving
Topic 2
Overview
Contents
●Engine (Ignition) SwitchP.1 7
●Automatic TransmissionP.1 8
●F-Sport Mode Total Control
SwitchP. 2 1
●Parking BrakeP. 2 2
●Tu r n S i g n a l L e v e rP. 2 2
●Multi-information DisplayP. 2 3
●Satellite SwitchesP. 2 4
●Emergency Flasher SwitchP. 2 5
●KeysP. 7
●Smart Access System with
Push-button StartP. 8
●Theft Deterrent SystemP.9
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
●Intuitive Parking AssistP. 2 5
●Cruise ControlP. 2 6
●Dynamic Radar Cruise
ControlP. 2 7
●Seats P.1 1
●Outside Rear View MirrorsP.1 2
●Steering WheelP.1 2
●Driving and Seat Position
Memory SystemP.1 3
●Head RestraintsP.1 4
●Seat BeltsP.1 4
●Anti-glare Inside
Rear View MirrorP.1 5

3
OverviewInstrument Panel
Paddle shift switch P.18
Headlight switch Turn signal lever Fog light switch P.29
P.22
P.30
Headlight cleaner switch P.29
Inside door lock buttons P.45
Fuel filler door opener P.47
Driving and seat position
memory switches
P.13
Door lock switches P.45
Power window switches P.46
Window lock switch P.46
Outside rear view
mirror switches
P.12
Trunk opener P.48
Hood release lever P.47
Parking brake pedal P.22
Satellite switches P.24
Tilt and telesc opic steering
control switch
P.12
Multi-information
display
P.23

Topic 1
Entering and Exiting
9
Theft Deterrent System
■Engine immobilizer system
The engine immobilizer system prevents the
engine from being started in the event that an
attempt is made to start the vehicle using an
unregistered key.
The security indicator light flashes to indicate that
the system is set.
■Alarm
The system sounds the alarm and flashes the lights when forcible entry is detected.
To set the alarm: close the doors, trunk and hood, and lock all doors. The security indicator
light comes on to indicate that the alarm is in its preparation state. When the indicator light
begins to flash, the system is armed.
To deactivate or stop the alarm: turn the “ENGINE START STOP” switch to ACCESSORY
or IGNITION ON mode, or unlock the doors or trunk using the entry function or the wire-
less remote control.
■Steering lock
The steering wheel locks when the “ENGINE
START STOP” switch is turned OFF and the
driver’s door is opened.
When the steering lock cannot be released, the
green indicator light on the “ENGINE START
STOP” switch will flash and a message will be
shown on the multi-information display. To release
it, press the “ENGINE START STOP” switch
while gently turning the wheel left and right.
The theft deterrent system includes the following features to help protect your vehicle from
theft.

When DrivingTopic 3
Engine (Ignition) Switch....................................... 17
Automatic Transmission ...................................... 18
F-Sport Mode Total Control Switch ................ 21
Parking Brake ........................................................ 22
Turn Signal Lever .................................................. 22
Multi-information Display.................................. 23
Satellite Switches ................................................. 24
Emergency Flasher Switch ................................ 25
Intuitive Parking Assist ....................................... 25
Cruise Control ...................................................... 26
Dynamic Radar Cruise Control....................... 27

Topic 3
When Driving
19
■Changing shift ranges in the D position
Operating the paddle shift switches allows shift ranges to be selected to suit the driving con-
ditions.
Pull the “-” paddle shift switch toward you.
The indicator in the meter cluster will
change to display the selected shift range.
Higher shift range:
Pull the “+” paddle shift switch toward you.
Lower shift range:
Pull the “-” paddle shift switch toward you.
Pulling and holding the “+” paddle shift switch for a certain period of time allows you to
return to normal D position driving. If the accelerator pedal is depressed for more than a
certain period of time in one range, shift range selection in the D position will be automati-
cally deactivated.

Topic 3
When Driving
20
Entering and Exiting
Before DrivingBefore Driving
When DrivingWhen Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
■Changing gears in the M position
Operating the shift lever or paddle shift switches allows a gear to be selected and held,
enabling you to time gear shifts as you please while driving.
Shift the shift lever to M.
The indicator in the meter cluster will
change to display the selected gear.
To u p s h i f t :
Move the shift lever in the “+” direction, or
pull the “+” paddle shift switch toward you.
To d o w n s h i f t :
Move the shift lever in the “-” direction, or
pull the “-” paddle shift switch toward you.
In M mode, the gear will change only when the shift lever or paddle shift switches are oper-
ated. However, when the vehicle speed drops the gear will be automatically downshifted.

Topic 3
When Driving
23
Multi-information Display
■Display information
●Trip information
Outside temperature
Driving range
Average fuel consumption
Average fuel consumption after refueling
Current fuel consumption
Average vehicle speed
Gear position
●Satellite switch mode
●Intuitive parking assist information
(if equipped)
●Dynamic radar cruise control settings
(if equipped)
●Wa r n i n g m e s s a g e s
■Changing the display of trip information
Trip information items can be switched by press-
ing the “DISP” switch.
The multi-information display shows information about your vehicle, including the items
shown below.
Ty p e ATy p e B
■When using the intuitive parking assist or dynamic radar cruise control, the appropriate
display is shown on the screen.
■In the event that a problem is detected in any of the vehicle's systems, a warning message is
shown on the multi-information display.

Topic 3
When Driving
24
Entering and Exiting
Before DrivingBefore Driving
When DrivingWhen Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Satellite Switches
The satellite switches can be used to change the
settings of the following items.
●Intuitive parking assist (if equipped)
●Tire inflation pressure warning system initial-
ization
●ID code selection for tire inflation pressure
warning system
●AFS (Adaptive Front-lighting System)
■Changing the settings
To cycle through the functions, press either the
left or right selector switch.
To change the settings, press the “ON/OFF”
button.
The satellite switches can be used to change the settings of various functions. Settings
are shown on the multi-information display.
For detailed information on changing the settings, see the Owner’s Manual.

Topic 3
When Driving
25
Emergency Flasher Switch
Engaging the emergency flasher switch causes all
the turn signal lights to flash.
The emergency flashers can be operated even
when the “ENGINE START STOP” switch is OFF.
Intuitive Parking Assist (If Equipped)
■Turning the system on and off
The system can be turned on and off using the satellite switch. (P. 2 4 )
■Screen display
Sensors are used to detect obstacles near the
vehicle. The distance to a detected obstacle is
shown by the number of indicator bars.
Indicates obstacles detected by the corner
sensors
Indicates obstacles detected by the back sen-
sors
The system uses a screen display and buzzer to inform the driver of obstacles near the
vehicle when parking or driving at low speed.
1
2

Topic 3
When Driving
27
Dynamic Radar Cruise Control (If Equipped)
■Cruise control display
Cruise control settings are shown on the multi-
information display.
Vehicle ahead indicator
Vehicle-to-vehicle distance
Preset speed
■Vehicle-to-vehicle distance control mode
Press the “ON-OFF” button.
Accelerate or decelerate to the desired
speed, and then push the lever down.
Vehicle-to-vehicle distance can be adjusted using
the distance switch.
■Constant speed control mode
Press the “ON-OFF” button.
Push the lever forward and hold for at least
one second.
Accelerate or decelerate to the desired
speed, and then push the lever down.
■Canceling
To temporarily cancel the dynamic radar
cruise control, pull the lever toward you. To
resume the cruise control, push the lever up.
To turn the system off, press the “ON-OFF”
button.
■Adjusting the speed setting
To increase speed: push the lever up.
To d e c r e a s e s p e e d: push the lever down.
Release the lever when the desired speed is
reached.
Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-
vehicle distance control mode.
1
2
3
1
2
The vehicle-to-vehicle distance control mode maintains the preset cruising speed as long
as no vehicle is detected ahead.
