Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
1
Air Conditioning System
Using the automatic mode ........................................................................................................34
Adjusting the temperature in dual mode ............................................................................ 34
Anti-glare Inside Rear View Mirror...............................................................................................13
Ashtrays ..................................................................................................................................................... 41
Audio System
Basic operation .............................................................................................................................. 28
Radio................................................................................................................................................... 29
CD player ......................................................................................................................................... 30
Operating an iPod ........................................................................................................................ 33
Remote control (steering wheel switches) ......................................................................... 33
Automatic Transmission .....................................................................................................................15
Compass ................................................................................................................................................. 44
Console Boxes ..................................................................................................................................... 42
Cruise Control...................................................................................................................................... 23
Cup Holders .......................................................................................................................................... 43
Door Locks..............................................................................................................................................47
Driving and Seat Position Memory System................................................................................. 11
Dynamic Radar Cruise Control ....................................................................................................24
Emergency Flasher Switch ...............................................................................................................22
Engine (Ignition) Switch ...................................................................................................................... 14
Fog Lights................................................................................................................................................ 26
F-Sport Mode Total Control Switch/SNOW Mode Switch ..............................................18
Fuel Tank Cap ....................................................................................................................................... 49
Garage Door Opener ...................................................................................................................... 35
Glove Box............................................................................................................................................... 43
Head Restraints ...................................................................................................................................... 12
Headlight Cleaner .............................................................................................................................. 25
Headlights............................................................................................................................................... 25
Hood ......................................................................................................................................................... 49
Instrument Panel Light Control ......................................................................................................27
Interior Lights ........................................................................................................................................ 44
Intuitive Parking Assist .......................................................................................................................22
Keys .............................................................................................................................................................. 6
Lexus Enform with Safety Connect............................................................................................. 39
Luggage Mat ......................................................................................................................................... 46
Moon Roof ............................................................................................................................................. 48

2
Multi-information Display .................................................................................................................20
Outside Rear View Mirrors.............................................................................................................. 10
Parking Brake ......................................................................................................................................... 19
Power Windows ...................................................................................................................................48
Rear Window and Outside Rear View Mirror Defoggers ................................................ 27
Safety Connect ..................................................................................................................................... 37
Satellite Switches................................................................................................................................... 21
Seat Belts .................................................................................................................................................. 12
Seat Heaters............................................................................................................................................ 41
Seats ............................................................................................................................................................. 9
Smart Access System with Push-button Start ............................................................................ 7
Steering Wheel ...................................................................................................................................... 10
Theft Deterrent System ........................................................................................................................8
Trunk......................................................................................................................................................... 50
Trunk Storage Extension ..................................................................................................................45
Turn Signal Lever .................................................................................................................................. 19
Windshield Wipers and Washer ...................................................................................................26

3
OverviewInstrument Panel
Paddle shift switch P.15
Headlight switch
Turn signal lever
Fog light switch P.25
P.19
P.26
Headlight cleaner switch  P.25
Distance switch  P.24
Inside door lock buttons P.47
Fuel filler door opener P.49
Driving and seat position
memory switches
P.11
Power window switches P.48
Window lock switch P.48
Outside rear view
mirror switches
P.10
Trunk opener P.50
Hood release lever P.49
Parking brake pedal P.19
Satellite switches P.21
Tilt and telescopic steering
control switch
P.10
Multi-information
display
P.20
Door lock switches P.47

4
Paddle shift switch P.15
Windshield wiper and
washer switch
P.26
Engine (ignition) switch P.14
Air conditioning system P.34
Emergency flasher switch P.22
Rear window and outside rear
view mirror defoggers switch
P.27
Security indicator P.8
Audio system P.28
Glove box P.43
Trunk opener main switch P.50
See P.5.
Cruise control switch

Dynamic radar cruise control switch 
P.23
P.24
SNOW mode switch P.18
F-sport mode total control switch P.18
 : If equipped

10
Outside Rear View Mirrors
Selects a mirror to adjust (“L”: left or “R”: right)
Adjusts the mirror up, down, in, or out using
the switch
The mirrors will automatically angle downwards
when the vehicle is reversing.
To disable this function, set the mirror select switch
in the neutral position (between “L” and “R”).
Steering Wheel
Up
Down
Aw a y f ro m t h e d r i v e r
Toward the driver1
2
3
4
The steering wheel retracts automatically when the “ENGINE START STOP” switch is
turned OFF to allow for easy exit and entry. The steering wheel returns automatically to its
previously set position when the “ENGINE START STOP” switch is switched to ACCES-
SORY or IGNITION ON mode.

11
Driving and Seat Position Memory System
■Setting memory positions
Press the “SET” button, then within 3 seconds
press one of the memory buttons (“1”, “2”, or “3”)
until you hear a beep.
The current position of the seat, as well as the
position of the steering wheel and the outside
rear view mirrors (for the driver's seat only) is
recorded.
■Recalling memory positions
Press one of the memory buttons (“1”, “2”, or “3”).
■Linking driving position memory with door unlock operation (driver’s seat only)
While holding down the desired memory button,
press and hold on the wireless remote control
or door lock switch until you hear a beep.
To prevent triggering of the alarm, open one of
the doors within 180 seconds after the beep is
heard.
Your preferred driving position (the position of the driver's seat, steering wheel and the
outside rear view mirrors) and front passenger seat position can be memorized and
recalled with the touch of a button.
Linking driving position memory to the door unlock operation allows the memory position
to be recalled automatically when the driver's door is opened. (The linked function does not
operate if the driver's door is unlocked using the mechanical key or manually from inside
the vehicle.)

13
Anti-glare Inside Rear View Mirror
Without compass
Turns automatic mode on
Turns automatic mode off
The indicator comes on when automatic mode
is turned on.
With compass
Turns automatic mode on/off
The indicator comes on when automatic mode
is turned on.
The anti-glare mirror uses a sensor to detect light from vehicles behind and automatically
reduces glare.
1
2

27
Rear Window and Outside Rear View
Mirror Defoggers
Without navigation system
To defog the rear window and the outside rear
view mirrors, press the switch.
Press again to cancel.
With navigation system

Instrument Panel Light Control
Darker
Brighter
The system turns off automatically after 15 to 60 minutes.
1
2
