turn signal bulb Lexus IS F 2011 Instrument Cluster / LEXUS 2011 IS F OWNERS MANUAL (OM53893U)

143
2-1. Driving procedures
2
When driving
Turn signal lever
■Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned out.
Right turn
Left turn
Move and hold the lever part-
way to signal a lane change
The right hand signal will flash
until you release the lever.
Move and hold the lever part-
way to signal a lane change
The left hand signal will flash
until you release the lever.

435
4-3. Do-it-yourself maintenance
4
Maintenance and care
Light bulbs
Replacing light bulbs■ Back-up lights
Open the trunk door and remove
the cover clips.
You may replace the following bulbs yourself. For more information about
replacing other light bulbs, contact your Lexus dealer.
■Preparing a replacement light bulb
Check the wattage of the light bulb being replaced. ( P. 512)
■ Bulb locations
Rear turn signal light Back-up light
STEP1

436
4-3. Do-it-yourself maintenance
Partly remove the cover. Remove
the wire harness and turn the bulb
base counterclockwise.
Remove the light bulb.
■ Rear turn signal lights
Open the trunk door and remove
the cover.
Remove the connector and turn
the bulb base counterclockwise.STEP2
STEP3
STEP1
STEP2

437
4-3. Do-it-yourself maintenance
4
Maintenance and care
Remove the light bulb.
■ Bulbs other than the above
If any of the bulbs listed below has burnt out, have your Lexus dealer
replace it.
●Headlight low and high beams (discharge bulbs)
● Headlight high beams
● Front fog lights
● Front turn signal lights
● Front side marker lights
● Stop/tail lights
● Tail lights
● Rear side marker lights
● High mounted stoplight
● License plate lights
● Daytime running ligh ts/parking lightsSTEP3

512
6-1. Specifications
Light bulbs
A: D4S discharge bulbs
B: H11 halogen bulbs
C: Wedge base bulbs (amber)
D: HB3 halogen bulbs
E: Wedge base bulbs (clear)
F: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
HeadlightsHigh beam
Low/high beam
9005
D4S6035DA
Front turn signal lights21C
Front fog lights55B
Rear turn signal lights21C
Back-up lights92116E
Outer foot lights5E
Interior
Vanity lights8E
Interior lights Front
Rear
53E F
Rear overhead courtesy light3F
Front door courtesy lights5E
Trunk light5F

558
Alphabetical index
InitializationItems to initialize ................................. 533
Inside rear view mirror .......................... 69
Interior lights Interior lights...........................................319
Switch ........................................................ 321
Wattage....................................................512
Jack Positioning a floor jack.................... 382
Vehicle-equipped jack ....................477
Jack handle .............................................. 477
Keyless entry.............................................. 39
Keys Electronic key ..........................................24
Engine switch........................................ 130
If you lose your keys........................ 488
If the electronic key does not operate properly ............................489
Key number ..............................................24
Keyless entry ........................................... 39
Keys ..............................................................24
Mechanical key...................................... 25
Wireless remote control key .......... 39 Lexus Enform*
Light bulbs
Replacing .............................................. 435
Wattage ................................................... 512
Lights Door courtesy lights .......................... 319
Emergency flasher switch..............442
Fog light switch ...................................... 161
Hazard light switch ...........................442
Headlights switch ................................158
Interior light switch ............................. 321
Outer foot lights................................... 319
Personal light switch .......................... 321
Replacing light bulbs ....................... 435
Shift lever light....................................... 319
Turn signal lever................................... 143
Vanity lights.......................................... 330
Wattage ................................................... 512
Load capacity......................................... 203
Maintenance Do-it-yourself maintenance......... 378
General maintenance......................374
Maintenance data ............................. 502
Maintenance requirements........... 372
J
K
L
M

560
Alphabetical index
Radar cruise control ............................. 169
Radiator ..................................................... 391
Radio .......................................................... 223
RDS ............................................................ 225
Rear turn signal lightsReplacing light bulbs........................ 435
Wattage....................................................512
Rear view mirror Compass ............................................... 354
Rear window defogger........................ 218
Replacing Electronic key battery........................ 417
Fuses ..........................................................419
Light bulbs............................................. 435
Reporting safety defects for U.S. owners ..........................................536
Safety connect ...................................... 358
Seat belts Adjusting the seat belt.......................... 61
Automatic locking retractor............ 62
Child restraint system installation ..............................................112
Cleaning and maintaining the seat belts ..................................... 370
Emergency locking retractor ......... 62
How to wear your seat belt............. 60
How your child should wear the seat belt .......................................... 63
Pregnant women, proper seat belt use......................... 62
Reminder light .....................................456
Seat belt extenders .............................. 63
Seat belt pretensioners ........................ 61 Seat heaters ............................................ 338
Seat position memory............................ 55
Seating capacity.................................... 203
Seats
Adjustment .............................................. 50
Adjustment precautions ................... 50
Child seats/child restraint system installation.............................. 112
Cleaning ................................................ 369
Driver’s seat position memory ........ 51
Front passenger seat position memory ................................................. 55
Head restraints ....................................... 57
Properly sitting in the seat................ 89
Seat heaters ......................................... 338
Service reminder indicators ............ 150
Shift lever If the shift lever cannot be shifted from P................................... 487
Transmission.......................................... 134
Shift lever light .........................................319
Shift lock system.................................... 487
Shopping bag hooks ........................... 345
Side airbags .................................................91
Side marker lights Switch ........................................................158
Side mirrors Adjusting and folding ............................71
Mirror position memory ..................... 51
Smart access system with push-button startEntry function ..........................................28
Starting the engine.............................. 130
“SOS” button..........................................358R
S

562
Alphabetical index
TiresChains ..................................................... 204
Checking ............................................... 397
If you have a flat tire ...........................477
Inflation pressure............................... 408
Inflation pressure sensor................ 397
Information............................................. 516
Replacing ................................................477
Rotating tires ........................................ 397
Size .............................................................. 511
Snow tires .............................................. 204
Tools ........................................................... 477
Total load capacity ...............................203
Towing Dinghy towing ..................................... 207
Emergency towing ........................... 443
Trailer towing.......................................206
TRAC.......................................................... 187
Traction control ...................................... 187
Transmission shift switches ...... 137, 139
Trip meter ................................................. 146
Trunk Extending trunk space ......................341
Opener ...................................................... 46
Trunk light Trunk light..................................................47
Wattage....................................................512 Turn signal lights
Replacing light bulbs ....................... 435
Switch ........................................................ 143
Wattage ................................................... 512
USB port ....................................... 246, 254
Vanity lights Vanity lights.......................................... 330
Wattage ................................................... 512
Vanity mirrors ........................................ 330
VDIM...........................................................187
Vehicle dynamics integrated management .........................................187
Vehicle identification number.........503
Vehicle stability control .......................187
Voice command switch ..................... 293
VSC .............................................................187
Warning buzzers Brake system ....................................... 453
Open door .......................................... 456
Seat belt reminder ............................ 456
U
V
W
