remote start Lexus IS F 2012 Specifications / LEXUS 2012 IS F (OM53A41U) User Guide

361
3-7. Other interior features
3
Interior features
■Programming a Rolling Code system (for U.S.A. owners)
If your device is Rolling Code eq uipped, follow the steps under the
heading “Programming the HomeLink
” before proceeding with the
steps listed below.
Locate the learn button on th e ceiling mounted garage door
opener motor. The exact location and color of the button may
vary by brand of garage door opener motor.
Refer to the operation manual supplied with the garage door opener
motor for the location of the learn button.
Press the learn button.
Following this step, you have 30 se conds in which to initiate step 3
below.
Press and hold the vehicle's programmed HomeLink button for
2 seconds and release it. Repeat this step once again. The garage
door may open.
If the garage door opens, the programming process is complete. If the
door does not open, press and release the button a third time. This third
press and release will complete the programming process by opening
the garage door.
The ceiling mounted garage door op ener motor should now recognize
the HomeLink
 signal and operate the garage door.
Repeat the steps above to prog ram another rolling code system
for any of the remaining HomeLink buttons.
■ Programming an entry gate (for U .S.A. owners)/Programming all
devices in the Canadian market
Place your transmitter 1 to 3 in. (25 to 75 mm) away from the sur-
face of the HomeLink
.
Keep the HomeLink indicator light in view while programming.
Press and hold the selected HomeLink button.
Repeatedly press and release (cyc le) the device’s remote control
button for two seconds each until step 4 is complete.
When the indicator light on the HomeLink
 compatible trans-
ceiver starts to flash rapidly, release the buttons.
STEP1
STEP2
STEP3
STEP4
STEP1
STEP2
STEP3
STEP4

430
4-3. Do-it-yourself maintenance
■If the electronic key battery is discharged
The following symptoms may occur.
●The smart access system with push-button start and wireless remote control will
not function properly.
●The operational range is reduced.
■Use a CR1632 lithium battery
●Batteries can be purchased at your Lexus dealer, jewelers, or camera stores.
●Replace only with the same or equivalent type recommended by a Lexus dealer.
●Dispose of used batteries according to the local laws.
■When the card key battery needs to be replaced (Canada only)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer
can replace the battery for you.
CAUTION
■Removed battery and other parts
Keep away from children. These parts are small and if swallowed by a child, they can
cause choking. Failure to do so could result in death or serious injury.
NOTICE
■For normal operation after replacing the battery
Observe the following precautions to prevent accidents.
●Always work with dry hands.
Moisture may cause the battery to rust.
●Do not touch or move any other comp onents inside the remote control.
●Do not bend either of the battery terminals.

5
When trouble arises
499
5-2. Steps to take in an emergency
If the electronic key does not operate properly
Locking and unlocking the doors, unlocking the trunk and key linked functions
Use the mechanical key built in to the electronic keys to operate the
doors. (P. 2 9 )
Doors Remove the cover on the driver’s
door handle.
Locks all the doors
Closes the windows/moon roof
(turn and hold)
Unlocks the door
Turning the key rearward unlocks
the driver's door. Turning the key
once again unlocks the other
doors.
Opens the windows/moon roof
(turn and hold)
If communication between the electron ic key and vehicle is interrupted
(  P. 36) or the electronic key cannot be used because the battery is
depleted, the smart access system with push-button start and wireless
remote control cannot be used. In su ch cases, the doors and trunk can be
opened or the engine can be started by following the procedure below.
STEP1
STEP2

538
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomizedsetting
Smart access
system with
push-button
start
(
P. 3 2 )
Operation signal
(Emergency flashers)OnOff
Operation signal
(Buzzer)OnOff
Wireless
remote con-
trol
(
P. 4 3 )
Unlocking operation
Driver's door
unlocked in one
step, all doors
unlocked in two
steps
All doors
unlocked in one
step
Automatic door lock
function to be activated if
door is not opened after
being unlocked
OnOff
Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being
unlocked
60 seconds
30 seconds
120 seconds
Your vehicle includes a variety of elec tronic features that can be personal-
ized to your preferences. Programming these preferences requires spe-
cialized equipment and may be performed by an authorized Lexus
dealership.
Some function settings are changed simultaneously with other functions
being customized. Contact your Lexus dealer for further details.

566
Alphabetical index
HeatersSeat heaters .......................................... 349
Side mirrors .......................................... 228
Hill-start assist control ......................... 197
Hood ..........................................................393
Hooks Cargo ......................................................356
Coat ......................................................... 354
Shopping bag ......................................356
Horn ............................................................ 149
I/M test ..................................................... 389
Identification Engine .......................................................513
Vehicle ......................................................513
Ignition switch.......................................... 134
Illuminated entry system ................... 330
Indicator lights......................................... 154
Initialization Items to initialize ................................. 543
Inside rear view mirror .......................... 72
Interior lights Interior lights.........................................330
Switch ...................................................... 332
Wattage.................................................. 522
Jack Positioning a floor jack.................... 394
Vehicle-equipped jack ................... 487
Jack handle .............................................. 487 Keyless entry ............................................. 43
Keys
Electronic key .........................................28
Engine switch ........................................ 134
If the electronic key does not operate properly............................ 499
If you lose your keys ........................ 498
Key number..............................................28
Keyless entry............................................ 43
Keys..............................................................28
Mechanical key ...................................... 29
Wireless remote control key........... 43
Lexus Enform*
Light bulbs Replacing ............................................... 447
Wattage ..................................................522
Lights Door courtesy lights ........................ 330
Emergency flasher switch............. 454
Fog light switch .................................... 166
Hazard light switch .......................... 454
Headlights switch ................................ 162
Interior light switch ............................332
Outer foot lights................................. 330
Personal light switch .........................332
Replacing light bulbs ........................ 447
Shift lever light..................................... 330
Turn signal lever................................... 147
Vanity lights............................................ 341
Wattage ..................................................522
Load capacity...........................................213
I
J
K
L
