5-2. Steps to take in an emergency
When trouble arises
IS F_EE
Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
To prevent battery discharge
Turn off the headlights and the audio system while the engine is off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
Charging the battery
The electricity stored in the battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects
of certain electrical appliances. If the vehicle is left for a long time, the
battery may discharge, and the engine may be unable to start. (The bat-
tery recharges automatically during driving.)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors with the “ENGINE
START STOP” switch OFF.
Maintain the engine speed of the second vehicle and turn
the “ENGINE START STOP” switch to IGNITION ON
mode, then start the vehicle's engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at any autho-
rized Lexus dealer or repairer, or another duly qualified and
id fil iblSTEP2
STEP3
STEP4
STEP5

5
465
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the automatic
air conditioning system.
Check to see if steam is coming out from under the hood.
If you see steam:
Stop the engine. Carefully lift the hood after the steam
subsides and then restart the engine.
If you do not see steam:
Leave the engine running and carefully lift the hood.
Check to see if the cooling fans are operating.
If the fans are operating:
Wait until the temperature of the engine (shown on the
instrument cluster) begins to fall and then stop the
engine.
If the fans are not operating:
Stop the engine immediately and call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
After the engine has cooled
down sufficiently, check the
engine coolant level and
inspect the radiator core
(radiator) for any leaks.
If the engine compartment
cover needs to be removed:
STEP1
STEP2
STEP3
STEP4

466
5-2. Steps to take in an emergency
IS F_EE
Overheating
If you observe the following, your vehicle may be overheating.
The display on the engine coolant temperature gauge flashes or a loss of
power is experienced.
Steam is coming from under the hood.
CAUTION
To prevent an accident or injury when inspecting under the hood of your
vehicle
If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injury such as burns.
Keep hands and clothing away from the fans and belt while the engine is
running.
Do not loosen the coolant reservoir cap while the engine and radiator are
hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
Add engine coolant if neces-
sary.
Water can be used in an
emergency if engine coolant
is unavailable.
(P. 4 7 7)
Have the vehicle checked at the nearest authorized Lexus dealer
or repairer, or another duly qualified and equipped professional,
as soon as possible.
STEP5

475
6-1. Specifications
6
Vehicle specifica-
IS F_EE
Lubrication system
*: The engine oil capacity is a reference quantity to be used when exchang-
ing. Warm up and turn off the engine, wait more than 5 minutes, and
check the oil level on the dipstick.
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Lexus
recommends the use of approved “Toyota Genuine Motor Oil”.
Another motor oil of matching quality can also be used.
Oil grade:
5W-30 and 10W-30:
API grade SL “Energy-Conserving”, SM “Energy-Conserving”,
SN “Resource-Conserving” or ILSAC multigrade engine oil
15W-40 and 20W-50:
API grade SL, SM or SN multigrade engine oil
Oil capacity
(Drain and refill 
reference*)
without filter
with filter
8.2 L (8.7 qt., 7.2 Imp. qt.)
9.3 L (9.8 qt., 8.2 Imp. qt.)

478
6-1. Specifications
IS F_EE
Ignition system
Electrical system
Differential
*: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil”
at the factory. Use Lexus approved “Toyota Genuine Differential Gear
Oil” or an equivalent of matching quality to satisfy the above specifica-
Spark plug
Make
GapDENSO FK20HBR11
1.1 mm (0.043 in.)
NOTICE
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning the
engine.
Battery
Open voltage* at
20C (68F):12.6 12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(*: Voltage checked 20 minutes
after the engine and all the lights are
turned off)
Charging rates5 A max.
Oil capacity1.35 L (1.42 qt., 1.19 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential Gear
Oil LX 75W-85 GL-5 or equivalent

494
Alphabetical index
IS F_EE
Electric power steering ..............206
Electronic key
If the electronic key does not
operate properly .................458
Emergency, in case of
If a warning message is
displayed ............................431
If the engine will not start.....454
If the shift lever cannot be
shifted from P .....................456
If the vehicle has a discharged
battery.................................462
If the warning buzzer sounds425
If the warning light turns on .425
If you have a flat tire ...........444
If you lose your keys ............457
If you think something is
wrong .................................423
If your electronic key does not
operate properly .................458
If your vehicle becomes stuck ....
468
If your vehicle has to be
stopped in an emergency ....469
If your vehicle needs to be
towed ..................................417
If your vehicle overheats ......465
Emergency flashers
Switch ...................................416Engine
ACCESSORY mode ............ 146
Compartment ....................... 366
Engine switch ...................... 146
Hood .................................... 363
How to start the engine ........ 146
Identification number .......... 473
If the engine will not start .... 454
Ignition switch ..................... 146
Overheating ......................... 465
Engine compartment cover....... 367
Engine coolant
Capacity ............................... 477
Checking .............................. 372
Preparing and checking before
winter................................. 222
Engine coolant temperature
gauge ...................................... 161
Engine immobilizer system ........ 92
Engine oil
Capacity ............................... 475
Checking .............................. 369
Preparing and checking before
winter................................. 222
EPS ........................................... 206E

500
Alphabetical index
IS F_EE
Tachometer ................................161
Tail lights
Switch ...................................172
Talk switch* ..............................301
Telephone switch* ....................301
Theft deterrent system
Alarm ......................................97
Double locking system ...........96
Engine immobilizer system ....92
Tire inflation pressure ...............382
Tires
Chains ...................................222
Checking ...............................379
If you have a flat tire ............444
Inflation pressure ..................382
Replacing ..............................444
Rotating tires ........................379
Size .......................................480
Snow tires .............................222
Tools ..........................................444
Towing
Emergency towing ................417
Trailer towing .......................225
Traction control .........................206
Transmission shift switches ....153,
155
TRC ...........................................206
Trip meter ..................................161Trunk
Extending trunk space ......... 342
Opener ................................... 59
Trunk light
Trunk light ............................. 60
Wattage ................................ 481
Turn signal lights
Replacing light bulbs ........... 407
Switch .................................. 159
Wattage ................................ 481
USB port* ......................... 260, 268
Vanity lights
Vanity lights ........................ 331
Wattage ................................ 481
Vanity mirrors .......................... 331
VDIM ....................................... 207
Vehicle dynamics integrated
management ........................... 207
Vehicle identification number .. 473
Vehicle stability control ........... 206
VSC .......................................... 206T
